Sony DR-BT30Q - Wireless Stereo Headset Manuel utilisateur

Wireless Stereo

Headset

2-696-114-51(1)

DR-BT30Q

Operating Instructions

Mode d’emploi

WARNING

To reduce the risk of fire or electric

shock, do not expose this

apparatus to rain or moisture.

To reduce the risk of electrical

shock, do not open the cabinet.

Refer servicing to qualified

personnel only.

Do not install the appliance in a

confined space, such as a bookcase or

built-in cabinet.

To reduce the risk of fire, do not cover the

ventilation of the apparatus with

newspapers, tablecloths, curtains, etc.

And do not place lighted candles on the

apparatus.

To reduce the risk of fire or electric

shock, do not place objects filled with

liquids, such as vases, on the apparatus.

Connect the AC power adaptor to an

easily accessible AC outlet. Should you

notice an abnormality in the AC power

adaptor, disconnect it from the AC outlet

immediately.

Information

This device complies with Part 15 of FCC

Rules and RSS-Gen of IC Rules.

Operation is subject to the following two

conditions: (1) this device may not cause

interference, and (2) this device must

accept any interference, including

interference that may cause undesired

operation of this device.

You are cautioned that any changes or

modifications not expressly approved in

this manual could void your authority to

operate this equipment.

This equipment must not be co-located or

operated in conjunction with any other

antenna or transmitter.

This equipment complies with FCC/IC

radiation exposure limits set forth for

uncontrolled equipment and meets the

FCC radio frequency (RF) Exposure

Guidelines in Supplement C to OET65

and RSS-102 of the IC radio frequency

(RF) Exposure rules. This equipment has

very low levels of RF energy that it is

deemed to comply without testing of

specific absorption ratio (SAR).

The Bluetooth word mark and logos are

owned by the Bluetooth SIG, Inc. and any

use of such marks by Sony Corporation is

under license.

Other trademarks and trade names are

those of their respective owners.

MPEG Layer-3 audio coding technology

and patents licensed from Fraunhofer IIS

and Thomson.

Table Of Contents

Welcome! .......................... 4

3 steps to BLUETOOTH

function ................................. 5

Location and Function of

Parts............................... 6

Charging the unit ............. 7

Pairing ............................... 9

What is pairing? ........................ 9

Procedures of pairing ................ 9

Wearing the headset ...... 11

Indications of

BLUETOOTH function 12

Listening to music ......... 13

Controlling the audio

device – AVRCP ................. 14

Calling ............................. 16

Controlling the BLUETOOTH

mobile phone – HFP, HSP .. 18

Calling while playing

back music .................. 19

Disposing of the unit ..... 20

Precautions .................... 21

What is BLUETOOTH

technology? ................ 23

Troubleshooting ............. 24

Initializing the unit ......... 25

Specifications ................. 26

For the customers in Canada

RECYCLING LITHIUM-ION

BATTERIES

Lithium-Ion

batteries are

recyclable.

You can help

preserve our

environment by

returning your used

rechargeable

batteries to the

collection and

recycling location

nearest you.

For more information regarding

recycling of rechargeable

batteries, call toll free 1-800-822-

8837, or visit

http://www.rbrc.org/

Caution: Do not handle damaged

or leaking Lithium-Ion batteries.

Welcome!

Thank you for purchasing this Sony Wireless Stereo Headset. This unit uses

BLUETOOTH™wireless technology.

•You can enjoy music from your BLUETOOTH device capable of

transmitting music.

• You can enjoy hands-free talking with your BLUETOOTH mobile phone

inside your bag.

•You can remotely control the basic functions of BLUETOOTH audio

device (Play, Pause, Stop, etc.).

•You can charge the unit using the supplied AC power adaptor.

• By simply pressing the button, the cord of the unit is retracted for storage.

For details on BLUETOOTH technology, see page 23.

Listening to music

Talking on the phone

Calling

Listening to music

3 steps to BLUETOOTH function

BLUETOOTH

mobile phone,

etc. Pairing

Wireless Stereo

Headset

BLUETOOTH connection

Operate the BLUETOOTH

device to make the

BLUETOOTH connection.

Connection

Listening to music

You can listen to music played on

the BLUETOOTH device.

Playback, stop, or pause is

possible from this unit.

Music

BLUETOOTH connection

When the unit is turned on, the

unit starts making the

BLUETOOTH connection to the

recognized mobile phone

automatically.

Talking on the phone

You can make and receive a call

by operating this unit.

Pairing

First, register (“pair”) a BLUETOOTH device (mobile phone, etc.) and

this unit with each other. Once pairing is established, there is no need for

pairing again.

Voice

Connection

A2DP AVRCP

HFP HSP

cPage 9

cPage 13

cPage 16

cPage 17 - 19cPage 13 - 15

Location and Function of Parts

1Jog switch

Controls various functions

when listening to music.

2VOLUME – button

3VOLUME + button

4Indicator (blue)

Indicates the communication

status of the unit.

5Multi function button

Controls various call functions.

6Indicator (red)

Indicates the power status of

the unit.

7Microphone

8RESET button

9DC IN 3 V jack

q; POWER button

qa AUTO WIND button

Retracts the cord of the unit.

GETTING STARTED

1Connect the supplied

AC power adaptor to the

DC IN 3 V jack on the

unit.

When the AC power adaptor is

connected to an AC outlet,

charging starts.

Tip

If the AC power adaptor is connected

to an AC outlet while the unit is

turned on, the unit will be turned off

automatically.

Charging the unit

The unit contains a rechargeable Lithium-Ion battery, which should be

charged before using for the first time.

Wireless Stereo

Headset

To DC IN

3 V jack

To an AC

outlet

AC power

adaptor

(supplied)

2Make sure that indicator

(red) lights up while

charging.

Charging is completed in about

3 hours* and the indicator (red)

goes off automatically.

*Time required for empty battery to

recharge.

Caution

If this unit detects a problem while

charging, the indicator (red) may

turn off, although charging is not

complete.

Check for the following causes:

–Ambient temperature exceeds the

range of 0 °C – 40 °C (32 °F –

104 °F).

–There is a problem with the

battery.

In this case, charge again within the

above-mentioned temperature range.

If the problem persists, consult your

nearest Sony dealer.

Continued

Checking the remaining

battery

When pressing the POWER button

while the unit is turned on, the

indicator (red) flashes. You can

check the remaining battery by the

number of times the indicator (red)

flashes.

Indicator (red)

3 times

2 times

1 time

Note

You cannot check the remaining battery

immediately after the unit is turned on, or

while pairing.

When the battery is almost empty

The indicator (red) flashes slowly

automatically.

When the battery becomes empty, a

beep sounds and the unit will turn

off automatically.

Approx.

usage hours

11 hours

100 hours

Status

Full

Mid

Low (needs to

charge)

Notes

•If the battery is not used for a long time,

battery may be quickly depleted,

however, after a few recharges, battery

life will improve.

•If the life of the built-in rechargeable

battery drops to half the normal length,

the battery should be replaced. Consult

your nearest Sony dealer for

replacement of the rechargeable battery.

•Avoid exposure to temperature

extremes, direct sunlight, moisture,

sand, dust or mechanical shock. Never

leave in a car parked in the sun.

•Use only the supplied AC power

adaptor. Do not use any other AC

power adaptor.

Usage hours*

Status

Communication

time (including

music playback

time) (up to)

Standby time

(up to)

*Time stated above may vary, depending

on ambient temperature or conditions of

use.

Pairing

Continued

What is pairing?

BLUETOOTH devices need to be

“paired” with each other beforehand.

Once BLUETOOTH devices are

paired, there is no need for pairing

again, except in the following cases:

•Pairing information is deleted

after repair, etc.

• This unit is paired with 9 or more

devices.

This unit can be paired with up to

8 devices; if a new device is

paired after 8 devices have been

paired, the device whose latest

connection time is the oldest

among the 8 paired devices is

replaced by the new one.

•When recognition of the unit by

the device to be connected is

deleted.

•This unit is initialized.

All pairing information is deleted.

Procedures of pairing

1Place the connecting

device within 1 m (3 ft)

of this unit.

2Press and hold the

POWER button for

7 seconds or more to

standby for pairing

while the unit is turned

off.

Notes

•After about 3 seconds, power is

turned on and the indicator (blue)

and indicator (red) flash together

twice. Keep the button pressed

without releasing until both

indicators start flashing together,

then release the button. This unit

enters into pairing mode.

•If pairing is not established within

about 5 minutes, pairing mode will

be canceled and this unit will turn

off. In this case, start over from

step 1.

3Perform pairing

procedure on the

connecting device to

detect this unit.

The list of detected devices

appears on the display of the

connecting device. This unit is

displayed as “DR-BT30Q.”

If “DR-BT30Q” is not

displayed, repeat from step 1.

4Select “DR-BT30Q” on

the display of the

connecting device.

5If Passcode*input is

required on the display

of a connecting device,

input “0000.”

Pairing is complete when the

indicator (blue) flashes slowly.

The message standing for

“Pairing complete” appears on

the display of some

BLUETOOTH devices.

*Passcode may be called “Passkey,”

“PIN code,” “PIN number,” or

“Password.”

6Start the BLUETOOTH

connection from the

BLUETOOTH device.

This unit memorizes the device

as the latest connected device.

Some BLUETOOTH devices

may connect with the unit

automatically when pairing is

complete.

When pairing with a

BLUETOOTH device that

cannot display a list of

detected devices or that

has no display

You may pair the device by setting

both this unit and the connecting

device to pairing mode. For details,

refer to the operating instructions

supplied with the connecting device.

Tips

•To pair with other BLUETOOTH

devices, repeat steps 1to 5for each

device.

•To delete all pairing information, see

“Initializing the unit” (page 25).

Autres manuels pour DR-BT30Q - Wireless Stereo Headset

Table des matières

Langues :

Autres manuels Sony casque

Sony

Sony DR-BT22iK Manuel utilisateur

Sony

Sony DR-BT21G - Stereo Bluetooth Headset; Neckband... Manuel utilisateur

Sony

Sony MDR-ZX770BN Manuel utilisateur

Sony

Sony WI-XB400 Guide de référence

Sony

Sony WH-H900N Manuel utilisateur

Sony

Sony DR-EX14VP/VLT Manuel utilisateur

Sony

Sony WH-CH710N Manuel utilisateur

Sony

Sony DR-BT22 - Headset - Semi-open Manuel utilisateur

Sony

Sony MDR-1ABT Manuel utilisateur

Sony

Sony YY2977 Manuel utilisateur

Sony

Sony MDR-AS700BT Manuel utilisateur

Sony

Sony LinkBuds S YY2950 Manuel utilisateur

Sony

Sony WH-CH520 Manuel utilisateur

Sony

Sony DR BT160IK Mode d’emploi

Sony

Sony DR-BT10CX Manuel utilisateur

Sony

Sony 4-130-181-52(1) Manuel utilisateur

Sony

Sony MDR-ZX770BN Manuel utilisateur

Sony

Sony WH-1000XM4 Manuel utilisateur

Sony

Sony LinkBuds S YY2950 Manuel utilisateur

Sony

Sony DRBT140Q - Bluetooth Wireless Stereo Headset Manuel utilisateur

Sony

Sony DR-BT21G - Stereo Bluetooth Headset; Neckband... Manuel utilisateur

Sony

Sony CECHYA-0090 Manuel utilisateur

Sony

Sony WH-1000XM4/S Guide de référence

Sony

Sony DR-V150iP Manuel utilisateur

Manuels casque populaires d'autres marques

Sena

Sena SMH10 Manuel utilisateur

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuel utilisateur

Sennheiser

Sennheiser EPOS ADAPT 230 Manuel utilisateur

Doro

Doro Flexus HS2005 Manuel utilisateur

GE 98971 Manuel utilisateur

Hama

Hama 00184070 Manuel utilisateur

Plantronics

Plantronics Blackwire 3200 Series Manuel utilisateur

Blue Tiger

Blue Tiger Advantage PLUS Manuel utilisateur

Jawbone

Jawbone Icon Manuel utilisateur

Jabra

Jabra FR 20 Manuel utilisateur

Roxcore

Roxcore Flow A+ Manuel utilisateur

Turtle Beach

Turtle Beach XP 510 Manuel utilisateur

Philips

Philips SHB6101 Manuel utilisateur

Jabra

Jabra PRO 9460 Duo Manuel utilisateur

HyperX

HyperX HyperX Cloud Flight Manuel utilisateur

Bose

Bose MIE2 Mobile Manuel utilisateur

Jabra

Jabra Steel Manuel utilisateur

HyperX

HyperX cloud ii Manuel utilisateur
