CD Radio
Cassette-Corder
Operating Instructions
3-263-561-11 (1)
© 2004 Sony Corporation
CFD-E90
2
Warning
To prevent fire or shock hazard,
do not expose the player to rain
or moisture.
This symbol is intended to alert
the user to the presence of
uninsulated “dangerous voltage”
within the product's enclosure that
may be of sufficient magnitude to
constitute a risk of electric shock
to persons.
This symbol is intended to alert
the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
CAUTION
The use of optical instruments with this product
will increase eye hazard.
WARNING
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.
To prevent fire or shock hazard, do not place
objects filled with liquids, such as vases, on the
appliance.
For customers in Canada
To prevent electric shock, match wide blade of
plug to wide slot, fully insert.
Information
For customers in the United States
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment
and receiver.
—Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
—Consult the dealer or an experienced radio/TV
technician for help.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.
Owner's Record
The model number is located on the bottom and
the serial number is located in the battery
compartment.
Record the serial number in the space provided
below. Refer to these numbers whenever you call
upon your Sony dealer regarding this product.
Model No. CFD-E90
Serial No.
Basic Operations
3
Table of contents
Basic Operations
Playing a CD .................................................. 4
Listening to the radio...................................... 6
Playing a tape ................................................. 8
Recording on a tape ...................................... 10
The CD Player
Using the display .......................................... 12
Locating a specific point in a track............... 12
Playing tracks repeatedly
(Repeat Play) ........................................... 13
Playing tracks in random order
(Shuffle Play) ........................................... 14
Creating your own program
(Program Play) ......................................... 14
The Radio
Presetting radio stations................................ 16
Playing preset radio stations ......................... 17
The Audio Emphasis
Selecting the audio emphasis
(MEGA BASS)........................................ 18
The Timer
Setting the clock ........................................... 19
Waking up to music...................................... 20
Falling asleep to music ................................. 21
Setting Up
Choosing the power sources ......................... 23
Additional Information
Precautions ................................................... 25
Troubleshooting............................................ 26
Maintenance ................................................. 29
Specifications ............................................... 30
Index ............................................................. 31
About the demonstration
mode
If “HELLO” appears on the display, the
player is in the demonstration mode. To
exit from the demonstration mode, set the
clock or press DISPLAY for 2 seconds.
4
Connect the supplied AC power cord (see page 23).
1Press ZPUSH OPEN/CLOSE down
to open the CD compartment and
place the CD on the CD
compartment.
2Close the lid of the CD compartment.
3Press u.
The player turns on (direct power-on)
and plays all the tracks once.
Basic Operations
3
Playing a CD
Display
With the label side up
1, 2
Playing timeTrack number
Basic Operations
5
Use these buttons for additional operations
POWER
x
u
Jog dial
VOLUME +, –
ZPUSH
OPEN/CLOSE
To Do this
adjust the volume Press VOLUME +*, – (VOL +, –
on the remote).
stop playback Press x.
pause playback Press u*.
Press the button again to resume
play after pause.
go to the next track Turn the jog dial clockwise.
(On the remote, press >.)
go back to the previous track Turn the jog dial counterclockwise.
(On the remote, press ..)
remove the CD Press ZPUSH OPEN/CLOSE.
turn on/off the player Press POWER.
*The button has a tactile dot.
6
Listening to the radio
Connect the supplied AC power cord (see page 23).
1Press RADIO•BAND•AUTO
PRESET until the band you want
appears in the display (direct power-
on).
2Hold down TUNE + or TUNE – until
the frequency digits begin to change
in the display.
The player automatically scans the
radio frequencies and stops when it
finds a clear station.
If you can't tune in a station, press
the button repeatedly to change the
frequency step by step.
Display
Indicates an FM stereo
broadcast
12
Basic Operations
7
Use these buttons for additional operations
To Press
adjust the volume VOLUME +*, –
(VOL +, – on the remote)
turn on/off the radio POWER
* VOLUME + has a tactile dot.
To improve broadcast reception
Reorient the antenna for FM. Reorient the player itself for
AM.
for FM for AM
Tip
If the FM broadcast is
noisy, press MODE until
“Mono” appears in the
display and the radio will
play in monaural.
POWER
VOLUME +, –
MODE
8
Playing a tape
Connect the supplied AC power cord (see page 23).
1Press xZ to open the tape
compartment and insert a recorded
tape. Use TYPE I (normal) tape only.
Close the compartment.
2Press n.
The player turns on (direct power-on)
and starts playing.
With the side you want
to play facing you
Display
21
Basic Operations
9
Use these buttons for additional operations
To Press
adjust the volume VOLUME +*, –
(VOL +, – on the remote)
stop playback xZ
fast-forward or rewind the tape mor M
pause playback X
Press the button again to
resume play after pause.
eject the cassette xZ
turn on/off the player POWER
*VOLUME + and nhave a tactile dot.
xZ
X
m, M
POWER
VOLUME +, –
10
Recording on a tape
Connect the supplied AC power cord (see page 23).
1Press xZ to open the tape
compartment and insert a blank tape.
Use TYPE I (normal) tape only.
2Select the program source you want
to record.
To record from the CD player, insert
a CD (see page 4) and press xon the
CD section.
To record from the radio, tune in the
station you want (see page 6).
3
With the side you want to
record on facing you
Display
