Sony S-Frame DPF-A73 Manuel utilisateur

4-174-751-11 (1)

Digital Photo

Frame

DPF-A73/E73

Before operation

Basic operations

Advanced operations

Using with a computer

Error messages

Troubleshooting

Additional information

Digital Photo Frame Handbook

2 GB

Table of Contents

Before operation

Enjoying your photo frame in various

ways ...............................................4

Features ..........................................5

Identifying the parts .......................7

Digital photo frame .......................... 7

Remote control ................................ 8

Basic operations

Preparing the remote control ..........9

Setting the stand ..........................10

To exchange a panel

(DPF-E73 only) .............................11

Turning the photo frame on ..........12

Setting the current time ................13

Inserting a memory card ..............14

Changing the display ....................15

Slideshow display .........................17

Clock and calendar display ...........18

Single view mode (single image

display) .........................................19

Index image display ......................20

Advanced operations

Enjoying a slideshow ....................22

Changing the settings of the

slideshow .......................................22

Importing images from a memory

card to the internal memory .........24

Specifying the playback device .....26

Exporting an image from the

internal memory to a memory

card ..............................................26

Deleting an image .........................28

Adjusting image size and

orientation ....................................29

Enlarging/reducing an image ..........29

Rotating an image ...........................29

Changing the settings of the auto

power on/off function ...................30

Changing the settings ...................31

Setting procedure ...........................31

Items to set .....................................32

Using with a computer

Connecting to a computer ............34

System requirements ......................34

Connecting to a computer to exchange

images ............................................34

Disconnecting your computer .........35

3 GB

Error messages

If an error message appears .........36

Troubleshooting

If trouble occurs ...........................38

Additional information

About memory cards ....................42

“Memory Stick” ..............................42

SD memory card ............................43

xD-Picture Card .............................43

Notes on using a memory card .......43

Index ............................................44

On the illustrations and screen

shots used in this manual

The illustrations and screen shots used in this

manual are of the DPF-A73 unless noted

otherwise.

The illustrations and screen shots used in this

manual may not be identical to those actually

used or displayed.

4 GB

Before operation

Enjoying your photo frame in various ways

The Sony DPF-A73/E73 is a digital photo frame for easily displaying images taken with a digital

camera or other device, without using a computer.

5 GB

Before operation

Features

xSupport for various memory cards

Supports various memory cards, such as a

“Memory Stick”, SD memory card, and xD-

Picture Card. Just insert a memory card

removed from a digital camera or other

device, and you will be able to view the

images immediately. (.page 14, 42)

xVarious display functions

You can enjoy various viewing modes, such

as the slideshow display, Clock and calendar

display, Single view mode, and Index image

display. (.page 15)

xVarious slideshow styles

The displayed image can be switched

automatically as though you are turning the

pages of an album yourself. You can select

from various slideshow styles, including the

ones displaying a clock or calendar. You can

also change playback settings such as the

playback order. (.page 22)

xImporting images to internal memory

You can import and save the images in the

internal memory. (.page 24)

* When using a miniSD/miniSDHC1,

microSD/microSDHC 2or “Memory

Stick Micro” media 3, be sure to insert it

in an appropriate adaptor.

Continued

6 GB

xExporting images

You can export images in the the internal

memory to your memory card.

(.page 26)

* When using a miniSD/miniSDHC1,

microSD/microSDHC 2or “Memory

Stick Micro” media 3, be sure to insert it

in an appropriate adaptor.

xAutomatic rotation of images

The photo frame automatically rotates

images to their proper orientation. Images

are also automatically rotated when the

photo frame is set in either the portrait or

landscape position. (.page 10)

xDisplaying images on a wall

You can hang the photo frame on the wall.

(.supplied Operating Instructions, page

11)

7 GB

Before operation

Identifying the parts

xDigital photo frame

Front

Rear

LCD screen

Remote sensor

Sony logo (DPF-A73 only)

(.page 12)

VIEW MODE button (.page 15)

1(on/standby) button

Standby indicator

MENU button

Direction (B/b/v/V) buttons, ENTER ( ) button

BACK button

Access lamp

Memory card slot (.page 14)

Holes for hanging unit on the wall

Space for storing the stand

Continued

8 GB

xRemote control

USB B connector (.page 34)

Stand (.page 10)

DC IN 5 V jack

SLIDE-SHOW ( ) button

CLOCK ( ) button

MENU button

BACK button

SELECT DEVICE button

ROTATE ( ) button

VIEW MODE buttons

1(on/standby) button

SINGLE button

INDEX ( ) button

Zoom in ( ) button

Direction (B/b/v/V) buttons

ENTER ( ) button

Zoom out ( ) button

IMPORT ( ) button

DELETE ( ) button

About descriptions in this manual

The operations described in this manual are based on remote control operation.

When an operation is performed differently, for example, with the remote control and the

buttons on the photo frame, it will be explained in a tip.

9 GB

Basic operations

Preparing the remote

control

The supplied lithium battery (CR2025) has

already been inserted into the remote control.

Pull out the protective sheet before use as

shown in the figure.

Using the remote control

Point the top end of the remote control towards

the remote sensor on the photo frame.

Note

The photo frame may fall if you use the buttons on the

photo frame when it is hanging on the wall. Operate

the photo frame using the remote control.

Replacing the battery of the

remote control

If the remote control stops working, replace the

battery (CR2025 lithium battery) with a new

one.

1Press the tab in.

2Pull the battery holder out.

3Insert a new battery and slide the

battery holder back into the remote

control.

Insert the battery so that “+” is facing

upwards.

Notes

• Using a battery other than the specified one may

result in the battery rupturing.

• Dispose of used batteries as specified by the local

authorities.

• Do not leave the remote control in a very hot and

humid place.

• Take care that no foreign objects get inside the

remote control when you, for example, replace the

battery.

Protective sheet

Remote

sensor

Continued

10 GB

• Incorrect use of the battery may cause leaking and

corrosion.

– Do not recharge the battery.

– When the remote control will not be used for a

long period of time, remove the battery from the

remote control to prevent leaking and corrosion.

– Incorrectly inserting, shorting, dismantling, or

heating the battery, or throwing it into a fire

may cause the battery to rupture or leak.

Setting the stand

1Hold the photo frame tightly and

insert the stand straight into the

screw hole on the rear panel.

2Screw the stand into the screw hole

firmly until the stand stops turning.

Setting to portrait or landscape

orientation

You can set the photo frame to portrait or

landscape orientation by rotating it without

moving the stand.
