Sony DRC-BT60 Manuel utilisateur

Wireless

Audio Receiver

4-169-540-11(1)

DRC-BT60

Operating Instructions GB

WARNING

To reduce the risk of electrical shock, do

not open the cabinet. Refer servicing to

qualified personnel only.

The Bluetooth word mark and logos are

owned by the Bluetooth SIG, Inc. and any

use of such marks by Sony Corporation is

under licence.

Windows and Windows Vista are registered

trademarks or trademarks of Microsoft

Corporation in the United States and/or

other countries.

Macintosh and Mac OS are trademarks of

Apple Inc., registered in the U.S. and other

countries.

Other trademarks and trade names are those

of their respective owners.

Table Of Contents

What is Bluetooth wireless

technology? .........................4

Welcome!..................................5

3 steps to Bluetooth function...........6

GETTING STARTED

Location and Function of

Parts......................................7

About the HOME menu ...........9

Charging the unit ................. 11

Pairing ................................... 13

What is pairing? ..............................13

Procedures of pairing .....................13

Wearing the unit................... 15

Indications of Bluetooth

function............................. 16

OPERATING THE UNIT

Listening to music ................ 17

Controlling the audio device –

AVRCP........................................19

Calling.................................... 20

Controlling the Bluetooth mobile

phone – HFP, HSP ....................23

Calling while playing back

music ................................. 24

Listening to FM radio ........... 25

Selecting broadcast stations...........26

Presetting broadcast stations.........27

Calling while receiving an FM

broadcast .......................... 28

ADDITIONAL INFORMATION

Settings ................................. 29

Managing the paired Bluetooth

device ................................ 31

Precautions ........................... 33

Troubleshooting................... 35

Common ..........................................35

When charging................................36

When listening to music ................36

When calling....................................37

When listening to FM radio ..........37

Messages............................... 38

Listening to FM radio more

clearly ................................ 39

Specifications........................ 40

General .............................................40

Wireless Audio Receiver................41

System requirements for battery

charge using USB.......................41

What is Bluetooth wireless technology?

Bluetooth®wireless technology is a

short-range wireless technology that

enables wireless data communication

between digital devices, such as a

computer or digital camera. Bluetooth

wireless technology operates within a

range of about 10 metres.

Connecting two devices as necessary is

common, but some devices can be

connected to multiple devices at the

same time.

You do not need to use a cable for

connection, nor is it necessary for the

devices to face one another, such is the

case with infrared technology. For

example, you can use such a device in

a bag or pocket.

Bluetooth standard is an international

standard supported by thousands of

companies all over the world, and

employed by various companies

worldwide.

Communication System and

Compatible Bluetooth Profiles

of the unit

Profile is standardization of the

function for each Bluetooth device

specification. The unit supports the

following Bluetooth version and

profiles:

Communication System:

Bluetooth Specification version 2.1 + EDR*1

Compatible Bluetooth Profiles:

– A2DP (Advanced Audio Distribution

Profile): Transmitting or receiving audio

content of high-quality.

– AVRCP (Audio Video Remote Control

Profile): Controlling A/V equipment;

pausing, stopping, or starting playback,

etc.

– HSP (Headset Profile)*2: Talking on the

phone/Operating the phone.

– HFP (Hands-free Profile)*2: Talking on

the phone/Operating the phone by

hands-free.

*1Enhanced Data Rate

*2When you use a Bluetooth mobile phone

supported by both HFP and HSP, set to

HFP.

Notes

To be able to use the Bluetooth function,

the Bluetooth device to be connected

requires the same profile as the unit’s.

Note also that even if the same profile

exists, devices may vary in function

depending on their specifications.

Due to the characteristic of Bluetooth

wireless technology, the sound played on

the unit is slightly delayed from the sound

played on the Bluetooth device during

talking on the telephone or listening to the

music.

Welcome!

Thank you for purchasing this Sony Wireless Audio Receiver. The unit uses

Bluetooth wireless technology.

Enjoy music wirelessly from Bluetooth Stereo-enabled music players and

mobile phones.*1

Connect your favourite headphones via stereo mini jack (high quality

headphones are supplied).

Embedded microphone enables hands-free conversation from Bluetooth-

enabled mobile phone.*2

Enjoy basic remote control operation (play, stop, etc.) of music player functions

via Bluetooth connection.*3

Bluetooth version 2.1 + EDR*4for higher quality audio with less interference,

lower power consumption and easy connection.

Enjoy listening to FM radio using the unit itself.

USB rechargeable function.

Noise suppression and echo cancellation functions for superior conversation

sound quality.

Clip included for attaching the unit to a pocket of your clothing.

For details on Bluetooth wireless technology, see page 4.

Talking on the phone Listening to music

*1The connected Bluetooth device is required to support A2DP.

*2The connected Bluetooth device is required to support HFP or HSP.

*3The connected Bluetooth device is required to support AVRCP.

*4Enhanced Data Rate



Calling



Listening to music

3 steps to Bluetooth function

Pairing

First, register (“pair”) a Bluetooth device (mobile phone, etc.) and the unit with

each other. Once pairing is established, there is no need for pairing again.

Bluetooth

mobile phone,

etc.

Pairing

Wireless

Audio Receiver

Page 13-14

Bluetooth connection

Operate the Bluetooth device to

make the Bluetooth connection.

Connection

A2DP AVRCP

Page 17

Bluetooth connection

When the unit is turned on, the

unit starts making the Bluetooth

connection to the recognised

mobile phone automatically.

Connection

HFP HSP

Page 20-21

Listening to music

You can listen to music played on

the Bluetooth device.

Playback, stop, or pause is

possible from the unit.

Music

Page 17-19

Talking on the phone

You can make and receive a call

by operating the unit.

Voice

Page 21-23

GETTING STARTED

Location and Function of Parts

Unit

(headphones) jack

POWER button

VOL (volume)+*/− button

BACK/HOME button

Indicator (blue) (red)

Indicates the Bluetooth

communication status (blue) or

charging status (red) of the unit.

Display

See page 8.

/, TUNE+/− button

Skips to the next/previous song,

or selects items or frequency/

broadcast station.

(multi function) button

Controls various call functions.

RESET button

(play/pause/confirm)

button*

FM (FM radio) button

USB connector

Clip

Microphone

* This button has a tactile dot for ease of use.

Display

HOME menu

The next menu of HOME menu

Function icon

Displays the selected icon

inverted.

Icon function name

Displays the function name of the

selected icon.

Bluetooth connection status

: appears during Bluetooth

connection to the unit with

A2DP.

: appears during Bluetooth

connection to the unit with

HSP/HFP.

Remaining battery

Mode icon

Present menu

Selected item

Icons for shifting items

Appears when there are items on

the left and right of the screen.

Press the /button to

select the desired item.

About the HOME menu

You can display the HOME menu by pressing and holding the BACK /HOME

button of the unit for about 2 seconds. The HOME menu is the starting point to

pair, play audio, and change settings.

HOME menu

Bluetooth Displays the Bluetooth function menu.

FM Plays the FM radio.

Music Plays songs in the Bluetooth device.

Phone Call Displays the phone call function menu.

Settings Displays the settings menu of Bluetooth, FM, or the unit.

About operation of the HOME menu

When menu items appear on the HOME menu, press the /button to

select an item, and then press the button to confirm.

You can return to the previous menu by pressing the BACK/HOME button, and

you can always return to the HOME menu by pressing and holding it for about 2

seconds. The following illustration shows an example for setting the display

brightness on (Settings) of the HOME menu.

Select (Settings), and then

press the button to confirm.

Select “Brightness,” and then

press the button to confirm.

Select a brightness level, and then

press the button to confirm.

Press the BACK/HOME button.

Press and hold the BACK/HOME button for about 2 seconds.

HOME Menu List

(Bluetooth)*1

Pairing

Device List

Connected Device List

Phone Connect

Phone Disconnect

Music Connect

Music Disconnect

Delete

Unit Info

Device Address

Profile

(FM)

(Music)

(Phone Call)

Received Call

Redial

Voice Dial

(Settings)*2

Bluetooth

Sound Quality

High Quality

Standard

Video Mode

Off

Remote Command

Mode 1

Mode 2

Unit Info

Device Name

Device Address

Profile

FM Tuner

Dx/Local/Mono

Local

Mono

Scan Sens

High

Low

Brightness

Level 1

Level 2

Level 3

Level 4

Level 5

Initialize

*1If no device is registered, “Pairing” is

displayed as the function name of the

icon, and “Device List” is not displayed.

*2The default setting is underlined.

Table des matières

Autres manuels Sony Récepteur

Sony

Sony SAT-A1 - Digital Satellite System Guide de l'utilisateur

Sony

Sony ICF-7600DA Manuel utilisateur

Sony

Sony STR-DA3200ES - Es Receiver Manuel utilisateur

Sony

Sony MVA-20 Manuel utilisateur

Sony

Sony STR-DA5300ES - Multi Channel Av Receiver Manuel utilisateur

Sony

Sony STR-DN1040 Guide Manuel utilisateur

Sony

Sony STR-DE325 User Manual Addendum Guide de l'utilisateur

Sony

Sony STR-DH810 - Audio Video Receiver Manuel utilisateur

Sony

Sony STR-DG600 - Multi Channel Av Receiver Manuel utilisateur

Sony

Sony ICF-SW100E Manuel utilisateur

Sony

Sony ICF-SW1000TS Manuel utilisateur

Sony

Sony HCD-DZ100 - Super Audio Cd/dvd Receiver Manuel utilisateur

Sony

Sony HCD-FR1 - Dvd Home Theater System Manuel utilisateur

Sony

Sony HCD-DZ530 Manuel utilisateur

Sony

Sony STR-DA4ES - Fm Stereo/fm-am Receiver Manuel utilisateur

Sony

Sony SAT-HD200 - Directv High Definition Satellite... Guide de l'utilisateur

Sony

Sony HCD-DZ230 Manuel utilisateur

Sony

Sony MRD-D1 Manuel utilisateur

Sony

Sony STR-DA4400ES Manuel utilisateur

Sony

Sony MEX-DV1000 - Cd/dvd Receiver, Mp3/wma Player Manuel utilisateur

Sony

Sony HCD-FL7D - System Components Manuel utilisateur

Sony

Sony HWS-AV10K Manuel utilisateur

Sony

Sony R-DG1200 Manuel utilisateur

Sony

Sony ICF ICF-SW11 Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
