Sony XAV-AX7000 Guide de référence

Help Guide

In-Car Receiver

XAV-AX7000

Use this manual if you encounter any problems, or have any questions.

Getting Started

Guide to Parts and Controls

Main Unit and Remote Commander

Screen Displays

Performing Initial Settings

Preparing a BLUETOOTH Device

Preparing a Bluetooth® Device

Pairing and Connecting with a BLUETOOTH Device

Connecting with a Paired BLUETOOTH Device

Connecting Rear View Camera

Radio

Listening to the Radio

Listening to the Radio
Tuning
Using Tuner Option Functions
Listening to the SiriusXM Radio
Listening to the SiriusXM Radio
Tuning Channels for SiriusXM
Tuning the Channel by Inputting its Channel Number
Tuning the Channel from the Channel List or Category List
Setting a Parental Control
Using SXM Option Functions
Playback
Playing a USB Device
Playing a USB Device
USB Port 1 and USB Port 2
Playing a BLUETOOTH Device
Searching and Playing Tracks
Repeat Play and Shuffle Play
Searching for a File from the List Screen
Other Settings During Playback
Handsfree Calling
Preparing a Mobile Phone
Receiving a Call
Making a Call
Available Operations During a Call
Useful Functions
Apple CarPlay
Android Auto™
Using Gesture Command
Settings
2

Basic Setting Operation
General Settings (General)
Sound Settings (Sound)
Visual Settings (Visual)
BLUETOOTH Settings (Bluetooth)
Additional Information
Canceling the Demonstration Mode
Updating the Firmware
Precautions
Supported Formats for USB Playback
About iPhone
Notice on License
Maintenance
Specifications
Copyrights
Troubleshooting
Troubleshooting
General
There is no beep sound.
The fuse has blown./The unit makes noise when the position of the ignition is switched.
The display disappears from/does not appear on the monitor.
Menu items cannot be selected.
The USB functions do not work properly.
The unit cannot be operated.
The clock set automatically is not accurate.
Touch panel
The touch panel does not react to your touch correctly.
Multi-touch is not recognized.
Radio
The radio reception is poor./Static noise occurs.
3

RDS
PTY displays [PTY not found.].
There is no picture/picture noise occurs.
The picture does not fit in the screen.
Sound
There is no sound/sound skips/sound cracks.
Sound is noisy.
USB playback
Items cannot be played.
The USB device takes longer to play.
Audio files cannot be played.
Operations cannot be performed.
BLUETOOTH
The other BLUETOOTH device cannot detect this unit.
Connection is not possible.
The name of the detected device does not appear.
There is no ringtone.
The talker’s voice volume is low.
The other party says that the volume is too low or high.
Echo or noise occurs during call conversations.
The phone sound quality is poor.
The volume of the connected BLUETOOTH device is low or high.
The sound skips during audio streaming or the BLUETOOTH connection fails.
The connected BLUETOOTH device cannot be controlled during audio streaming.
Some functions do not work.
A call is answered unintentionally.
Pairing failed due to time out.
Cannot pair.
The BLUETOOTH function cannot be operated.
4

No sound is output from the car speakers during a handsfree call.

SiriusXM Connect Vehicle Tuner

A mature channel is not blocked although parental control setting has been made.

Apple CarPlay

The Apple CarPlay icon does not appear on the HOME screen.

Android Auto

The Android Auto icon does not appear on the HOME screen.

Messages

General

BLUETOOTH

SiriusXM Connect Vehicle Tuner

Customer Support Websites

About the “Support by Sony” App

Help Guide

In-Car Receiver

XAV-AX7000

Main Unit and Remote Commander

Main unit

The VOL (volume) + button has a tactile dot.

RM-X170 remote commander

The remote commander can be used to operate the audio controls. For menu operations, use the touch panel.

Note

The white buttons in the illustration above are not supported.

Remove the insulation film before use.

Display/touch panel1.

HOME

Displays the HOME screen.

STANDBY

Press and hold to turn the unit to standby mode (USB charging is still available).

To resume, press any button.

VOL (volume) +/–3.

Receptor for the remote commander4.

OPTION

Displays the OPTION screen.

ATT (attenuate)

Press and hold for 1 second to attenuate the sound.

To cancel, press and hold again, or press VOL (volume) +.

/ (previous/next)

Functions differently depending on the selected source:

Tuner: select a preset station.

SiriusXM: select a preset channel.

USB: move to the previous/next file.

BT Audio: move to the previous/next file.

Press and hold to:

Tuner: tune into a station automatically (SEEK+/SEEK–).

USB: fast-reverse/fast-forward.

BT Audio: fast-reverse/fast-forward.

VOICE

Activates the voice command function for Apple CarPlay and Android Auto.

OFF

Turns the source off.

MONITOR OFF

Turns off the monitor.

To turn back on, press again.

EQ (equalizer)

Selects an equalizer curve.

10.

Number buttons (0 to 9)11.

CLEAR12.

ATT (attenuate)

Attenuates the sound. Press again to cancel the attenuation.

13.

(play/pause)14.

/ (previous/next)

/ (fast-reverse/fast-forward)

Functions differently depending on the selected source:

Tuner: select a preset station.

SiriusXM: select a preset channel.

USB: move to the previous/next file.

BT Audio: move to the previous/next file.

Press and hold to:

Tuner: tune into a station automatically (SEEK+/SEEK–).

USB: fast-reverse/fast-forward.

BT Audio: fast-reverse/fast-forward.

15.

/ / / (left/up/down/right)

Functions differently depending on the selected source.

Tuner: select a preset station or tune into a station automatically.

SiriusXM: select a preset channel or move to the previous/next channel.

16.

Related Topic

Screen Displays

USB: select a folder or move to the previous/next file.

ENTER

Enters the selected item.

SRC (source)

Changes the source. Each time you press this button, a selectable source is displayed in a popup on the current

display.

17.

MODE

Selects the radio band.

18.

Help Guide

In-Car Receiver

XAV-AX7000

Screen Displays

Playback screen:

HOME screen:

OPTION screen:

1. Status indication

Icon in the

display Detail

(attenuate) Lights up when the sound is attenuated.

(SiriusXM) Indicates the signal strength status of the connected SiriusXM Connect Vehicle Tuner.

(BLUETOOTH) Lights up when the BLUETOOTH signal is on. Flashes when the connection is in progress.

2. (source option)

Opens the source option menu. The available items differ depending on the source.

3. Application specific area

Displays playback controls/indications or show the unit’s status. Displayed items differ depending on the source.

4. Clock

Displays the time which are set on the Date/Time setting.

5. (return to the playback screen)

Switches from the HOME screen to the playback screen.

6. Sources and Settings select keys

Changes the source or make various settings.

Flick to select the setting icon and other icons.

7. Sound select keys

Changes the sound.

8. ( EXTRA BASS )

Changes the EXTRA BASS setting.

9. ( EQ10/Subwoofer )

Changes the EQ10/Subwoofer setting.

Icon in the

display Detail

(audio)

Lights up when the audio device is playable by enabling the A2DP (Advanced Audio Distribution

Profile).

(mobile phone) Lights up when handsfree calling is available by enabling the HFP (Handsfree Profile).

(antenna) Indicates the signal strength status of the connected mobile phone.

(battery) Indicates the remaining battery status of the connected mobile phone.

Icon in the display Name

Android Auto

Apple CarPlay

Tuner

SXM

BT Audio

Phone

USB port 1

USB port 2

Rear Camera

Settings
