Operating Instructions

1998 by Sony Corporation

FM/AM

Compact Disc

Player

CDX-C680

For installation and connections, see the supplied installation/connections

manual.

Owner’s Record

The model and serial numbers are located on the bottom of the unit.

Record the serial number in the space provided below.

Refer to these numbers whenever you call upon your Sony dealer regarding this

product.

Model No. CDX-C680␣ ␣ Serial No.

Welcome !

Thank you for purchasing the Sony Compact

Disc Player. This unit lets you enjoy a variety

of features by using either an optional rotary

commander or an optional wireless remote.

In addition to the CD playback and radio

operations, you can expand your system by

connecting an optional CD/MD unit*1.

If you operate this unit or connect an optional

CD unit with the CD TEXT function, the

CD TEXT information will appear in the

display when you play back a CD TEXT disc*2.

*1You can connect to a CD changer or an MD

changer.

*2A CD TEXT disc is an audio CD that includes

information such as the disc name, artist name

and track names.

This information is recorded on the disc.

Warning

This equipment has been tested and found to

comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation. This

equipment generates, uses, and can radiate

radio frequency energy and, if not installed

and used in accordance with the instructions,

may cause harmful interference to radio

communications. However, there is no

guarantee that interference will not occur in a

particular installation. If this equipment does

cause harmful interference to radio or

television reception, which can be determined

by turning the equipment off and on, the user

is encouraged to try to correct the interference

by one or more of the following measures:

— Reorient or relocate the receiving antenna.

— Increase the separation between the

equipment and receiver.

— Connect the equipment into an outlet on a

circuit different from that to which the

receiver is connected.

— Consult the dealer or an experienced radio/

TV technician for help.

You are cautioned that any changes or

modifications not expressly approved in this

manual could void your authority to operate

this equipment.

CAUTION

The use of optical instruments with this

product will increase eye hazard.

Table of Contents

This Unit Only With Optional Equipment

Location of controls ................................................. 4

Getting Started

Resetting the unit ................................................ 6

Detaching the front panel .................................. 6

Setting the clock .................................................. 7

CD Player

Listening to a CD ................................................ 8

Playing a CD in various modes ........................ 9

Creating a programme

— CD Programme Memory ....................... 10

Radio

Memorising stations automatically

— Best Tuning Memory (BTM) ................. 13

Memorising only the desired stations............ 13

Receiving the memorised stations .................. 13

Storing the station names

—Station Memo ........................................... 14

Locating a station by name

— List-up ...................................................... 15

Other Functions

Using the rotary commander .......................... 16

Adjusting the sound characteristics ............... 17

Attenuating the sound ..................................... 17

Changing the sound and display settings ..... 18

Adjusting the frequency of the

subwoofer(s) ................................................. 18

CD/MD Unit

Playing a CD or MD ......................................... 19

Scanning the tracks

— Intro Scan ................................................ 20

Playing tracks repeatedly

— Repeat Play ............................................. 20

Playing tracks in random order

— Shuffle Play .............................................. 20

Creating a programme

— Programme Memory ...............................

Labeling a CD

— Disc Memo ............................................... 23

Locating a disc by name

— List-up ...................................................... 25

Selecting specific tracks for playback

— Bank .......................................................... 25

Additional Information

Precautions ......................................................... 26

Maintenance ....................................................... 27

Dismounting the unit ....................................... 28

Attaching the label to the rotary

commander ................................................... 28

Troubleshooting guide ..................................... 30

Location of controls

Refer to the pages for details.

1SEEK/AMS (seek/Automatic Music

Sensor/manual search) control

9, 10, 12, 13, 14, 20, 21, 22, 25

2MODE (band/unit select) button

13, 19, 21, 24

36(eject) button (located on the front of

the unit hidden by the front panel) 8

4SOURCE (source select) button

8, 13, 18, 19, 21, 24

5Dial (volume/subwoofer volume/bass/

treble/left-right/rear-front control)

7, 15, 17, 23, 24

6SOUND button 17

7DSPL (display mode change) button

8, 9, 14, 15, 19, 24, 25

8Display window

9OPEN button 6, 8, 27

!º LIST button

Station Memo 14, 15

Disc Memo 23, 24

List-up 15, 25

!¡ OFF button 6, 8

!™ Reset button (located on the front side

of the unit behind by the front panel) 6

!£ Receptor for the optional wireless

remote

!¢ SHIFT button

PLAY MODE 9, 10, 11, 12, 13, 14, 20, 21,

22, 23, 25, 26

REP 10, 20

SET UP 7, 9, 18, 19

SHUF 10, 20

!∞ POWER SELECT switch (located on the

bottom of the unit)

See “POWER SELECT Switch” in the

Installation/Connections manual.

!§ During radio reception:

Number buttons 13

During CD/MD playback:

Direct disc selection buttons 20, 21

MODE

OFF

SOUND

DSPL LIST

OPEN

SOURCE

SHIFT

12345678910

CDX-C680

Optional wireless

remote (RM-X47)

The buttons of the wireless remote

work the same functions as those on

this unit.

1OFF button

2SEEK/AMS button

3(–) (+) buttons

4ATT button

5SOUND/SEL button

6DSPL button

7PRESET/DISC button

You cannot do manual search and manual

tuning with the remote.

8SOURCE button

9MODE/DIR button

(MODE) controls the same function on this

unit.

When the POWER SELECT switch is set to the Bposition, the unit cannot be operated with the

wireless remote unless (SOURCE) on the unit is pressed or a CD is inserted to activate the unit

first.

OFF

SOURCE

DIR

SEL

–

REW

SOUND

–

ATT DSPL

SEEK

AMS

PRESET

DISC

MODE

Reset button

Getting Started

Resetting the unit

Before operating the unit for the first time or

after replacing the car battery, you must reset

the unit.

Press the reset button with a pointed object,

such as a ballpoint pen.

Notes

• Pressing the reset button will erase the clock and

some memorized functions.

• When you connect the power supply cord to the

unit or reset the unit, wait for about 10 seconds

before you insert a disc. If you insert a disc within

these 10 seconds, the unit will not be reset, and

you will have to press the reset button again.

Detaching the front panel

You can detach the front panel of this unit to

prevent the unit from being stolen.

1Press (OFF).

2Press (OPEN) to open the front panel,

then slide the front panel to the right

side, and pull out the left side of the

front panel.

Notes

• Do not put anything on the inner surface of the

front panel.

• Be sure not to drop the panel when detaching it

from the unit.

•If you detach the panel while the unit is still on,

the power will turn off automatically to prevent

the speakers from being damaged.

•When you carry the front panel with you, put it

in the supplied front panel case.

Attaching the front panel

Place the hole ain the front panel onto the

spindle bon the unit as illustrated, then push

the left side in.

Notes

• Be sure not to attach the front panel upside

down.

•Do not press the front panel hard against the

unit when attaching it. Press it lightly against the

unit.

•Do not press hard or put excessive pressure on

the display windows of the front panel.

•Do not expose the front panel to direct sunlight,

heat sources such as hot air ducts, and do not

leave it in a humid place. Never leave it on the

dashboard of a car parked in direct sunlight

where there may be a considerable rise in

temperature.

Caution alarm

If you turn the ignition key switch to the OFF

position without removing the front panel, the

caution alarm will beep for a few seconds

(only when the POWER SELECT switch is set

to the Aposition).

Setting the clock

The clock uses a 12-hour digital indication.

Example: Set the clock to 10:08

1Press (SHIFT), then press (3) (SET UP).

1Press (5) (n).

The hour digit flashes.

2Set the hour.

3Press (5) (n).

The minute digits flash.

4Set the minute.

2Press (SHIFT).

The clock starts.

to go forward

to go backward

to go forward

to go backward

SET UP

Getting Started

3Press (SHIFT).

After the mode setting is complete, the

display goes back to normal playback

mode.

Note

If the POWER SELECT switch on the bottom of the

unit is set to the Bposition, turn the power on

first, then set the clock.

SET UP

Changing the displayed item

Each time you press (DSPL), the item changes

as follows:

Elapsed playback time

Disc name*1/Artist name*2

Track name*1

Clock

MOTION DISPLAY*3

*1If you inserted a non-CD TEXT disc,

“NO D.Name” or “NO T.Name” appears in the

display.

*2If you play a CD TEXT disc, the artist name

appears in the display after the disc name. (Only

for CD TEXT discs with the artist name.)

*3All the items above are scrolled in the display

one by one in order.

You can label CD and CD TEXT discs with a

personalized name using the disc memo

function, refer to “Labeling a CD” (page 23).

However, if you use personalized labels, they

will always take priority over the original CD

TEXT information when such information is

displayed.

Tips

• If the name of the CD TEXT disc is too long, you

can scroll it across the display by pressing

(SHIFT), then (2) (N).

• If you want to display the original CD TEXT

information after labelling the CD TEXT disc with

a personalized name, press (SHIFT), then (5)

(n).

Automatically scrolling a disc name

— Auto Scroll

If the disc name/artist name or track name on

a CD TEXT disc exceeds 10 characters and the

Auto Scroll function is on, automatically

scrolls on the display as follows:

• The disc name appears when the disc has

changed (if the disc name is selected).

• The track name appears when the track has

changed (if the track name is selected).

Track number

Elapsed playing time

Labelled side up

TRACK

CD Player

Listening to a CD

1Press (OPEN) and insert the CD.

2Close the front panel.

Playback starts automatically.

If a CD is already inserted, press (SOURCE)

repeatedly until “CD” appears.

Note

To play back an 8 cm (3 in.) CD, use the optional

Sony compact disc single adapter (CSA-8).

To Press

Stop playback (OFF)

Eject the CD (OPEN) then 6

If you press (DSPL) to change the display

item, the disc or track name of the CD TEXT

disc is scrolled automatically whether you set

the function on or off.

1During playback, press (SHIFT).

2Press (3) (SET UP) repeatedly until

“A.Scrl” appears.

3Press (5) (n) to select “A.Scrl on.”

4Press (SHIFT)

To cancel Auto Scroll, select “A.Scrl off” in

step 2 above.

Note

For some CD TEXT discs with extremely many

characters, the following cases may happen:

— Some of the characters are not displayed.

— Auto Scroll does not work.

Locating a specific track

— Automatic Music Sensor (AMS)

During playback, push the SEEK/AMS

control up or down momentarily.

Locating a specific point in a track

— Manual Search

During playback, push the SEEK/AMS

control up or down and hold.

Release when you have found the

desired point.

Note

If “ ” or “ ” appears in the display,

that means you have reached the beginning or the

end of the disc and you cannot go any further.

To locate

preceding tracks

To locate succeeding

tracks

To search backward

To search forward

CD Player

SHIFT

12345678910

SET UP PLAY MODE

REP SHUF

Playing a CD in various

modes

You can play CDs in various modes:

•Intro (Intro Scan) lets you play the first 10

seconds of all the tracks.

•Repeat (Repeat Play) repeats the current

track.

•Shuf (Shuffle Play) plays all the tracks in

random order.

Searching for the desired track

— Intro scan

1Press (SHIFT).

Every time you press (SHIFT), only the

items you can select light up.

2Press (4) (PLAY MODE) repeatedly until

“Intro” appears.

Each time you press (4) (PLAY MODE),

the item changes as follows:

Intro ˜PGM

3Press (5) (n) to select “Intro on.”

Intro Scan starts.

4Press (SHIFT).

To go back to normal playback mode, select

“Intro off” in step 3 above.

PLAY MODE

Creating a programme

— CD Programme Memory

You can play the tracks in the order you want

by making your own programme. You can

make two programmes: Programme 1 and

Programme 2. You can select up to 12 tracks

for each programme. You can store the

programmes in memory.

1Press (SHIFT), then press (4) (PLAY

MODE) for two seconds.

“P 1” shows Programme 1 is selected.

To select Programme 2, press (5) (n)

repeatedly until “P 2” appears.

2Push the SEEK/AMS control up or down

to select the track you want.

3Press (6) (ENTER) momentarily.

4To continue entering tracks, repeat steps

2 and 3.

5When you finish selecting tracks, press

(4) (PLAY MODE) for two seconds.

6Press (SHIFT).

Notes

•“*Wait*” appears in the display while the unit is

reading the data.

•“*Mem Full*” appears in the display when you

try to enter more than 12 tracks into a

programme.

PLAY

TRACK

MODE ENTER

PLAY MODE ENTER

PLAY

TRACK

MODE ENTER

Playing tracks repeatedly

— Repeat Play

1During playback, press (SHIFT).

2Press (7) (REP) repeatedly until ”Repeat

1“ appears.

Repeat Play starts.

3Press (SHIFT).

To go back to normal playback mode, select

“Repeat off” in step 2 above.

Playing tracks in random order

— Shuffle Play

1During playback, press (SHIFT).

2Press (8) (SHUF) repeatedly until ”Shuf

1“ appears.

Shuffle Play starts.

3Press (SHIFT).

To go back to normal playback mode, select

“Shuf off” in step 2 above.

DSPL

SHIFT

1234567891

SET UP PLAY MODE

REP SHUF

DSPL PT

AF/

SHIFT

12345678910

SET UP PLAY MODE

REP SHUF

Autres manuels pour CDX-C680

Table des matières

Autres manuels Sony Lecteur CD

Sony

Sony ICF-CD73V Manuel utilisateur

Sony

Sony CFD-S26 - Cd Radio Cassette-corder Manuel utilisateur

Sony

Sony CFD-E75L Manuel utilisateur

Sony

Sony CFD-DW83 - Cd Stereo Am/fm Cassette Recorder Manuel utilisateur

Sony

Sony CDP-C331 - Compact Disc Player Manuel utilisateur

Sony

Sony Walkman D-E888 Manuel utilisateur

Sony

Sony CFD-S03CPL Manuel utilisateur

Sony

Sony Discman D-E440 Manuel utilisateur

Sony

Sony CDX-1300 - Fm/am Compact Disc Player Guide produit

Sony

Sony CDX-MP30 Guide produit

Sony

Sony Walkman MZ-RH710 Manuel utilisateur

Sony

Sony Walkman D-CJ506CK Manuel utilisateur

Sony

Sony CFD-S28L Manuel utilisateur

Sony

Sony CFD-ZW705 - Cd Radio Cassette-corder Manuel utilisateur

Sony

Sony CDP-CA70ES - Compact Disc Player Manuel utilisateur

Sony

Sony CD Walkman D-FJ200 Manuel utilisateur

Sony

Sony CD Walkman D-EQ550 Manuel utilisateur

Sony

Sony CDX-GT627UV Manuel utilisateur

Sony

Sony CDX-454RF - Compact Disc Changer System Guide produit

Sony

Sony Walkman D-NE711 Manuel utilisateur

Sony

Sony CFD-S550 - Cd Radio Cassette-corder Manuel utilisateur

Sony

Sony CFD-S38 - Cd Radio Cassette-corder Manuel utilisateur

Sony

Sony CDP-CX333ES - Es 300 Disc Cd Changer Manuel utilisateur

Sony

Sony D-E451 Primary Manuel utilisateur

Manuels Lecteur CD populaires d'autres marques

RCA

RCA RP-7923 Manuel utilisateur

Pioneer

Pioneer DEH-P3550MP XM Manuel utilisateur

Philips

Philips AZ1207 Manuel utilisateur

Philips

Philips CD582 Manuel utilisateur

Philips

Philips AZ 6821 Manuel utilisateur

Lasonic

Lasonic MSU-2020 Manuel utilisateur

THOMSON

THOMSON RCD150 Manuel utilisateur

Denon

Denon DCD-1420 Manuel utilisateur

Panasonic

Panasonic SJ-MR100 Manuel utilisateur

Onkyo

Onkyo DX-7210 Manuel utilisateur

Denon

Denon DVM-4800 Manuel utilisateur

JBL

JBL MR-32 Manuel utilisateur

RCA

RCA RCD152 Manuel utilisateur

Technics

Technics SL-PS770A Manuel utilisateur

Clarion

Clarion compact disc Manuel utilisateur

Philips

Philips Expanium AZ 1538 Manuel utilisateur

Rotel

Rotel RCD 975 Manuel utilisateur

Pioneer

Pioneer CLD-D790 Manuel utilisateur
