Sony D2303/D2305/D2306 Guide de référence rapide

Eagle SS WP

White paper

February 2014

Xperia™ M2

D2303/D2305/D2306

Note: Screen images are simulated.

White paper | Xperia™ M2

2 February 2014

This document is published by Sony Mobile

Communications AB, without any warranty*.

Improvements and changes to this text

necessitated by typographical errors,

inaccuracies of current information or

improvements to programs and/or equipment

may be made by Sony Mobile Communications

AB at any time and without notice. Such changes

will, however, be incorporated into new editions

of this document. Printed versions are to be

regarded as temporary reference copies only.

*All implied warranties, including without

limitation the implied warranties of

merchantability or fitness for a particular

purpose, are excluded. In no event shall Sony or

its licensors be liable for incidental or

consequential damages of any nature, including

but not limited to lost profits or commercial loss,

arising out of the use of the information in this

document.

This White paper is published by:

Sony Mobile Communications AB,

SE-221 88 Lund, Sweden

www.sonymobile.com

license to download and/or print a copy of this

document.

Any rights not expressly granted herein are

reserved.

First released version (February 2014)

Publication number: 1272-9741

Purpose of this document

Sony Mobile Communications product White papers are intended to give an overview of a product and

provide details in relevant areas of technology.

Document history

Sony Mobile Developer World

For the latest technical documentation and development tools, go to www.sonymobile.com/developer.

Version

February 2014 First released version Version 1

White paper | Xperia™ M2

1 February 2014

Table of contents

Facts – dimensions, weight, performance and networks ......................................2

Categorised feature list ..........................................................................................5

Technologies in detail ...................................................................................................7

Device-to-device communications (local) .............................................................7

ANT+™ wireless technology...............................................................................7

Bluetooth® wireless technology .........................................................................8

Wi-Fi® .................................................................................................................9

Messaging ...........................................................................................................10

MMS (Multimedia Messaging Service)..............................................................10

Email .................................................................................................................10

Positioning – location based services .................................................................11

Provisioning (OMA CP) ........................................................................................11

Multimedia (audio, image and video) ...................................................................12

Synchronisation (OMA DS, EAS, Google Sync™) ...............................................13

Web browser .......................................................................................................13

Memory in Android™ devices .............................................................................14

Trademarks and acknowledgements ..................................................................18

White paper | Xperia™ M2

2 February 2014

Facts – dimensions, weight, performance and

networks

Operating system Google™ Android™ 4.3 (Jelly Bean MR2)

Processor 1.2 GHz Qualcomm MSM8926 Quad Core (D2303, D2306)

1.2 GHz Qualcomm MSM8226 Quad Core (D2305)

GPU Adreno 305

Size 139.65 x 71.14 x 8.64 mm

Weight 148 grams

Available colours Black

White

Purple

Main screen

Colours 16,777,216 colour TFT

Resolution 540x960 pixels

Size (diagonal) 4.8 inches

Scratch-resistant Yes -Touch panel cover glass

Input mechanisms

Text input On-screen QWERTY keyboard, 12 key input

Touch screen Capacitive

Touch gesture Yes – multi-touch, up to 4 fingers supported

Handwriting recognition Yes

Memory

RAM 1 GB

Flash memory Up to 8 GB*

Expansion slot microSD™ card, up to 32 GB

Camera

Camera resolution 8 MP

Digital zoom 4x

Video recording Yes – HD 1080p

Sensors

Accelerometer Yes

Ambient light sensor Yes

White paper | Xperia™ M2

3 February 2014

* Memory comprises of approximately of 3 GB firmware, plus 5 GB of “Internal Storage” for downloaded

applications, music, pictures and movies, and some application data. For more details about memory, see

“Memory in Android™ devices” on page 14.

** Values are according to GSM Association Battery Life Measurement Technique as performed in con-

trolled laboratory conditions. Actual time may vary.

NOTE: Battery performance may vary depending on network conditions and configurations, and device

usage.

NOTE: All performance metrics are measured under laboratory conditions.

Proximity sensor Yes

Magnetometer Yes

Networks

D2303 UMTS HSPA+ 900 (Band VIII), 850 (Band V), 2100 (Band I) MHz

GSM GPRS/EDGE 850, 900, 1800, 1900 MHz

D2306 UMTS HSPA+ 850 (Band V), 1700 (Band IV), 1900 (Band II),

2100 (Band I) MHz

GSM GPRS/EDGE 850, 900, 1800, 1900 MHz

D2305 UMTS HSPA+ 900 (Band VIII), 850 (Band V), 1900 (Band II),

2100 (Band I) MHz

GSM GPRS/EDGE 850, 900, 1800, 1900 MHz

Data transfer speeds

GSM GPRS

(upload and download)

Up to 107 kbps (download), Up to 85.6 kbps (upload).

GSM EDGE

(upload and download)

Up to 296 kbps (download). Up to 236.8 kbps (upload).

UMTS HSUPA (upload) Cat. 6, up to 5.76 Mbps

UMTS HSDPA (download) Cat. 14, up to 21 Mbps

HAC/TTY

HAC M3/T3

TTY Yes

Talk time (GSM) Up to 13 hours 25 min.**

Standby time (GSM) Up to 588 hours**

Talk time (UMTS) Up to 14 hours 36 min.**

Standby time (UMTS) Up to 633 hours**

Music listening time Up to 58 hours 25 min.**

Video playback time Up to 7 hours 58 min.**

Battery (Embedded) 2300 mAh

White paper | Xperia™ M2

4 February 2014

Categorised feature list

Camera

8 megapixel camera

4x digital zoom

Auto focus

Face detection

Fast capture

Flash/Photo light

Geotagging

HDR for pictures

HD video recording (1080p)

Image stabiliser

Quick Launch

Red-eye reduction

Scene recognition

Self-timer

Send to web

Superior Auto

Smile shutter™

Sony Exmor RS® for mobile

Red-eye reduction

Sweep Panorama

Touch capture

Touch focus

Video light

Video recording (WVGA)

White balance

Music

3D Surround Sound (VPT)

Album art

Bluetooth® stereo (A2DP)

ClearAudio+

Clear Bass™

Clear Phase™

Clear stereo

Dynamic normaliser

Manual equaliser

PlayNow™ service*

SensMe™

TrackID™ music recognition*

“WALKMAN” application

xLoud™ Experience

Internet

Bookmarks

Google Chrome™*

Google Play™

Google™ search*

Google Voice™ Search*

Google Maps™ for Mobile with

Street view*

NeoReader™ barcode scanner*

Web browser (WebKit™)*

Communication

Call list

Conference calls

Facebook™ application*

Friends application

Hangouts™*

HD voice support

Loud Speaker

Multiple IM

Noise suppression

Speakerphone

Twitter™ application*

Xperia™ with Facebook™

Messaging

Conversations

Google mail™*

Handwriting recognition

Instant messaging

Multimedia messaging (MMS)

Predictive text input

Text messaging (SMS)

Design

Auto rotation

Gesture input

Hardware Walkman key

Illumination effect

On-screen 12-key keyboard

On-screen QWERTY keyboard

Picture wallpaper

Screen capturing

Shake control

STAMINA mode

Touch screen

Voice input

Wallpaper animation

White paper | Xperia™ M2

5 February 2014

* This service is not available in all markets.

** Sony Entertainment Network with Music Unlimited is not available in every market. Separate

subscription required. Additional terms and conditions apply.

Entertainment

3D games

Media browser

Motion gaming

PlayMemories*

Radio (FM radio with RDS)

Sony Entertainment Network**

Video streaming

YouTube™*

Organiser

Airplane mode

Alarm clock

Calculator

Calendar

Contacts

Document readers

eCompass™

Notes

Setup guide

Stopwatch

Timer

World clock

Connectivity

3.5 mm audio jack (CTIA)

ANT+™ sport, fitness, health sup-

port

aGPS*

Bluetooth® 4.0 wireless

technology

DLNA Certified®

GLONASS

Media Transfer Protocol support

Micro USB support

Native USB tethering

Media Go™*

NFC

PC Companion

Play Anywhere

Smart Connect

Synchronisation via Facebook™

Synchronisation via SyncML™

Synchronisation via Google™

Synchronisation with computer

Synchronisation via Microsoft®

Exchange ActiveSync®

USB High speed 2.0 support

USB Host

USB mass storage

Xperia Link™

Wi-Fi®

Wi-Fi® Hotspot functionality

White paper | Xperia™ M2

6 February 2014

Technologies in detail

NOTE: The information outlined below is general and levels of compliance to standards and specifications

may vary between products and markets. For more information, contact Sony Developer World or your

Sony contact person where applicable.

Device-to-device communications (local)

ANT+™ wireless technology

Connectable devices ANT+™ devices require download of a supporting appli-

cation

Frequency band 2.4 GHz

Data transfer rate Up to 60 Kbps

Encryption AES-128

Topologies One to Many, Many to One, Peer to Peer, Star, Practical

Mesh

White paper | Xperia™ M2

7 February 2014

Bluetooth® wireless technology

More information:

www.sonymobile.com/developer

www.bluetooth.com

Bluetooth® profiles supported Advanced Audio Distribution Profile v1.2

Audio/Video Remote Control Profile v1.3

Generic Attribute Profile Client/Server over LE

Handsfree Profile v1.6 (Wide band speech)

Headset Profile v1.2

Human Interface Device Profile v1.0

Object Push Profile v1.1

Personal Area Networking Profile v1.0

FTP v1.1 (server role)

DUN 1.1

Core version and supported

core features

Version 4.0

Connectable devices Products that support at least one of the profiles listed

above.

Bluetooth 4.0 accessories generally require installation of

a supporting application.

White paper | Xperia™ M2

8 February 2014

Wi-Fi®

Supported standards IEEE 802.11 a/b/g/n and Wi-Fi®

Wi-Fi Direct®, Wi-Fi Protected Setup

Connectable devices Wi-Fi® access points

Wi-Fi Direct compatible devices

Frequency band 2.4 GHz / 5 GHz

Data transfer rate Up to 150 Mbit/s

Security Open Authentication

Shared Authentication

EAP-SIM

EAP-AKA

EAP-TLS

EAP-TTLS/MSCHAPv2

PEAPv0/EAP-MSCHAPv2

PEAPv1/EAP-GTC

WPA Personal and WPA2 Personal

WPA Enterprise and WPA2 Enterprise

Encryption WEP 64 bit, WEP 128 bit, TKIP and CCMP (AES)

Power save WMM-UAPSD

QoS WMM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sony Téléphone portable

Sony

Sony CMD-J5 Manuel utilisateur

Sony

Sony CM-S 100 Series Manuel utilisateur

Sony

Sony Xperia PRO Guide de référence

Sony

Sony XPeria ST25i Manuel utilisateur

Sony

Sony Xperia neo MT15 Manuel utilisateur

Sony

Sony J3173 Guide de l'utilisateur

Sony

Sony Xperia SM13 Manuel utilisateur

Sony

Sony Xperia 1 Manuel utilisateur

Sony

Sony Xperia Z1 Compact D5503 Guide de référence rapide

Sony

Sony Xperia XA1 Ultra Manuel utilisateur

Sony

Sony Xperia Z3 Manuel utilisateur

Sony

Sony Xperia M2 Aqua D2403 Manuel utilisateur

Sony

Sony Xperia ZL Manuel utilisateur

Sony

Sony XPERIA R1 PLUS Manuel utilisateur

Sony

Sony Xperia XZ2 Premium SOV38 Manuel de service

Sony

Sony Xperia advance Manuel utilisateur

Sony

Sony Xperia TL LT30at Guide de référence rapide

Sony

Sony G3313 Manuel utilisateur

Sony

Sony Xperia X Compact F5321 Guide de l'utilisateur

Sony

Sony Xperia ZL Manuel utilisateur

Sony

Sony G3212 Guide de l'utilisateur

Sony

Sony Xperia Z1 Manuel utilisateur

Sony

Sony Xperia XA F3116 Manuel utilisateur

Sony

Sony Xperia X F5121 Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
