VAIO®C1 PictureBook™

Computer Adding Memory

PCG-C1X

In the future you may want to install memory modules to expand the

functionality of your computer. You can increase memory to 128 MB by

installing optional memory modules. 64 MB of memory are already

installed on your computer. You can add another memory module in a

slot. 32 and 64 MB expansion memory modules are available as optional

memory modules.

❑The procedures described below assume familiarity with the general

terminology associated with personal computers and with the safety

practices and regulatory compliance required for using and

modifying electronic equipment.

❑Disconnect the system from its power source and from any

telecommunications links, networks, or modems before you open the

system or follow any of the procedures described below. Failure to do

so may result in personal injury or equipment damage.

❑Electrostatic discharge (ESD) can damage disk drives and other

components. Perform the procedures described below only at anESD

workstation. If such a station is not available, do not work in a

carpeted area, and do not handle materials that produce or hold static

electricity (cellophane wrappers, for example). Ground yourself by

maintaining contact with an unpainted metal portion of the chassis

while performing the procedure.

❑Do not open the memory module package until you are ready to

install the module. The package protects the module from ESD.

❑Use the special bag for preventing ESD or use aluminum foil when

you store the memory module.

!Make sure you observe the proper safety precautions when you install memory modules in

your computer. See the bulletedlist below. Be careful when adding memory. Mistakes when

installing or removing a memory module may cause a malfunction.

VAIO® C1 PictureBook™ Computer Adding Memory2

Typical expansion memory configuration

* 64 MB is the default memory amount.

To install a memory module

1Turn off your computer and remove all the cables connected to it. You

must also remove the battery.

2When the computer has cooled completely, turn it upside down.

Gently insert a wire or other pointed object into the hole next to the

lid of the memory module compartment. Slide the lid off in the

direction of the arrow.

3Discharge static electricity by touching a grounded metal object.

Total System Memory

(MB) On-board (MB) Slot (MB)

64* 64 Empty

96 64 32

128 64 64

!The computer remains hot after it has been turned off. To avoid burns to fingers or hands,

let the computer cool completely before detaching the memory module lid.

To install a memory module 3

4If the compartment contains a memory module, remove it. Lift the

memory module by its edges to remove it from the computer.

5Unpack the new memory module. Discharge static electricity by

touching a grounded metal object. Remove the new memory module

from its package.

6Install the memory module by matching the connector on the

memory module unit to the connector on the computer.

Lift by the edges

Align the module

Memory module

with the white

guideline

VAIO® C1 PictureBook™ Computer Adding Memory4

7Gently press the white stripe of the memory module tightly into

place.

8Close the memory module compartment lid by sliding it back into

place until it clicks.

9Turn on the computer.

10 Right-click the My Computer icon and select Properties. The System

Properties screen appears.

11 Click the Performance tab to view memory. If the additional memory

is not shown, repeat steps 1-11.

rights reserved. Sony and VAIO are trademarks of Sony. All other trademarks are trademarks or registered

trademarks of their respective owners.
