Enjoy the crisp and clear sound of your MP3/WMA/AAC1 les with CD or control
your digital music using the USB 1-wire on your Sony® CDX-GT65UIW. Flip down the
2-line LCD face plate for CD access and customize your stereo with Dynamic Color
Illuminator.
Specications
CDX-GT65UIW CDX-GT65UIW CD Receiver with USB input
Bullets
• Dynamic Color Illuminator with Sound Synchronization
• Detach face with 2-line LCD display and front aux input
• Front USB input for iPod®2, iPhone® & USB music players
• MP3/WMA/AAC1 playback with DM+ enhancement technology
• Intuitive Quick-BrowZer® and ZAPPIN™ search features
• Advanced Sound Engine and 52 Watts x 4 High Power
• Satellite Radio/HD Radio™ ready3
• 2 Volt Front, Rear and Sub pre-amp output with LPF/HPF
• Radio Data System (RDS)
• Wireless card remote included (RM-X151)
Amplier Section
Max power output 52 watts x 4 at 4 ohms
Power Ad Hoc CEA2006 Standard Power: 17 Watts RMS per channel into 4 Ohms, 4 channels driven from 20 Hz to 20
kHz with less than 1% THD+N.
Speaker Impedance 4-8 Ohms
AMP & General Feature
Aux-In Yes (Front)
DM+ (Codec enhancer) Yes(Gen2.1)
EQ EQ7: 7 band EQ with +/- 6 dB adjustment at 63 Hz, 160 Hz, 400 Hz, 1000 Hz, 2.5 kHz, 6.3 kHz and 16
kHz.
High Pass Filter Selectable on/o at: 50, 60, 80, 100 or 120 Hz.
Loudness Dynamic Loudness
Low Pass Filter Selectable on/o at: 50, 60, 80, 100 or 120 Hz.
Output Power (4ohm, 1kHz,16V)(W) 52 watts x 4
Pre Out (3) Front, Rear and Sub
Rear Bass Enhancer Yes
Sub Out Yes
TEL ATT/Navi ATT Yes
Time Alignment Custom Yes (Adjustment)
Time Alignment Preset Yes
USB Yes (Front)
Audio
Band AM / FM
Equalizer EQ7: 7 band EQ with +/- 6 dB adjustment at 63 Hz, 160 Hz, 400 Hz, 1000 Hz, 2.5 kHz, 6.3 kHz and 16
kHz.
Format(s) Supported MP3/WMA/AAC les1
Preout Impedance 220 ohms
Preout Voltage 2 volt
S/N Ratio Audio Power: CEA2006 S/N 80 dBA
Signal-to-Noise Ratio (dB) CD: 120 dB
Station Preset(s) 18 FM / 12 AM
Tuner Frequency Range FM (MHz): 87.5-107.9
AM (kHz): 530-1710
Tuner Type SSIR-EXA with RDS
Volume Control Tel/Nav Attenuation
Wow and Flutter Below measurable limit
AUX in Feature
Level Adjustment Yes (-8dB / +18dB)
Convenience
Tilt Range 0-45° mounting angle
Convenience Features
Dimmer Adjust Selectable Auto adjust or manual on/o
Key Illumination Variable color illumination
On-Screen Clock 12H
Display
Display Color Black / Variable color
Display Technology LCD
Text Displayed Source, artist, track, playback time, menu and clock
Text Lines 2 lines of information
Display Panel
Auto o mode Yes
Dimmer Adjust Auto
Key Illumination Initial RAINBOW
Panel Design
Display color (Color Variation/Nega or Posi) Black color / Negative
Display Device (LCD/FL/OEL/TFT) LCD
Key Illumination Variable
Panel nish color Dark Titanium
USB Shutter Yes
Feature
CODEC (for USB) MP3, WMA, AAC1
Jump Mode Yes
List Browsing (Folders/Files) Yes
Pause Yes
Repeat OFF/ TRACK/ ALBUM
Resume Play Yes
Shue OFF/ALBUM/DEVICE
ZAPPIN Yes
General
CEA2006 output power 17
CEA2006 S/N 80
Dimensions (WxHxD) (mm) 178x50x180
Maximum output power (4ohm, 1kHz, 16V)(W) 52
Mounting dimensions (WxHxD)(mm) 182 x 53 x 162
Preout impedance (ohms) 220
Preout output level (V) 2
Weight (kg) 1.3
Inputs and Outputs
12V Trigger Output(s) Power antenna and amplier turn on
Antenna Terminal(s) AM/FM Antenna Input Terminal
Audio In Front Aux in with variable level
Front USB input
Sony Bus terminal
Digital Audio Input(s)
Ability to use all forms of USB devices may vary as not all devices are compatible. This unit is compliant
with MSC (Mass Storage Class) and MTP (Media Transfer Protocol) type USB devices compliant with the
USB standard. This unit cannot recognize USB devices via a USB hub.
This unit can be connected to the following iPods. Update your iPod to the latest software before you
use it.
iPod Nano 1st - 6th generation
iPod Touch 1st - 4th generation
iPod Classic
iPod with video
iPhone
iPhone 3G
iPhone 3GS
iPhone 4
If you have any questions or problems concerning your unit that are not covered in the owners
manual, consult your nearest Sony dealer.
Infrared Port Wireless remote
RCA Audio Output(s) Front, Rear and Subwoofer RCA pre-amp outputs
Remote Jack Optional wired remote terminal
USB Port(s) Front
iPod Control Feature
Accessory Information Yes
CODEC (for iPod) depend on iPod content
List Browsing (Folders / Files) Quick-BrowZer®
Passenger Control Yes
Pause Yes
Repeat Yes (Track, Album, Artist, Playlist, Genre, Podcast)
Resume Play Yes
Shue Yes (Genre, Album, Artist, Playlist, Device, Podcast)
ZAPPIN Yes
USB Capable
USB Mass Storage Device Yes
Other Features
Card Remote ( ): Option RM-X151
CD lock mode Yes
Clock 12H
Rotary commander ( ):Option (RM-X4S)
Security Detachable
Sub panel illumination color Red
Sony Bus Control
Sony Bus Yes
Tuner
FM Usable Sensitivity 10 dBf
Frequency Response FM: 20-15,000 Hz
S/N Ratio 70 dB (stereo)
Selectivity 75 dB at 400 kHz
Stereo Separation 40 dB at 1 KHz
FM: Channel separation (dB) 40 dB at 1 kHz
FM: Frequency response (Hz) 20 - 15k
FM: Intermediate frequency (MHz) 25 KHz
FM: S/N ratio (mono) (dB) 70 dB stereo
FM: Selectivity (400 kHz) (dB) 75 dB
FM: Tuning range (MHz) 87.5-107.9
FM: Usable sensitivity (75 ohm) (dBf) 10 dBf
MW: Tuning range(kHz) 530-1710
MW/LW/SW: Sensitivity (75 ohm) MW/LW/SW(uV) 26/-/-
Tuner Feature
Preset FM18/AM12
RDS/EON (NA Only:RBDS, Others:RDS) Yes (RBDS)
Weights and Measurements
Dimensions (Approx.) 178 x 50 x 180 mm, 7.125 x 2 x 7.125 inch (w/h/d)
Dimensions (Approx) Depth 7.125" (180 mm)
Dimensions (Approx) Height 2" (50 mm)
Dimensions (Approx) Width 7.125" (178 mm)
Weight (Approx.) 1.3 kg (2 lb. 14 oz.)
Supplied Accessories
Supplied Accessories Parts for installation and connections (1 set)
RM-X151 wireless remote
Optional Accessories
Optional Accessories
USB Connection Cable for iPod®: RC-100IP
HD Radio® tuner: XT-100HD
Source selector: XA-40C
1. Copy-protected content not supported.
2. Works with iPod touch® 1st - 4th generation, iPod nano® 1st - 6th generation, iPod classic®, iPod® with video, and iPhone® 3G, 3GS and 4.
3. Requires antenna and tuner, both sold sep.
© 2011 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, ZAPPIN, SensMe, Walkman, Quick-BrowZer and their respective logos are trademarks
of Sony. iPod, iPod classic, iPod nano, and iPhone are trademarks of Apple Inc. All other trademarks are trademarks of their respective owners. Features and specications are subject to change without notice.
Updated: September 9, 2011
