Sony SCD-XE600 Manuel utilisateur

2-021-059-61(2)

Super Audio CD

Player

Operating Instructions __________________________

使用説明書 __________________________________

SCD-XE600

2GB

To prevent fire or shock hazard, do not

expose the unit to rain or moisture.

To avoid electrical shock, do not open

the cabinet. Refer servicing to qualified

personnel only.

To prevent fire, do not cover the ventilation of the

apparatus with news papers, table-cloths, curtains, etc.

And don’t place lighted candles on the apparatus.

To prevent fire or shock hazard, do not place objects

filled with liquids, such as vases, on the apparatus.

This appliance is

classified as a CLASS 1

LASER product. This

label is located on the

rear exterior.

Don’t throw away the battery with

general house waste, dispose of it

correctly as chemical waste.

WARNING

3GB

Features of the player....................................................................................4

Compatible Disc Types .................................................................................4

About the Super Audio CD...........................................................................5

Getting Started

Inserting batteries into the remote.................................................................6

Hooking Up the Audio Components.............................................................6

Playing Discs

Playing a Disc................................................................................................9

Using the Display........................................................................................10

Locating a Particular Point in a Track.........................................................12

Playing Tracks Repeatedly..........................................................................13

— Repeat Play

Playing Tracks in Random Order................................................................13

— Shuffle Play

Creating Your Own Program ......................................................................14

— Program Play

Enjoying a Multi-channel Super Audio CD................................................15

— Multi-channel management function

Additional Information

Precautions ..................................................................................................19

Notes on Discs.............................................................................................20

Troubleshooting...........................................................................................21

Specifications ..............................................................................................22

Index to Parts and Controls .........................................................................23

Table of Contents

4GB

This player is designed to play back 2-channel

and Multi-channel Super Audio CDs, and

conventional CDs, and provides the following

features:

• Mounted with a Discrete Dual Laser Optical

Pickup, capable of reading a Super Audio CD

or conventional CD depending on the

exclusive wavelength.

• Quicker track access performance enabled by

an advanced servo mechanism.

• A Multi-Channel Management function that

allows you to adjust the multi-channel

playback environment according to the

allocation and size of your speakers.

• A Super Audio D/A Converter, which allows

higher-quality sound reproduction.

• A Super Audio CD can mark up to 255 track

numbers. This feature applies to SCD-XE600.

• The supplied remote is capable of controlling

both the SCD-XE600 and a conventional

Sony CD player.

You can play the following types of discs on this

player.

• Super Audio CDs

• Audio CDs

This player cannot play the following discs. If

you try to play them, the error message “TOC

ERROR” or “NO DISC” will appear.

•CD-ROMs

• DVDs, etc.

Music discs encoded with copyright

protection technologies

This product is designed to playback discs that

conform to the Compact Disc (CD) standard.

Recently, various music discs encoded with copyright

protection technologies are marketed by some record

companies. Please be aware that among those discs,

there are some that do not conform to the CD standard

and may not be playable by this product.

Notes on CD-R/CD-RW playback

Discs recorded on CD-R/CD-RW drives may not be

played back because of scratches, dirt, recording

condition, or the drive’s characteristics. Besides, the

discs, which are not yet finalized at the end of

recording, cannot be played back. In these cases,

“READING” will remain or “TOC ERROR” will

appear in the display.

Note on dts-CDs

Do not play a dts-CD on this player. If you do, severe

noise will be generated.

Features of the player Compatible Disc Types

5GB

Super Audio CD is a new high-quality audio

disc standard where music is recorded in the

DSD (Direct Stream Digital) format

(conventional CDs are recorded in the PCM

format). The DSD format, using a sampling

frequency 64 times higher than that of a

conventional CD, and with 1-bit quantization,

achievesbothawidefrequencyrangeandawide

dynamic range across the audible frequency

range, and so provides music reproduction

extremely faithful to the original sound.

Types of Super Audio CDs

There are two types of discs, depending on the

SA-CD layer and CD layer combination.

SA-CD layer:A high-density signal layer for

Super Audio CD

CD layer1): A layer that is readable by a

conventional CD player

Single layer disc

(a disc with a single SA-CD layer)

Hybrid disc2)

(a disc with an SA-CD layer and a CD layer)

An SA-CD layer consists of the 2 channel area

or the multi-channel area.

2 channel area: An area in which 2 channel

stereo tracks are recorded

Multi-channel area:

An area in which multi-

channel (up to 5.1 channels)

tracks are recorded

Example:

When the 2 channel area and the multi-channel area

are recorded on an SA-CD layer of a hybrid disc

1) You can play the CD layer on a conventional CD

player.

2) Since both layers are on one side, it is not necessary

to turn the disc over.

3) Press SA-CD/CD to select the layer you want to

listen to (see page 9).

4) In case of a disc with both areas, press MULTI/2CH

to select the area you want to listen to (see page 9).

About the Super Audio CD

SA-CD layer

CD layer3)

SA-CD layer3)

Multi-channel area4)

2 channel area4)

SA-CD layer

6GB

Insert two R6 (size-AA) batteries into the

battery compartment with the + and – correctly

oriented to the markings. When using the

remote, point it at the remote sensor on the

player.

Tip

Under normal conditions, the batteries should last for

about six months. When the remote no longer operates

the player, replace both batteries with new ones.

Notes

• Do not leave the remote in an extremely hot or a

humid place.

• Do not drop any foreign object into the remote

casing, particularly when replacing the batteries.

• Do not use a new battery with an old one.

• Do not expose the remote sensor to direct sunlight or

lighting apparatus. Doing so may cause a

malfunction.

• If you do not intend to use the remote for an extended

period of time, remove the batteries to avoid possible

damage from battery leakage and corrosion.

Connect the Super Audio CD player to an audio

component. Be sure to turn off the power of all

components before making connections and

connect securely to prevent noise.

Connecting a multi-channel

amplifier

When you have an amplifier equipped with the

5.1CH inputjacks (multi-channel amplifier, AV

amplifier, etc.) and connect the player and the

amplifier through the ANALOG 5.1CH OUT

jacks (FRONT L/R, SURR L/R,CENTER, SUB

WOOFER), you can play a Multi-channel Super

Audio CD and enjoy the multi-channel

playback.

Use audio connecting cords for this connection.

For FRONT or SURR connection, use the

connecting cords (Red and White jacks) and be

sure to match the color-coded pin to the

appropriate jacks: white (left) to white and red

(right) to red. For CENTER and SUB WOOFER

connection, use the connecting cords (Black).

FRONT or SURR connection

Audio connecting cords (one cord is supplied)

CENTER or SUB WOOFER

connection

Audio connecting cords (not supplied)

Getting Started

Inserting batteries into

the remote

Hooking Up the Audio

Components

White (L)

Red (R)

Black

Getting Started

7GB

Note

There are 5CH, 4CH, and 3CH Super Audio CD. When

you play these discs, the signal does not output from all

the jacks of the ANALOG 5.1CH OUT. For details of

the playback, seethe cover or instructions of the Super

Audio CD.

Connecting a stereo amplifier

or MD deck

When you connect a stereo amplifier or make an

analogconnectionwithanMD deck,connectthe

player and the component through the

ANALOG 5.1CH OUT FRONT L/R jacks.

Use an audio connecting cord for this

connection. Be sure to match the color-coded

pin to the appropriate jacks: white (left) to white

and red (right) to red.

Audio connecting cord (supplied)

Note

When a disc with the 2 channel area and multi-channel

area is played through the ANALOG 5.1CH OUT

FRONT L/R jacks, change the default playback area to

“SEL– 2ch” (2 channel playback area) (see page 9). If

you do not, the multi-channel playback area will be

automatically played back and only the signal to the

front speakers will be output. In this case, the vocals or

other sounds may not be heard, depending on the disc.

A: To front speaker input jacks (L/R)

B: To surround or rear speaker input jacks (L/R)

C: To sub woofer input jack

D: To center speaker input jack

ABC

Tomulti-channel

amplifier, AV

amplifier, etc.

White (L)

Red (R)

To CD (Super Audio CD) or line input jacks

(L/R) on a stereo amplifier, MD deck, etc.

continued

8GB

Connecting a digital

component

When you connect an MD deck or another

digital component through the DIGITAL (CD)

OUT OPTICAL connector, you can make a

digital recording.

Use an optical digital cable for this connection.

When connecting the optical digital cable to the

DIGITAL (CD) OUT OPTICAL connector,

push the cable plug in until it clicks into place.

Be careful not to bend or twist the optical cable.

Optical digital cable (not supplied)

Note

Only the audio signals of conventional CDs can be

output from the DIGITAL (CD) OUT OPTICAL

connector. Those of the Super Audio CD cannot be

output through the DIGITAL (CD) OUT OPTICAL

connector.

Connecting the AC power

cord

Connect the AC power cord to a wall outlet.

When using another Sony CD

playerin conjunction with this

player

You can set the supplied remote to be effective

on this player only by changing the command

mode of the remote.

To set the command mode of the

remote

• If the other player’s command mode can be

set:

Set the CD1/2 switch of this player’s remote

to CD1 (factory setting), and set the other

player’s remote to CD2.

• If the other player’s command mode cannot

be set:

Set the CD1/2 switch of this player’s remote

to CD2.

To set the command mode of this

player

1Press MENU on the player.

2Turn l AMS L(or press ./>

on the remote repeatedly) to select

“CD1/2 SEL”.

3Press l AMS L(or ENTER on the

remote).

The current command mode appears.

4Turn l AMS L(or press ./>

on the remote) to select “CD – 1” or

“CD – 2”, then press l AMS L(or

ENTER on the remote).

To CD optical digital input connector

on an MD deck, etc.

Playing Discs

9GB

The operations for normal play and the basic

operations during play are explained below.

1Turn on the amplifier. Turn down the

volume level to the lowest.

2Select the player position using the

input selector on the amplifier.

3Press POWER on the player to turn on

the player.

4Press Aon the player to open the disc

tray, and place a disc on the tray.

5Press H.

Playback starts from the first track. If you

want to start playing from a specific track,

turn l AMS L(or press ./>

on the remote repeatedly) to select the track

number before pressing H.

6Adjust the volume on the amplifier.

Basic operations during play

Tip

If you turn on the player when a disc is already loaded,

playback starts automatically. If you connect a

commercially available timer, you can set it to start

playing the disc at any time you want.

Note

During playback, increase the volume level gradually

starting from the lowest level. The output from this

player may contain band width that is out of the normal

listening range. This may cause damage to the speakers

or ears.

Selecting the playback layer

When playing a hybrid disc with an SA-CD

layer and a CD layer (page 5), you can select the

layer you want to listen to. Also, since both

layers are on one side, it is not necessary to turn

the disc over.

Press SA-CD/CD to select the desired

playback layer.

To select the default playback

layer

1Press MENU on the player.

2Turn l AMS L(or press ./>

onthe remoterepeatedly) until“LAYER

SEL” appears in the display.

3Press l AMS L(or ENTER on the

remote).

The current default layer appears.

4Turn l AMS L(or press ./>

on the remote) to select the desired

playback layer.

5Press l AMS L(or ENTER on the

remote).

Selecting the playback area

When playing a disc with the 2 channel playback

area and the multi-channel playback area

(page 5), you can select the playback area you

want to listen to.

Press MULTI/2CH to select the desired

playback area.

Playing Discs

Playing a Disc

To Do the following:

Stop play Press x.

Pause play Press X.

Resume play

after pausing Press Xor H.

Select a track Turn l AMS L(or press

./> on the remote

repeatedly).

Eject a disc Press Aon the player.

With the label side up

continued

10GB

To select the default playback

area

1Press MENU on the player.

2Turn l AMS L(or press ./>

on the remote repeatedly) until “M/2ch

SEL” appears in the display.

3Press l AMS L(or ENTER on the

remote).

The current default area appears.

4Turn l AMS L(or press ./>

on the remote) to select the desired

playback area.

5Press l AMS L(or ENTER on the

remote).

Note

The multi-channel playback area is automatically

selected whenever you start playback because “SEL–

Mch” (multi-channel playback area) is the factory

setting. Select “SEL– 2ch” (2 channel playback area)

when only the ANALOG 5.1CH OUT FRONT L/R

jacks are connected.

The display window shows various information

about the disc or track being played. This section

describes the current disc information and

information that appears for each play status.

Disc information when a disc

is loaded

The display shows the total number of tracks and

total playing time.

Using the Display

A: Hybrid disc

B: Currently loaded disc and number of playable

channels

C: Track 16 and above (for discs with 16 or more

tracks)

D: Total playing time

E: Total number of tracks

Autres manuels pour SCD-XE600

Table des matières

Autres manuels Sony Lecteur CD

Sony

Sony CDX-GT627UV Manuel utilisateur

Sony

Sony DVP-CX777ES Guide de configuration rapide

Sony

Sony MXD-D5C Manuel utilisateur

Sony

Sony CDX-CA760X - Fm/am Compact Disc Player Manuel utilisateur

Sony

Sony CDP-211 - Compact Disc Player Manuel utilisateur

Sony

Sony CDX-424RF - Compact Disc Changer System Manuel utilisateur

Sony

Sony CFD-S250 - Cd Radio Cassette-corder Manuel utilisateur

Sony

Sony CDX-GT500 - Fm/am Compact Disc Player Manuel utilisateur

Sony

Sony CFD-Z500 - Cd Radio Cassette-corder Manuel utilisateur

Sony

Sony Walkman D-NF421 Mode d’emploi

Sony

Sony CDX-GT35U - Fm/am Compact Disc Player Guide produit

Sony

Sony SCD-1 - Super Audio Cd Player Manuel utilisateur

Sony

Sony CFD-DW250S Manuel utilisateur

Sony

Sony D-263 Manuel utilisateur

Sony

Sony CDP-CX260 - 200 Disc Cd Changer Manuel utilisateur

Sony

Sony CDX-F5705X - Fm/am Compact Disc Player Guide produit

Sony

Sony Walkman D-EJ835 Manuel utilisateur

Sony

Sony Discman D-121 Manuel utilisateur

Sony

Sony SCD-XE800 Manuel utilisateur

Sony

Sony MZ-B100 - Minidisc Business Product Recorder Manuel utilisateur

Sony

Sony Discman D-T405 Manuel utilisateur

Sony

Sony HCD-BX9 Manuel utilisateur

Sony

Sony Net MD Walkman MZ-N1 Manuel utilisateur

Sony

Sony CDX-747X - Compact Disc Changer System Manuel utilisateur

Manuels Lecteur CD populaires d'autres marques

RCA

RCA RP-7923 Manuel utilisateur

Pioneer

Pioneer DEH-P3550MP XM Manuel utilisateur

Philips

Philips AZ1207 Manuel utilisateur

Philips

Philips CD582 Manuel utilisateur

Philips

Philips AZ 6821 Manuel utilisateur

Lasonic

Lasonic MSU-2020 Manuel utilisateur

THOMSON

THOMSON RCD150 Manuel utilisateur

Denon

Denon DCD-1420 Manuel utilisateur

Panasonic

Panasonic SJ-MR100 Manuel utilisateur

Onkyo

Onkyo DX-7210 Manuel utilisateur

Denon

Denon DVM-4800 Manuel utilisateur

JBL

JBL MR-32 Manuel utilisateur

RCA

RCA RCD152 Manuel utilisateur

Technics

Technics SL-PS770A Manuel utilisateur

Clarion

Clarion compact disc Manuel utilisateur

Philips

Philips Expanium AZ 1538 Manuel utilisateur

Rotel

Rotel RCD 975 Manuel utilisateur

Pioneer

Pioneer CLD-D790 Manuel utilisateur
