Sony NWZ-E343 - Network Walkman Manuel utilisateur

ModelName: NWZ-E343/E344/E345 (GB)

PartNumber: 4-154-414-11(1)

Click! You can directly jump

Operation Guide

NWZ-E343/E344/E345

 Troubleshooting

 Transferring Videos/Photos

 Transferring Music

Table of

Contents

Index

Home

ModelName: NWZ-E343/E344/E345 (GB)

PartNumber: 4-154-414-11(1)

Note

Depending on the country/region in which you have purchased the player, some models

may not be available.

Browsing the Operation Guide

To use the buttons in the Operation Guide

Click the buttons located in the upper right of the pages of this manual to jump

to “Table of Contents,” “About the Home Menu” or “Index.”

Hint

You can jump to the indicated page by clicking a page number in the table of contents or

in the index.

Y

ou can jump to the indicated page by clicking a page reference indication (e.g., p. 5)

on each page.

To search for a reference page by keyword, enter the keyword into the find text field on

the Adobe Reader window.

Operation procedures may differ, depending on your Adobe Reader version.

To change the page layout

The buttons on the Adobe Reader window enable you to select how pages are

displayed.

Continuous

Pages are displayed as a continuous

roll of pages, fitting the page width

inside the window. When you scroll,

the previous or next pages scroll up

or down continuously.

Single Page

Pages are displayed one at a time,

fitting the page into the window.

When you scroll, the display changes

to the previous or next page.

Jumps to the table of contents

Find what you are looking for from a list of topics in the manual.

Jumps to the [Home] menu list

Find what you are looking for from a list of the option items in the player’s menu.

Jumps to the index

Find what you are looking for from a list of key words mentioned in the manual.

Text field to find text

Table of

Contents

Home

Index

ModelName: NWZ-E343/E344/E345 (GB)

PartNumber: 4-154-414-11(1)

Table of Contents

Basic Operations and Screens

Parts and Controls...................................5

Turning the Player On and Off ...............7

About the Home Menu............................8

How to Use the Home Menu .................11

How to Use the Option Menu................14

About the Software................................16

Bundled Software...........................................16

Compatible Software .....................................16

Preparing the Player

Charging the Battery.............................17

Selecting the Display Language ............19

Setting the Date and Time.....................20

Transferring Music

Selecting the Way to Transfer Music.....21



Transferring Music Using Windows

Media Player 11..............................................22

Importing music from CDs ..........................22

Transferring Music ........................................24

Transferring Music Using Content

Transfer ...............................................26

Transferring Music Using Windows

Explorer...............................................28

Transferring Videos/Photos

Selecting the Way to Transfer

Videos/Photos .....................................30



Transferring Videos/Photos Using

Content Transfer............................................31



Transferring Videos/Photos Using

Windows Explorer ............................................33

Playing Music

Playing Music [Music] .............................35

Music playback screen...................................36

Music list screen.............................................37

Searching for Songs...............................38

Playing a playlist.............................................39

Playing All Songs in Random Order.....40

Deleting Songs.......................................41

Using the Music Option Menu..............42

Displaying the detailed information screen

[Detailed Information] .......................................44

Displaying the cover art screen

[Cover Art].......................................................44

Changing the Music Settings.................45

Setting the play mode [Play Mode]..................45

Setting the sound quality [Equalizer]..............46

Listening with Clear Stereo [Clear Stereo] ......47

Adjusting the volume level

[Dynamic Normalizer].......................................48

Watching Videos

Playing a Video [Videos]..........................49

Video playback screen...................................50

Deleting Videos .....................................51

Using the Video Option Menu ..............52

Changing the Video Settings.................53

Setting the zoom function

[Zoom Settings] ................................................53

Setting the display of the video screen

[Display] ..........................................................55

Setting the video orientation

[Video Orientation] ...........................................56

Continued 

Table of

Contents

Home

Index

ModelName: NWZ-E343/E344/E345 (GB)

PartNumber: 4-154-414-11(1)

Viewing Photos

Viewing Photos [Photos] .........................57

Photo display screen......................................58

Playing a Slide Show..............................59

Deleting Photos .....................................60

Using the Photo Option Menu ..............61

Changing the Photo Settings.................62

Photo orientation [Photo Orientation]..............62

Setting the display of the photo screen

[Display] ..........................................................63

Setting the slide show play mode

[Slide Show Repeat] ...........................................63

Setting the interval of a slide show

[Slide Show Interval]..........................................64

Listening to FM Radio

Listening to FM Radio...........................65

FM Radio screen ............................................66

Presetting broadcast stations

automatically [Auto Preset]............................67

Presetting broadcast stations manually.......68

Deleting preset broadcast stations...............68

Using the FM Radio Option Menu........69

Changing the FM Radio Settings ..........70

Setting the reception [Scan Sensitivity] ............70

Setting monaural/stereo [Mono/Auto]............70

Using the Timer

Setting the Timer...................................71

Setting the alarm [Alarm]................................72

Setting the sleep timer [Sleep Timer]...............73

Common Settings

Changing the Common Settings...........74

Displaying the player information

[Unit Information].............................................74

Limiting the volume [AVLS (Volume Limit)] ....75

Turning off the beep sound [Beep Settings]....75

Setting a screensaver type [Screensaver] .........76

Adjusting the brightness of the screen

[Brightness] ......................................................76

Setting the current time [Set Date-Time].........77

Setting the date format

[Date Display Format]........................................78

Setting the time format

[Time Display Format] .......................................78

Returning to the factory settings

[Reset all Settings] .............................................79

Formatting memory [Format].........................79

Selecting the Display Language

[Language Settings] ...................................80

Useful Facts

About Battery Life.................................81

What are Format and Bit Rate?.............82

What is audio format? ...................................82

What is video format? ...................................83

What is photo format?...................................83

Storing Data...........................................84

Upgrading the Player’s Firmware .........85

Troubleshooting

Troubleshooting ....................................86

Messages ................................................97

Additional Information

Precautions............................................99

License and Trademark Notice ...........108

Specifications.......................................110

Index ....................................................117

Table of

Contents

Home

Index

ModelName: NWZ-E343/E344/E345 (GB)

PartNumber: 4-154-414-11(1)

Basic Operations and Screens

Parts and Controls

BACK/HOME button

Press to go up one list screen level, or

to return to the previous menu.

Press and hold the BACK/HOME

button to display the [Home] menu

(p. 8).

5-way button*1

Starts playback and enables

navigation of the player’s on-screen

menus (p. 11, 14).

Display

See p. 8.

VOL +*1/− button

Adjusts the volume.

HOLD switch

You can protect the player against

accidental operation during

transportation by setting the HOLD

switch. By sliding the HOLD switch

in the direction of the arrow ,

all operation buttons are disabled. If

you slide the HOLD switch in the

opposite position, the HOLD

function is released.

OPTION/PWR OFF button

Press to display the option menu (

p. 14, 42, 52, 61, 69).

If you press and hold the OPTION/

PWR OFF button, the screen turns

off and the player enters standby

mode (p. 7).

*1There are tactile dots. Use them to help with

button operations.

Continued 

Basic Operations and Screens

Front

Table of

Contents

Home

Index

ModelName: NWZ-E343/E344/E345 (GB)

PartNumber: 4-154-414-11(1)

Basic Operations and Screens

RESET button

Press the RESET button with a small

pin, etc., to reset the player (

p. 86).

Strap hole

This is used to attach a strap (sold

separately).

USB connector

Connect the supplied USB cable.

Headphone jack

Insert the headphone plug until it

clicks into place. If the headphones

are connected improperly, the sound

from the headphones will be

impaired.

Rear

Table of

Contents

Home

Index

ModelName: NWZ-E343/E344/E345 (GB)

PartNumber: 4-154-414-11(1)

Basic Operations and Screens

Turning the Player On and Off

To turn on the player

Press any button to turn the player on.

Hint

If [On hold... Cancel HOLD function to activate controls.] appears on the screen, slide

the HOLD switch on the right of the player in the opposite direction of the arrow 

to release the HOLD function.

To turn off the player

Press and hold the OPTION/PWR OFF button. [POWER OFF] appears, then

the player enters standby mode, and the screen turns off.

Hint

Set the date and time on the player before using it (p. 20, 77).

During pause, if there is no operation for more than 3 minutes, the player automatically

enters standby mode to save battery power, and the screen turns off.

While the player is in standby mode, if there is no operation for about 4 hours, the player

completely turns off automatically. The batteries are consumed a little in this status.

Note

You cannot operate the player when it is connected to a computer. Disconnect the USB

cable before operating the player.

The player consumes battery power very slightly even when it is in standby mode.

Therefore, the player might turn completely off unexpectedly depending on the power

remaining in the battery.

OPTION/PWR OFF

button

Table of

Contents

Home

Index

ModelName: NWZ-E343/E344/E345 (GB)

PartNumber: 4-154-414-11(1)

Basic Operations and Screens

About the Home Menu

The following table shows the items of the [Home] menu. For details on the

item list of each menu, see p. 9.

For details about each menu item, refer to the specified reference page.

[Shuffle All] Listen to all the songs stored on the player in random

order (p. 40).

[FM Radio] Listen to FM radio broadcasting (p. 65).

[Clock Display] Display the current time (p. 20, 77).

[Photos] View photos transferred to the player (p. 57).

[Music] Listen to songs transferred to the player. (p. 35).

[Videos] Watch videos transferred to the player (p. 49).

[Settings] Set up the player and its applications (p. 74).

[Playlists] Listen to songs in the playlists (p. 39).

[Now Playing] Display the playback or display screen of the currently

playing content.

Continued 

[FM Radio]

[Shuffle All]

[Photos]

[Music]

[Settings]

[Clock Display]

[Videos]

[Now Playing]

[Playlists]

Information area

Table of

Contents

Home

Index

ModelName: NWZ-E343/E344/E345 (GB)

PartNumber: 4-154-414-11(1)

Basic Operations and Screens

[Shuffle All] ............................. 40

[FM Radio] ............................... 65

[Clock Display].................... 20, 77

[Photos] ................................. 57

[Music]

[All Songs]...................................38

[Album].......................................38

[Artist].........................................38

[Genre] ........................................38

[Release Year] .............................38

[Folder]........................................38

[Videos].................................. 49

[Settings]

[Music Settings]

[Play Mode] ........................... 45

[Equalizer].............................. 46

[Clear Stereo]......................... 47

[Dynamic Normalizer]......... 48

[Video Settings]

[Zoom Settings]..................... 53

[Video Orientation].............. 56

[Display]................................. 55

[Photo Settings]

[Photo Orientation].............. 62

[Display]................................. 63

[Slide Show Repeat] .............. 63

[Slide Show Interval] ............ 64

[FM Radio Settings]

[Scan Sensitivity]................... 70

[Mono/Auto] ......................... 70

[Common Settings]

[Unit Information]................ 74

[AVLS (Volume Limit)]........ 75

[Beep Settings]....................... 75

[Screensaver] ......................... 76

[Brightness]............................ 76

[Set Date-Time]...............20, 77

[Date Display Format].......... 78

[Time Display Format]......... 78

[Reset all Settings]................. 79

[Format] ................................. 79

[Language Settings] .............19, 80

[Playlists]................................. 39

[Now Playing]

Continued 

Table of

Contents

Home

Index

ModelName: NWZ-E343/E344/E345 (GB)

PartNumber: 4-154-414-11(1)

Basic Operations and Screens

About the information area

The icons, shown in the table below, appear in the information area. The icons

vary according to the playback status, setting or the screen.

For details about the icons, see each reference page.

Icons Description

, , , ,

, ,

, , etc

Playback status (p. 36, 50, 58)

, , , Song name, artist name, video title, or photo title

FM radio

, , etc Play mode (p. 45)

, etc Equalizer (p. 46)

, Zoom setting ([Auto] or [Full]) (p. 53)

Sleep timer (p. 73)

Remaining battery power (p. 17)

Table of

Contents

Home

Index

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sony Lecteur MP3

Sony

Sony NWZ-E436FRED Manuel utilisateur

Sony

Sony ZAPPIN NWZ-W202 Manuel utilisateur

Sony

Sony NW-S205F - Network Walkman Manuel utilisateur

Sony

Sony WALKMAN NW-WM1A Manuel utilisateur

Sony

Sony NWZ-W252BLK - Digital Music Player Guide de démarrage rapide

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Sony

Sony NW-MS90D - Network Walkman Manuel utilisateur

Sony

Sony NW-E307 - Walkman Bean 1 GB MP3 Player Manuel utilisateur

Sony

Sony NW-A55 Manuel utilisateur

Sony

Sony NW-E95 - Network Walkman Instructions de montage

Sony

Sony SEP-30BTBLK - Rolly™ Sound Entertainment... Manuel utilisateur

Sony

Sony MP3 Walkman Manuel utilisateur

Sony

Sony Walkman NWZ-E443 Manuel utilisateur

Sony

Sony NW-E002BLUE - Network Walkman Manuel utilisateur

Sony

Sony NW-MS9 SonicStage v2.0 Manuel utilisateur

Sony

Sony NW-MS70D - Network Walkman Manuel utilisateur

Sony

Sony Walkman NWZ-W273 Manuel utilisateur

Sony

Sony NWZ-W252 Marketing Specifications (Black) Manuel utilisateur

Sony

Sony Walkman NWZ-A815PNK Manuel utilisateur

Sony

Sony Walkman NWZ-S764 Manuel utilisateur

Sony

Sony Walkman NW-WS623 Manuel utilisateur

Sony

Sony NWZ-E344BLK Manuel utilisateur

Sony

Sony Walkman NWZ-E464 Manuel utilisateur

Sony

Sony NW-A55 Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur

Kenwood

Kenwood M1GD50 Manuel utilisateur
