Operating Instructions

Manual de instrucciones

#####

XR-1940

FM/AM

Cassette Car

Stereo

For installation and connections, see the supplied installation/connections

manual.

Con respecto a la instalación y las conexiónes, consulte el manual de Instalación/

conexiones suministrado.

#####

Actual total number: Sony XR-1940 (E,S,C) 3-856-691-42 (1)

Table of contents

Getting Started

Setting the clock .................................................. 4

Cassette player

Listening to the tape ........................................... 4

Radio

Memorizing stations automatically

— Automatic Memory .................................. 5

Memorizing only the desired stations ............. 6

Receiving the memorized stations .................... 6

Other Functions

Adjusting the sound characteristics ................. 7

Changing the sound and display settings ....... 7

Additional Information

Precautions ........................................................... 7

Maintenance ......................................................... 8

Dismounting the unit ......................................... 9

Location of controls .......................................... 10

Specifications ..................................................... 11

Troubleshooting guide ..................................... 12

Welcome!

Thank you for purchasing the Sony Cassette

Car Stereo. This unit lets you enjoy a variety of

features.

Actual total number: Sony XR-1940 (E,S,C) 3-856-691-42 (1)

6666

3333

Cassette Player

Listening to the tape

Insert the cassette.

Playback will start automatically.

The side facing up is being played.

The side facing down is being played.

Tip

To change the tape transport direction, press both 0and

)at the same time.

To eject the cassette, press 6.

Fast-winding the tape

To resume playback, press the other fast-

winding button partially until the locked

button is released.

Tip

9and (flashs while fast-winding the tape.

Direction

indicator

(

Fast-forward

Rewind

Getting Started

Setting the clock

The clock has a 12-hour digital indication.

Note

Turn the power on first, then set the clock.

To turn the power on, press (TUNER).

Example : Set the clock to 10:08

1Display the time.

press (DSPL) during operation.

2Press (DSPL) for two seconds.

1Set the hour.

2Press (SEL) momentarily.

3Set the minute.

3Press (DSPL) momentarily.

1000

The minute digits flash.

to go back to go forward

1008

100

The hour digit flashes.

1000

to go back to go forward

1008

The clock starts.

Actual total number: Sony XR-1940 (E,S,C) 3-856-691-42 (1)

Changing the displayed items

Each time you press (DSPL) momentarily

during tape playback, the displayed item

changes as follows:

Tape playback ˜Clock

Radio

Memorizing stations

automatically

— Automatic Memory

The unit selects the stations with clearst

reception and memorises them. You can store

up to 6 stations on each band (FM1, FM2, FM3,

AM1 and AM2).

Caution

When tuning in the station while driving, use

Automatic Memory to prevent accidents.

1Press (TUNER) repeatedly to select the

desired band (FM1, FM2, FM3, AM1 and

AM2).

2Press (A.MEM/M.SCAN) for two seconds.

The unit stores stations on the number

buttons.

Notes

• The unit will not store stations with weak signals. If

there are only a few stations that you can receive, the

stations stored before will remain on the other number

buttons.

• When a preset number is indicated in the display , the

unit starts storing stations from the one currently

displayed.

Getting Started/Cassette Player/Radio

Actual total number: Sony XR-1940 (E,S,C) 3-856-691-42 (1)

Receiving the memorized

stations

1Press (TUNER) repeatedly to select the

desired band.

2Press the number button ((1) to (6))

momentarily where the desired station is

stored.

Tip

Press (A.MEM/M.SCAN) momentarily to receive in order

the stations stored in the memory (Memory scan

Function).

If you cannot tune in a preset

station

Press either side of (SEEK/MANU)

momentarily to search for the station

(automatic tuning).

Scanning stops when the unit receives a

station. Press either side of (SEEK/MANU)

repeatedly until the desired station is

received.

Note

If the automatic tuning stops too frequently, press

(LOUD/SENS) momentarily until “LCL” (local seek mode)

appears in the display. Only the stations with relatively

strong signals will be tuned on.

Tip

If you know the frequency of the station you want to listen

to, press and hold either side of (SEEK/MANU) until the

desired frequency appears (manual tuning).

If FM stereo reception is poor

— Monaural mode

Press (LOUD/SENS) momentarily until

“MONO” appears.

The sound improves, but it will becomes

monaural (“STEREO” disappears).

Changing the displayed items

Each time you press (DSPL), the item changes

as follows:

Frequency ˜Clock

Memorizing only the

desired stations

You can store up to 6 stations on each band (18

for FM1, FM2 and FM3, 12 for AM1 and AM2)

in order of your choice.

1Press (TUNER) repeatedly to select the

desired band.

2Press either side of (SEEK/MANU) to tune

in the station that you want to store on

the number button.

3Keep the desired number button ((1) to

(6)) pressed for two seconds until you

hear a beep tones.

The number button indication appears in the

display.

Note

If you try to store another station on the same number

button, the previously stored station will be erased.

Actual total number: Sony XR-1940 (E,S,C) 3-856-691-42 (1)

Additional

Information

Precautions

•If your car was parked in direct sunlight

resulting in a considerable rise in

temperature inside the car, allow the unit to

cool off before operating it.

•If no power is being supplied to the unit,

check the connections first. If everything is in

order, check the fuse.

•If no sound comes from the speakers of a

2-speaker system, set the fader control to the

center position.

•When the tape is played back for a long

period, the cassette shell may become warm

because of the built-in power amplifier.

However, this is not a sign of a malfunction.

If you have any questions or problems

concerning your unit that are not covered in

this manual, please consult your nearest Sony

dealer.

To maintain high quality sound

If you have drink holders near your audio

equipment, be careful not to splash juice or

other soft drinks onto the car audio. Sugary

residues on this unit or cassette tapes may

contaminate the playback heads, reduce the

sound quality, or prevent sound reproduction

altogether.

Cassette cleaning kits cannot remove sugar

from the tape heads.

Other Functions

Adjusting the sound

characteristics

You can adjust the bass, treble, balance and

fader.

1Select the item you want to adjust by

pressing (SEL) repeatedly.

To adjust bass or treble, press (SEL)

repeatedly until “BAS“ or “TRE“ flashes.

BAS (bass) nTRE (treble)

nBAL (balance) nFAD (fader)

nVOL (volume)

2Adjust the selected item by pressing (+)

or (–).

Adjust within three seconds after selecting.

(After three seconds the buttons work as

volume control buttons.)

Changing the sound and

display settings

Enjoying bass and treble even at

low volume — Loudness

Bass and treble will be reinforced.

Press (LOUD/SENS) for two seconds.

“LOUD” appears.

To cancel, press (LOUD/SENS) for two seconds

again.

Turn off the beeps

Press (6) while pressing (SEL).

To obtain the beeps again, press these

buttons again.

Radio/Other Functions/Additional Information

Actual total number: Sony XR-1940 (E,S,C) 3-856-691-42 (1)

Notes on Cassettes

Cassette care

•Do not touch the tape surface of a cassette, as

any dirt or dust will contaminate the heads.

•Keep cassettes away from equipment with

built-in magnets such as speakers and

amplifiers, as erasure or distortion on the

recorded tape could occur.

•Do not expose cassettes to direct sunlight,

extremely cold temperatures or moisture.

•Slack in the tape may cause the tape to be

caught in the machine. Before you insert the

tape, use a pencil or similar object to turn the

reel and take up any slack.

•Distorted cassettes and loose labels can cause

problems when inserting or ejecting tapes.

Remove or replace loose labels.

Cassettes longer than 90 minutes

The use of cassettes longer than 90 minutes is

not recommended except for long continuous

play. The tapes used for these cassettes are

very thin and tend to be stretched easily.

Frequent playing and stopping of these tapes

may cause them to be pulled into the cassette

deck mechanism.

Maintenance

Fuse Replacement

When replacing the fuse, be sure to use one

matching the amperage rating stated on the

fuse. If the fuse blows, check the power

connection and replace the fuse. If the fuse

blows again after replacement, there may be

an internal malfunction. In such a case, consult

your nearest Sony dealer.

Replace the fuse on the rear of the unit.

Warning

Never use a fuse with an amperage rating

exceeding the one supplied with the unit as

this could damage the unit.

Slack Fuse (10 A)

Actual total number: Sony XR-1940 (E,S,C) 3-856-691-42 (1)

Dismounting the unit

1While pushing in on the left side of the

front cover, insert the tip of a thin

screwdriver as shown in the illustration,

then pry off the front cover.

Thin screwdriver

(Be careful to not break the front cover.)

2Repeat step 1 on the right side. Then the

front cover will be removed.

3Use a thin screwdriver to push in the clip

on the left side of the unit, then pull out

the left side of the unit until the catch

clears the mounting.

4Repeat step 3 on the right side.

5 Slide the unit out of the mounting.

Additional Information

Actual total number: Sony XR-1940 (E,S,C) 3-856-691-42 (1)

DSPL

SEEK

MANU

SENS

M.SCAN

A.MEM

TUNER OFF

DIR

61 2 3 4 5

SEL

LOUD

Location of controls

Refer to the pages for further details.

1Display window

2SEL (control mode select) button 4, 7

3DSPL (display mode change/time set)

button 4, 5, 6, 7

46(eject) button 4

5During radio reception:

Preset number buttons 6

60/)(fast winding)/DIR (tape

transport direction change) buttons 4

7(+)(–) (volume/bass/treble/balance/

fader control) button 7

8SEEK/MANU button 6

9LOUD (loudness)/SENS (sensitivity

adjust) button 6, 7

!º A.MEM (automatic memory)/M.SCAN

(Memory scan) 5, 6

!¡ TUNER (radio on/band select) button

5, 6

!™ OFF button

!£ Frequency select switch (located on the

bottom of the unit)

See “Frequency select switch“ in the

Installation/Connections manual.

Table des matières

Langues :

Autres manuels Sony Récepteur de voiture

Sony

Sony HCD-V818 Manuel utilisateur

Sony

Sony ST-S5 Manuel utilisateur

Sony

Sony CDX-C90R Manuel utilisateur

Sony

Sony XR-C8220 Guide produit

Sony

Sony ST-S222ES Manuel utilisateur

Sony

Sony CDX-M8800 - Fm/am Compact Disc Player Guide produit

Sony

Sony DSX-M50BT Manuel utilisateur

Sony

Sony HCD-HX50BTR Manuel utilisateur

Sony

Sony CDX-F5510 (XT-XM1) Manuel utilisateur

Sony

Sony CDX-GS500R Manuel utilisateur

Sony

Sony CDX-MP50 Guide produit

Sony

Sony XR-C2200 Manuel utilisateur

Sony

Sony WX-4500X Installation/Connections Guide produit

Sony

Sony CDX-M20 Guide produit

Sony

Sony CDX-GT780UI Guide produit

Sony

Sony CDX-R5515X - Fm/am Compact Disc Player Manuel utilisateur

Sony

Sony CDX-GT10W - Fm/am Compact Disc Player Manuel utilisateur

Sony

Sony CDX-S2010 - Fm/am Compact Disc Player Guide produit

Sony

Sony XR-CA600X - Fm/mw/sw Cassette Car Stereo Manuel utilisateur

Sony

Sony CDX-555RF Operating Instructions... Guide produit

Sony

Sony CDX-GT720 - Fm/am Compact Disc Player Guide produit

Sony

Sony HCD-DR4 Manuel utilisateur

Sony

Sony CDX-GT930UI - Fm/am Compact Disc Player Guide produit

Sony

Sony Xplod CDX-GT430IP Manuel utilisateur

Manuels Récepteur de voiture populaires d'autres marques

Motorola

Motorola VWA63 Manuel utilisateur

Nextar

Nextar D3201 Manuel utilisateur

Alpine

Alpine CDE-163BT Manuel utilisateur

Pioneer

Pioneer DEH-P645R Manuel utilisateur

Axxera

Axxera XDMA7600 Mode d'emploi

XM OnyX Manuel utilisateur

Sound Storm

Sound Storm STM93R Manuel utilisateur

Soundstream

Soundstream VIR-5000 Manuel utilisateur

Avson

Avson MKT Platform Manuel utilisateur

Pioneer

Pioneer DVH-P500UB Manuel utilisateur

JVC

JVC KD-AHD69 Manuel utilisateur

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manuel utilisateur

XFIRE AUDIO

XFIRE AUDIO BMW42S Manuel utilisateur

VDO

VDO CD 2253 Manuel utilisateur

Volvo

Volvo 13 84 580 Manuel utilisateur

ZENEC

ZENEC ZE-160DVD Manuel utilisateur

Medion

Medion Car Audio Manuel utilisateur

Philips

Philips CEM5000 Manuel utilisateur
