Sony Xperia XZ2 Manuel utilisateur

xperia-xz2_00_Introduction.docx

Introduction

Thank you for purchasing XperiaTM XZ2.

 Before You Begin

 Guide Usage Notes

 Screenshots & Key Labels

Before You Begin

 XperiaTM XZ2 is referred to as "handset" in this guide.

 Read "Safety Precautions" and this guide thoroughly beforehand for proper usage.

 Accessible services may be limited by contract conditions.

 Unauthorized copying of any part of this guide is prohibited.

 Guide content subject to change without prior notice.

 Contact SoftBank Customer Support, General Information if you find inaccuracies.

Guide Usage Notes

 Most operation descriptions are based on default settings.

 Unless noted otherwise, descriptions are for Home Screen.

 Some operation descriptions may be omitted.

 In this guide and on handset, "abroad" means "outside Japan" with regard to handset/service

usage.

 In this guide, microSDTM/microSDHCTM/microSDXCTM Card is referred to as "SD Card."

Screenshots & Key Labels

Screenshots and Key labels are provided for reference only. Actual handset windows, menus, etc.

may differ in appearance.

xperia-xz2_01_Getting Started.docx

Parts & Functions

 Handset (Front)

 Handset (Back/Side)

 Handset Keys

Handset (Front)

Part

Description

Proximity/Light

Sensor

Detects surrounding

brightness to

automatically adjust

Display or backlight

and prevent

Touchscreen

misoperation during a

call.

Earpiece/Speaker

Hear the other party's

voice here.

Also, hear sound

(music, videos, TV,

etc.) from here.

Front Camera

Use to shoot still

images, videos of

yourself, etc.

Notification Lamp

Flashes for

notifications while in

sleep mode. Lights

while charging.

Display

Touchscreen-type

display, operate with

your fingers on

Display.

Speaker

Listen to music as well

as video, TV, etc.

audio.

xperia-xz2_01_Getting Started.docx

Handset (Back/Side)

Part

Description

Second Mic

Reduces noise for

calling.

SIM Card/SD Card

Slot

Insert SIM Card/SD

Card.

Internal

Antenna/GPS

Antenna Area

Internal Antenna for

calls, data

communication and

GPS.

RGBC-IR Sensor

Automatically adjusts

white balance based

for shooting based on

the light source.

Flash/Photo Light

Use as camera flash

when taking photos,

etc.

LaserAF Sensor

Autofocuses for

shooting based on

subject distance.

Wi-Fi®Antenna

Area

Internal Antenna for

Wi-Fi.

Internal Antenna

Area

Internal Antenna for

calls and data

communication.

Wi-Fi/Bluetooth®

Antenna Area

Internal Antenna for

Wi-Fi and Bluetooth®

feature.

Nameplate

CE mark, FCC ID,

IMEI information

printed sticker is

attached. Do not

remove nameplate.

Internal Antenna

Area

Internal Antenna for

calls and data

xperia-xz2_01_Getting Started.docx

communication.

NFC/Osaifu-Keitai

Detection Area

Hold up to a

reader/writer to use

NFC/Osaifu-Keitai®.

Camera

Capture still images

and videos.

Fingerprint

Sensor

Use Fingerprint

authentication.

USB Type-CTM

Port

Connect USB Type-C

cable (commercially

available), etc.

Mic

Speak here.

Handset Keys

Part

Description

Volume/Zoom

Up/Down Key

Adjust Volume.

Adjust Zoom while

using Camera.

Power

Key/Screen Lock

Key ( )

Long Press for power

on/off.

Press for sleep mode

on/off.

Camera Key

( )

Use as Camera

shutter.

Long Press to launch

Camera.

xperia-xz2_01_Getting Started.docx

CE mark and FCC ID

Open the slot cover, and insert a fingernail into the hook at the edge of the label tray, then pull it out

straight.

Available radio frequencies

GSM/GPRS/EDGE 850, 900, 1800, 1900MHz

UMTS 2100 (Band I), 1900 (Band II), 1700 (Band IV), 900 (Band VIII)MHz

LTE (Bands 1,2,3,4,8,11,12,17,28,38,39,40,41,42)

WLAN 2.4G/5G, NFC

GSM 850/900 : Power Class 4, DCS (1800)/PCS (1900) : Power Class 1, UMTS : Power Class 3,

LTE : Power Class 3, 2.4GHz<100mW, 5.15-5.35GHz<200mW, 5.47-5.725GHz<200mW,

5.735-5.835GHz<25mW, NFC 13.56MHz

xperia-xz2_01_Getting Started.docx

SIM Card

SIM Card is an IC card containing phone number and other customer information.

 Inserting SIM Card

 Removing SIM Card

 SIM-Unlocking Handset

Inserting SIM Card

Always unmount SD Card beforehand.

Draw SIM Card/SD Card Slot Cover out straight using groove, and pull SD Card Tray

out

Draw SIM Card Tray out straight using projecting part, and pull SIM Card Tray out

xperia-xz2_01_Getting Started.docx

Set SIM Card into SIM Card Tray with IC chip facing up

 Check SIM Card orientation by notch.

 Make sure SIM Card is in SIM Card Tray securely.

Holding handset level, insert SIM Card Tray into SIM Card Slot straight, and then press

in all the way

xperia-xz2_01_Getting Started.docx

 Check direction of insertion.

Holding handset level, insert SD Card Tray straight, and then press SIM Card/SD Card

Slot Cover firmly where circled ○

SIM Card is inserted.

 Make sure there is no gap between handset and SIM Card/SD Card Slot Cover.

Removing SIM Card

Always unmount SD Card beforehand.

xperia-xz2_01_Getting Started.docx

Draw SIM Card/SD Card Slot Cover out straight using groove, and pull SD Card Tray

out

Draw SIM Card Tray out straight using projecting part, and pull SIM Card Tray out

Remove SIM Card from SIM Card Tray

xperia-xz2_01_Getting Started.docx

Holding handset level, insert SIM Card Tray into SIM Card Slot straight, and then press

in all the way

 Check direction of insertion.

Holding handset level, insert SD Card Tray straight, and then press SIM Card/SD Card

Slot Cover firmly where circled ○
