Sony PS3 INFIMOD Instructions de montage

Repair your PSP with this Repair Guide

PS3 Repair Guide - Don't spend Big bucks to have it fixed!

Do you have a PS3 that needs repair?

This Repair Guide contains repairs for some

of the most common PS3 Problems:

●How to clean the Blu-Ray lens in your PS3

●Fix the Blinking Playstation 3 problem

●fix the PS3 Bluetooth controller issue

●Freezing games - and Movies

●No - Display

●Other common video issues

This Guide is for you!

www.sharatronica.com

Index
Index

Cover
Index
Legal Disclaimer
Disassembly
1. PS3 Disassembly
2. PS3 Controller Disassembly
Fix Common Problems
1. The Mystery of the Blinking PlayStation 3
2. The dirt on Blu-ray lens (and how to clean it)
3. PS3 Owners Report Blu-ray Problems After 1.5 Upgrade
4. PS3 Bluetooth Controller Issues
5. Playstation 3 HDMI Problem and Fix!
6. Display/Video Fixes
7. PS3 Error Codes (With Some Advice)
8. How to Change From HDMI > Composite Easier
9. PS3 3 Beep & Blinking Red Light Fix
PS3 Modifications
1. PS3 3.5" SATA HDD Mod
2. Adding IR Remote Control to the Sony PS3
3. PS3 HDD Replacement Mini-Guide
4. USB Flash Memory, USB Hard Drive (External Use)
Controller Modifications
1. PS3 Controller Light Mod
2. PS360: Microsoft Controller, Meet Sony Controller
3. PS3 Controller Light Mod 2
file:///C|/Documents%20and%20Settings/Bean/My%20Documents/My%20Webs/ps3rg/index.html (1 of 4) [11/12/2007 12:47:46 PM]
www.sharatronica.com

Index
PS3 Controller Button Contacts, Add extra buttons to the PS3 controller
Other Modifications
Charging Station Headset Mod
Blu-Ray
Decrypt Blu-Ray Movies with a PS3 WITHOUT keys
Blu-Ray Unique Volume Keys
Blu-Ray Media Links
Play BluRay movies without disk FULL INSTRUCTIONS
Convert HD-DVD To Blu-ray (works On PS3), No Loss Of Quality
Other Media/Video
Set up media servers for your PS3
Transfer files from PC to PS3 via WmP11/Nero (via DLNA/MediaServers)
How to stream AVI files on PS3 via Tversity
Copy music/videos from your iPod to PS3
Getting your PS3 to recognize your External Hard Drive
How to create a PS3 HD-MPG from HD-TS (Best Result For Below 1.6FW)
How to install your game saves
Downloading PS3 Game Saves
Audio
How to connect PS3 to PC speakers
Networking
How to change from 'NAT type 3' to 'NAT type 2'
Make a Lag Switch
Who Needs SIMPLE DNS
Remote Play On-The-Go
Playstation Network
PSN Game Sharing Instructions
file:///C|/Documents%20and%20Settings/Bean/My%20Documents/My%20Webs/ps3rg/index.html (2 of 4) [11/12/2007 12:47:46 PM]
www.sharatronica.com

Index
How to download Japanese Demos/Create Jap PSN account
Create Different Region PSN Accounts
View PS3 Store, Download Demos on your PC and install Demos To PS3
Play Online And Access Sony Store No Updating
View Playstation store on PC
Firmware Modifications
PS3 Firmware Version Check Bypassed (Linux)
PS3 Firmware Version Check Bypassed (Windows)
Ettercap Windows
PS3 Demonstration Mode "Unlock" Code
Use SIMPLEDNS To Bypass The Firmware Check (Windows)
How to UPDATE your PS3
Linux
How to install Fedora Core 6 Linux for PS3
PS3 Linux - The void has been filled...Full install instructions for Fedora Core 5
PS3 Linux FAQ
GUI Kboot
Yellow Dog Linux Free Version
Yellow Dog Linux 5.0 Installation
Partitioning and readying your PS3 for Linux
Gentoo
Uninstalling Linux
Installing YDL+VLC+Mplayer+Snes9x
Installing Mplayer on PS3
Installing VLC player on PS3
Installing "Other OS" on PS3
How to get Wi-Fi to work with YDL
Set up a Linux UPnP media server w/PS3 support
Run Ubuntu Linux 7.04 (Feisty Fawn) on PS3
Ubuntu, Kubuntu, Xubuntu, and Edubuntu onto a PlayStation 3
Emulate WinXP in PS3 under Linux
Downloads
Homebrew Loaders
www.sharatronica.com

Index
Linux
Utilities
Firmware Updates
"Other OS" Bootable Homebrew
Drivers
Proof-Of-Concept Exploits
Game Saves
PS2/PS1 on PS3
Do your PS2 games look too jaggy on the PS3? Here's a semi-fix...
PS3 SWAP to play PS2 and PSX Games!
How to play/install to play PS2 backups on PS3
Miscellaneous
PS3 Features
Finding RAM locations on resistance
PS3 Parental Controls How-to
20 ways to get the most out of your PS3
PS3 BiOS Flash Diagram Rev 1.0 BETA
Parts, Accessories, etc..
Previous/Next
www.sharatronica.com

Legal Disclaimer

Legal Disclaimer:

Opening your PS3 will void any remaining warranty you have left on your PS3

For more repair guides click here to see my other auctions.

www.sharatronica.com

Disassembly Index

PS3 Disassembly

PS3 Controller Disassembly

Previous/Next

www.sharatronica.com

PS3 Disassembly

Taking the PS3 apart is a long and involved process, so make sure you have at least a couple of hours

to do this if it’s the first time. Also make sure you have proper lighting and the right tools.

You will need:

●Torx screwdriver

●Phillips head screw driver

●Small flathead screw driver (for removing the rubber foot)

●Somewhere with plenty of space that is well lit and that wont build up static electricity. (Mainly

anywhere but carpet)

So, here we have a brand spanking new PS3…..all ready to be taken part…..

On the left side of the console you will see a few rubber feet. The first screw to be removed is

underneath the rubber foot circled in red in the pic below. The foot can be pried out with a small screw

driver. Then underneath is a Torx security screw. You will either need a Torx screwdriver, or a flat

head screwdriver that will fit in the screw.

www.sharatronica.com

PS3 Disassembly

www.sharatronica.com

PS3 Disassembly

Once the screw is removed, slide the top of the case to the left. It may require a bit of force to slide if

your opening the console for the first time. After the top slides as far as it will go, lift the top and it

should come off as seen in the pic below:

After the top is off, there will be another cover. You will need to remove the 7 long screws circled in

red.

www.sharatronica.com
