STR-DG500

Audio Video Receiver

Key Features

660W-110 Watts X 6 (8ohms 1kHz, THD 0.7%)

Digital Cinema Auto Calibration w/ Mic (Auto

Speaker Setup)

HD Component Video Switching (2 Inputs/1

Output)

2 Optical Inputs /1 Coaxial Input

A/V Sync

Key Technologies

Digital Cinema Auto Calibration

Now the optimal speaker for your living room is only a press of button away.

Simply place the included microphone in your listening position and allow the strength of Sony’s Digital Signal

Processing to take over. Speaker placement, distance, and delays are all adjusted automatically to ensure a worry

free listening experience.

A/V Sync

Special Digital Signal Processing allows for lip sync delay to adjust to match the refresh rates of todays’

advanced flat panel televisions and microdisplays.

Digital Cinema Sound™

Sony’s original Digital Cinema Sound technology uses exclusive DSP technology to

recreate the precise environment of three Hollywood Dubbing Stages where your movies are created. True theater

sound in the home from the source.

EarlMartin ●

16450 West Bernardo Drive

●

San Diego, CA 92127

-1898

Last Updated: 07/25/2006

STR-DG500

Audio Video Receiver

Pleasevisit theDealer Networkfor current

information at www.sony.com/dn

Features

Audio

Dolby®

Digital Decoding:

Yes

Dolby® Pro Logic® II Decoding: Yes

DTS

® 96/24 Decoding: Yes

DTS

® NEO:6 Decoding: Yes

Dolby®

Digital EX Decoding:

Yes

Dolby® Pro Logic® IIX Decoding: Yes

Dolby® Pro Logic® Decoding: Yes

DTS

®-ES Decoding: Yes

Digital Cinema Sound

™

Technology: Yes

Convenience

Sound Fields: Yes

A/B Speaker Switch:

A / B / A+B

Digital Cinema Auto Calibration:

Yes (Mic-

Mono)

Specifications

Audio

Impedance: 8 Ohm

Channel Power Rating: 660W-110 Watts X 6

(8ohms, THD 0.7%), 600W-100 Watt x 6 (8

Ohms, THD .09%)

Sound Fields: Cinema - 3; Music - 3; Auto

Format Decoding - 11; 2 Channel - 1

Zones:

Single

Tuner Type: Auto Tuning, Direct Tuning,

Station Name

Convenience

AM/FM Memory Presets: 30 FM - 30 AM

Inputs and Outputs

Composite Video Input(s): 4 (1 Front, 3 Rear)

Composite Video Output(s): 1 (Rear)

Optical Audio Input(s): 2 (Rear)

Coaxial Audio Digital Input(s): 1 (Rear)

RCA Audio Input(s): 6 (2 Dedicated Audio, 4

Audio/Video)

RCA Audio Output(s): 1 (Rear)

Multi

-Channel Input(s): 1 (Rear, 5.1 Channel)

Subwoofer Output(s): 1 (Rear)

Antenna Terminal (AM Loop): 1 (Rear)

Antenna Terminal (FM 75 Ohm): 1 (Rear)

Headphone Output(s): Yes (Front-

Silver)

Speaker Terminal Type:

Screw Binding Posts (A

& B)

HD Component Video Input(s): 2 (Rear)

HD Component Video Output(s): 1 (Rear)

Power

Power Requirements: AC 120V, 60 Hz

Power Consumption (in Operation): TBD

Power Consumption (in Standby): TBD

Dimensions

Weight:

Approx. 17 Lbs. 10 oz. (8Kg)

Measurements: Approx. 17" x 6-1/5" x 12-

7/16" (430x157.5x316mm)

Supplied Accessories

Instruction Manual

FM Wire Antenna

AM Loop Antenna

Size AA Batteries: 2

Remote Commander® Remote Control

Color: Black

UPC Code: 027242683129

Sony, Remote Commander, and Digital Cinema Sound are trademarks of

Sony. Dolby, Dolby Digital, ProLogic are registered trademarks of Dolby

Laboratories. dts is a trademark of Digital Theater Systems, L.P. All other

trademarks are property of their respective owners.

Features and specifications are subject to change without notice. All

Weights and measures are approximate.
