Sony PCG-SRX51P/B Manuel utilisateur
Specifications
Specifications
1
nN
Specifications
Model name PCG-SRX51P/B
Model number PCG-463M
Operating system Microsoft®Windows®XP Professional
Processor Low Voltage Mobile Intel®Pentium®III processor 850 MHz-M
Hard disk drive 30 GB hard disk drive
Standard RAM 256 MB SDRAM (128 MB on board, 128 MB in slot)
Maximum RAM 384 MB
LCD screen 10.4'' XGA (1024x768) p-Si TFT screen
L2 cache memory 512 KB (on die)
Graphics Intel®815EM Chipset with integrated graphics accelerator
Video RAM: max. 11 MB (shared with main memory) with 3D accelerator
DVM (Dynamic Video Memory)
Sound capabilities 16-bit CD-quality stereo sound
Internal modem Built-in V.90/K56Flex (56kbps) data/fax modem
Specifications
Specifications
2
nN
CD-ROM drive
DVD-ROM drive
CD-RW drive
External i.LINK™ CD-RW/DVD-ROM drive:
up to 24x max. CD-ROM reading speed
up to 8x max. CD-R writing speed
up to 4x max. CD-RW writing speed
up to 8x max. DVD-ROM reading speed
Laser diode properties:
Wave length: DVD 660 nm / CD 785 nm
Laser output: 468 µW
Telecommunication capabilities Ethernet network, PSTN data connectivity, Wireless LAN, Bluetooth™ functionality
Expansion capabilities 1 x PC Card type I or 1 x PC Card type II and CardBus support
Built-in capabilities Stereo speakers, touchpad, Jog Dial™ with back button, MagicGate Memory Stick™ slot
Special buttons Jog Dial™, Wireless switch
Connection capabilities on notebook External speakers/headphone (with MEGA BASS), external microphone, USB port, 1 x PC Card
type I or 1 x PC Card type II, i.LINK™ (IEEE1394) S400, Ethernet (10 BASE-T/100 BASE-TX),
phone line, monitor connector (on display adapter), MagicGate Memory Stick™ slot
Supplied accessories Rechargeable battery, AC adapter, AC power cord, phone cable,
phone plug, display adapter, i.LINK™ CD-RW/DVD-ROM drive
Power source 16V DC/ AC100 - 240V
Model name PCG-SRX51P/B
Model number PCG-463M
Specifications
Specifications
3
nN
Power management ENERGY STAR®compliant
ACPI (Advanced Configuration & Power Interface)
Battery 6 cells lithium ion
Dimensions
Width
Height
Depth
259.0 mm
27.8 mm to 32.0 mm
194.0 mm
Weight
With battery 1.26 kg
Operating temperature +5°C to +35°C (temperature gradient less than 10°C/hour)
Storage temperature -20°C to +60°C (temperature gradient less than 10°C/hour)
Operating humidity 20% to 80% (not condensed), provided that humidity is less than 65%
at +35°C (hygrometer reading of less than +29°C)
Storage humidity 10% to 90% (not condensed), provided that humidity is less than 20%
at +60°C (hygrometer reading of less than +35°C)
Wireless communication:
Method of communication:
Bluetooth™
Bluetooth™ standard version 1.1
Maximum communication speed (1) Max. 723 kbps
Model name PCG-SRX51P/B
Model number PCG-463M
Specifications
Specifications
4
nN
Output Bluetooth™ standard Power Class 1
Communication distance (2) Approx. 10 –100 m (open space)
Compatible Bluetooth™ profiles (3) Generic Access Profile
Service Discovery Application Profile
Serial Port Profile
Dial-up Networking Profile
Fax Profile
Object Push Profile
Generic Object Exchange Profile
LAN Access Profile
Usable frequency band 2.4 GHz band (2.400 GHz - 2.4835 GHz)
Bluetooth™ software BlueSpace
Wireless communication:
Method of communication:
Wireless LAN
IEEE802.11b standard (IBSS Ad hoc mode support)
Usable frequency band 2.4 GHz band (2.400 GHz - 2.474 GHz)
Maximum communication speed (4) Max. 11 Mbps
Communication distance (5) Approx. 10-100 m (open space)
Wireless channels From 1 to 11
Model name PCG-SRX51P/B
Model number PCG-463M
Specifications
Specifications
5
nN
Specifications are subject to change without notice.
(1) The maximum communication speed of the Bluetooth™ standard version 1.1 can vary depending on the obstacles or the distance between the
communication devices, the radio waves, the operating system or the software you use.
(2) Communication distance can vary depending on the obstacles between the communication devices, the radio waves, the operating system or the
software you use.
(3) These profiles show what you can do with devices compatible with the Bluetooth™ functionality.
(4) The maximum communication speed of the IEEE802.11b standard can vary depending on the obstacles or the distance between the
communication devices, the radio waves, the operating system or the software you use.
(5) Communication distance can vary depending on the obstacles between the communication devices, the radio waves, the operating system, the
software you use or the surroundings (walls, etc.).
(6) You can type maximum 5 letters (40 bit) and 13 letters (104 bit).
Modulation method DS-SS (IEEE802.11b standard)
Length of network key (6) 64, 128 bit
Model name PCG-SRX51P/B
Model number PCG-463M
