FLAT WIDE DISPLAY

FWD-50PX2

PROTOCOL MANUAL

1st Edition

FWD-50PX2

Table of Contents

1. Communication Parameter ................................................................ 1

2. Pin Configuration ..................................................................................... 1

3. Communication Data Format ........................................................... 1

4. General Function ..................................................................................... 3

5. Picture/Sound .......................................................................................... 12

6. Size/Shift .................................................................................................... 14

7. Status Enquiry ........................................................................................ 16

8. User Reset ................................................................................................. 19

FWD-50PX2

1. Communication Parameter

Communication system RS-232C

Synchronous system Asynchronous communication

Baud rate 9600 bps

Character length 8 bit

Parity None

Start bit 1 bit

Stop bit 1 bit

Flow control None

2. Pin Configuration

12345

Display side (D-sub 9-pin)

_External view _

6789

12345

6789

Host side (D-sub 9-pin)

_External view _

FWD-50PX2

Personal computer

Pin No. Signal

1NC

2TD

3RD

4NC

5 GND

6NC

7NC

8NC

9NC

Pin No. Signal

1NC

2RD

3TD

4NC

5 GND

6NC

7NC

8NC

9NC

3. Communication Data Format

(a) Control (Host →Request of Write to Display)

No. Item Value

1 Header 0x8C:Control

2 Category 0xXX

3 Function 0xXX

4 Data1 (Length) 0xXX

5 Data2 (Data1) 0xXX

: : 0xXX

X DataX 0xXX

X+1 Check Sum 0xXX

*Check Sum: The total from No. 1 to No. X, when value exceeds 255,1byte

of data is confirmed the bottom.

*Set the command interval to 500 ms or more when transmitting the

Control command continuously.

*Set the command interval to 500 ms or more when transmitting the same

command (Enquiry) after the Control command.

(b) Enquiry (Host →Request of Read to Display)

No. Item Value

1 Header 0x83:Enquiry

2 Category 0xXX

3 Function 0xXX

4 Data1 0xFF

5 Data2 0xFF

6 Check Sum 0xXX

*Check Sum: The total from No.1 to No.5, when value exceeds 255, 1byte

of data is confirmed the bottom.

2FWD-50PX2

1Control answer

No. Item Value

1 Header 0x70: Answer

2 Answer*0x00: Completed

0x01: Limit Over

0x02: Limit Under

0x03: Command Canceled

3 Check Sum 0xXX

*0x00:Completed Normal response.

0x01:Limit Over The packets was received normally, but the

data value was over the upper limit.

Forcedly the monitor adjusted the data to

maximum value.

0x02:Limit Under The packets was received normally, but the

data value was under the lower limit.

Forcedly the monitor adjusted the data to

minimum value.

0x03:Command Canceled The packets was received normally, but the

command was cancelled because the function

was not in adjustable mode, such as “_” a

function displayed as in user menu.

*Check Sum: The total from No.1 to No.2, when value

exceeds 255, 1byte of data is confirmed the

bottom.

2Enquiry answer (Complete)

No. Item Value

1 Header 0x70: Answer

2 Answer 0x00: Completed

3 Return Data Size 0xXX

4 Return Data1 0xXX

: : 0xXX

X Return DataX 0xXX

X+1 Check Sum 0xXX

*0x00: Completed Normal response.

*Return Data returns the read value.

*Check Sum: The total from No.1 to No.X, when value exceeds 255,1byte

of data is confirmed the bottom.

3Enquiry answer (Command cancel)

No. Item Value

1 Header 0x70: Answer

2 Answer 0x03: Command Canceled

3 Check Sum 0xXX

*0x03: Command Canceled The packets was received normally, but the

command was cancelled because the function

was not in adjustable mode, such as “_” a

function displayed as in user menu.

*Check Sum: The total from No.1 to No.2, when value

exceeds 255, 1byte of data is confirmed the

bottom.

4Error answer

No. Item Value

1 Header 0xE0: Answer

2 Answer*0x00: No Function Error

0x01: Check Sum Error

0x02: Data Length Error

3 Check Sum 0xXX

*0x00: No Function Error Packet header, category of function codes do not

exist in this protocol.

0x01: Check Sum Error The “Check Sum” value of the packet which

received is wrong.

0x02: Data Length Error The “Data Num” value of the packet which

received is wrong.

FWD-50PX2

4. General Function

(a) Mode Control

Syntax Header Category Function Data1 Data2 Check Sum

Control 0x8C 0x00 Code Table(1-a)[a] 0x02 Code Table(1-a)[b] 0xXX

Enquiry 0x83 0xFF 0xFF 0xXX

Answer Header Answer Check Sum

Control 0x70 0x00 0x70 Completed

0x70 0x01 0x71 Limit Over

0x70 0x02 0x72 Limit Under

0x70 0x03 0x73 Command Canceled

Answer Header Answer Return to Data Size Return Data1 Check Sum

Enquiry 0x70 0x00 0x02 Code Table(1-a)[b] 0xXX Completed

Code Table(1-a)

[a]Function [b]Range/Switch Code Command

Control Enquiry Standby Power On

0x00 Power*10x00 OFF Yes Yes Enable Enable

0x01 ON

0x01 Input Select*20x0A INPUT2 RGB Yes Yes Disable Enable

0x0B INPUT2 COMPONENT

0x0C OPTION1 VIDEO

0x0D OPTION1 S VIDEO

0x0E OPTION1 RGB

0x0F OPTION1 COMPONENT

0x10 OPTION2 VIDEO

0x11 OPTION2 S VIDEO

0x12 OPTION2 RGB

0x13 OPTION2 COMPONENT

0x20 INPUT1 DVI

0x02 Force Status Display 0x00 ON Yes Yes Disable Enable

0x01 OFF

0x03 Audio Mute 0x00 OFF Yes Yes Disable Enable

0x01 ON

0x04 Auto Status Display 0x00 ON Yes Yes Enable Enable

0x01 OFF

0x05 Closed Caption 0x00 OFF Yes Yes Disable Enable

0x01 CC1

0x02 CC2

0x03 CC3

0x04 CC4 (Continued)

4FWD-50PX2

Code Table(1-a)

[a]Function [b]Range/Switch Code Command

Control Enquiry Standby Power On

0x06 Color System 0x00 Auto Yes Yes Disable Enable

0x01 NTSC

0x02 NTSC4.43

0x03 PAL

0x04 SECAM

0x05 PAL-M

0x06 PAL-N

0x07 PAL60

0x0B Picture Inversion 0x00 OFF Yes Yes Disable Enable

0x01 Auto

0x02 On

0x0C Picture Orbit 0x00 OFF Yes Yes Disable Enable

0x02 ON

0x0D Orbit Range 0x00 Small Yes Yes Disable Enable

0x01 Middle

0x02 Large

0x0E Orbit Cycle 0x00 10 sec Yes Yes Disable Enable

0x01 30 sec

0x02 1 min

0x03 5 min

0x0F Language 0x00 Japanese Yes Yes Disable Enable

0x01 English

0x02 Deutsch

0x03 Français

0x04 Español

0x05 Italiano

0x10 Index Number 0x01-0xFF Yes Yes Disable Enable

0x13 Power Saving 0x00 Standard Yes Yes Disable Enable

0x01 Reduce

0x14 Speaker Out 0x00 ON Yes Yes Disable Enable

0x01 OFF

0x16 HD Mode 0x00 1080i Yes Yes Disable Enable

0x01 1035i

0x17 RGB Mode 0x00 DTV Yes Yes Disable Enable

0x01 PC

0x18 Sync Mode 0x00 H/Comp Yes Yes Disable Enable

0x01 Video

0x1B Clock Display 0x00 OFF Yes Yes Disable Enable

0x01 ON

0x40 All White 0x00 OFF Yes Yes Disable Enable

0x01 ON (Continued)

FWD-50PX2

Code Table(1-a)

[a]Function [b]Range/Switch Code Command

Control Enquiry Standby Power On

0x41 BackGroud 0x00 Gray Yes Yes Disable Enable

0x01 Dark Gray

0x02 Black

0x49 Auto Dimmer 0x00 OFF Yes Yes Disable Enable

0x01 ON

0x65 IP Setting Mode 0x00 DHCP Yes Yes Enable Enable

0x01 Manual

0X02 Speed

0x66 IP Setting Execute 0x00 No No Yes Enable Enable

0x01 Yes

0x67 IP Setting Result 0x00 Done Yes No Enable Enable

0x01 Error 1 (UART Commu.)

0x02 Error 2 (Duplication)

0x03 Error 3 (IP Add Setting)

0x04 Error 4 (GW Add setting)

0x05 Error 5 (DNS1 Setting)

0x06 Error 6 (DNS2 Setting)

0x07 Error 7 (Sbnt Msk Setting)

0x68 Speed Setting 0x00 100Mbps/Full Duplex Yes Yes Enable Enable

0x01 100Mbps/Half Duplex

0x02 10Mbps/Full Duplex

0x03 10Mbps/Half Duplex

0x04 Auto

0x24 Input Detect (Option1) 0x00 U3 (HD15) No Yes Disable Enable

0x01 U1 (CVBS/Y, C)

0x02 U2 (BNC)

0x03 Reserved

0x04 FW31/FW32

0x05 FW50

0x06 Reserved

0x07 Reserved

0x08 Reserved

0x09 Reserved

0x0A Reserved

0x0B Reserved

0x0C Reserved

0x0D Reserved

0x0E Reserved

0x0F Not Connected (Continued)

6FWD-50PX2

Code Table(1-a)

[a]Function [b]Range/Switch Code Command

Control Enquiry Standby Power On

0x25 Input Detect (Option2) 0x00 U3 (HD15) No Yes Disable Enable

0x01 U1 (CVBS/Y, C)

0x02 U2 (BNC)

0x03 Reserved

0x04 FW31/FW32

0x05 FW50

0x06 Reserved

0x07 Reserved

0x08 Reserved

0x09 Reserved

0x0A Reserved

0x0B Reserved

0x0C Reserved

0x0D Reserved

0x0E Reserved

0x0F Not Connect

0x26 Auto Shut OFF 0x00 OFF Yes Yes Disable Enable

0x01 ON

0x27 Auto Screen Adjust 0x00 OFF Yes Yes Disable Enable

0x01 ON

0x28 Input Setting 0x00 Selectable Yes Yes Disable Enable

0x01 Fix

0x30 PAP 0x00 OFF Yes Yes Disable Enable

0x01 P&P

0x02 PinP

0x31 Active Picture 0x00 Left (P&P)/Main (PinP) Yes Yes Disable Enable

0x01 Right (P&P)/Sub (PinP)

0x02 Swap*2

0x32 Picture Size (P&P) 0x00-0x0E Yes Yes Disable Enable

0x33 Sub Picture Size (PinP) 0x00 Large Yes Yes Disable Enable

0x01 Small

0x34 Picture Position (PinP)*30x00 Position1 Yes Yes Disable Enable

0x01 Position2

0x02 Position3

0x03 Position4 (Continued)
