remotely controlled,

clearly focused

Sony PTZ Camera Series

If you thought exceptional picture quality and camera control wasn’t

remotely possible, Sony’s Pan/Tilt/Zoom cameras will change your

mind. From video conferencing to distance learning, from worship

to sporting events, from telemedicine to patient consulting, there’s a

Sony remotely controlled PTZ camera that puts you clearly right in the

middle of the action, with legendary reliability, picture quality and

autofocus accuracy that set the Sony PTZ cameras apart.

Our expanded line of SD and HD models meets your needs with 10x to

28x optical zoom options and mounting ﬂexibility. The dynamic 1080p

and 1080i models offer unprecedented clarity and resolution, ideal

for small to large spaces in a variety of government, corporate, studio,

educational, medical and house of worship applications. Every model

offers the VISCA™protocol created by Sony, with a host of convenient

features in a sleek design.

Test out these amazing cameras that you

control remotely for close-up access.

EVI-D80

EVI-D80/W

18x SD Pan/Tilt/Zoom Color Video

Cameras

1/4-type CCD sensor

Video output:VBS (RCA jack) and

Y/C (4 pin MiniDIN)

High zoom ratio AF lens: 18x optical,

12x digital

Excellent low light sensitivity:

Minimum illumination 0.4 lux (F1.4, 50IRE)

Auto focus

Alarm function

Wide-range, quiet and quick

pan/tilt/zoom mechanism:

•

Pan: -170º to +170º

(max. speed 100º/second)

•

Tilt: -20º to +90º

(max. speed 90º/second)

Backward compatible D70 mode

Desktop or ceiling mountable with

E:Flip function

Available in white or black housing

Optional VISCA RM-BR300 Controller

EVI-D90

EVI-D90/W

28x SD Pan/Tilt/Zoom

Color Video Cameras

1/4-type ExView HAD CCD®sensor

Progressive or interlace scan option

Video output:VBS (RCA jack) and

Y/C (4 pin MiniDIN)

Excellent low light sensitivity:

Minimum illumination 0.65 lux

(F1.35, 50IRE)

High zoom ratio AF lens: 28x optical,

12x digital

Wide D function (Auto Wide-D)

Image stabilizer function

Auto ICR function

Auto focus

Alarm function

Wide-range, quiet and quick

pan/tilt/zoom mechanism:

•

Pan: -170º to +170º

(max. speed 100º/second)

•

Tilt: -20º to +90º

(max. speed 90º/second)

Backward compatible D70 mode

Desktop or ceiling mountable with

E:Flip function

Available in white or black housing

Optional VISCA RM-BR300 Controller

SD Cameras

BRC-300

3-CCD Pan/Tilt/Zoom

Color Video Camera

Optional RM-BR300 Controller

1/4.7-type CCD x 3 image sensor

Superb picture quality

Horizontal resolution - 600 TV lines

Minimum illumination – 7 lx

Supports SD output as standard

Optional interface card slot for SDI, i.Link™

DV interface,ﬁber and RGB capability

NTSC image format

12x optical, 4x digital zoom lens

Fully remote controllable via

RS-232C/RS-422 (VISCA protocol)

Optional VISCA RM-BR300 Controller

Wide-range, quiet and

quick pan/tilt mechanism:

•Pan: -170° to +170°

(max. speed 60°/second)

• Tilt: -30° to +90°

(max. speed 60°/second)

4:3/16:9 aspect selectable

(16:9 precision technology)

Desktop or ceiling mountable with

E:Flip function

a camera for every occasion

BRC-H900

1080i 3 CMOS HD

Pan/Tilt/Zoom Color Video Camera

Optional RM-IP10 Controller

1/2-type Exmor®CMOS x 3 image sensor

Superb broadcast picture quality

Full HD 1080i/60 resolution

High sensitivity – 4 lx minimum illumination

Advanced color adjustment

HD-SDI, component, RGB and composite,

Y/C video interfaces

Selectable image formats:

1080i/720p/NTSC/PAL at 59.94Hz and 50Hz

14x optical zoom lens

Fully remote controllable via RS-232C/RS-422

(VISCA™protocol)

Optional VISCA RM-BR300 Controller

Optional IP control with RM-IP10 controller &

BRBK-IP10 card

Tally lamp

Wide-range, quiet and quick pan/tilt mechanism:

•Pan: -170° to +170° (max.speed 60°/second)

•Tilt: -30° to +90° (max. speed 60°/second)

Horizontal viewing angle: 59.6° (wide-end)

Desktop or ceiling mountable with E:Flip function

BRC-H700

1080i 3 CCD HD

Pan/Tilt/Zoom Color Video Camera

Optional RM-BR300 Controller

1/3-type IT CCD x 3 image sensor

Superb picture quality

HD 1080i/60 resolution

Minimum illumination – 6 lx

Supports analog RGB,Y/Pb/PR output as standard

Optional interface card slot for HD-SDI,

computer XGA and HDV™formats

Selectable image formats:

1080i at 59.94Hz and 50Hz

12x optical, 4x digital zoom lens

Fully remote controllable via RS-232C/RS-422

(VISCA protocol)

Optional VISCA RM-BR300 Controller

Wide-range, quiet and quick pan/tilt mechanism:

•Pan: -170° to +170° (max. speed 60°/second)

•Tilt: -30° to +90° (max. speed 60°/second)

Horizontal viewing angle: 60.3° (wide-end)

Desktop or ceiling mountable with E:Flip function

HD Cameras

BRC-Z700

1080i 3 CMOS HD

Pan/Tilt/Zoom Color Video Camera

Optional RM-IP10 Controller

1/4-type CMOS x 3 image sensor

Superb picture quality

HD 1080i/60 resolution

Minimum illumination – 6 lx

Supports HD and SD outputs as standard

Optional interface card slot for HD-SDI

and SD-SDI formats

Selectable image formats:

1080i/NTSC/PAL at 59.94Hz and 50Hz

20x optical, 4x digital zoom lens

Fully remote controllable via RS-232C/RS-422

(VISCA protocol)

Optional VISCA RM-BR300 Controller

Optional IP control with RM-IP10 controller &

BRBK-IP7Z card

Wide-range, quiet and quick pan/tilt mechanism:

•Pan: -170° to +170° (max. speed 60°/second)

•Tilt: -30° to +90° (max. speed 60°/second)

Horizontal viewing angle: 55.2° (wide-end)

Desktop or ceiling mountable with

E:Flip function

BRC-Z330

1080i CMOS HD

Pan/Tilt/Zoom Color Video Camera

Optional RM-IP10 Controller

1/3-type CMOS image sensor

Superb picture quality

HD 1080i/60 resolution

Minimum illumination – 6 lx

Supports HD and SD outputs as standard

Optional interface card slot for HD-SDI

and Analog SD formats

Selectable image formats:

1080i/720p/NTSC/PAL at 59.94Hz and 50Hz

18x optical, 4x digital zoom lens

Fully remote controllable via RS-232C/RS-422

(VISCA protocol)

Optional VISCA RM-BR300 Controller

Optional IP control with RM-IP10 controller &

BRBK-IP10 card

Wide-range, quiet and quick pan/tilt mechanism:

•Pan: -175° to +175° (max. speed 60°/second)

• Tilt: -30° to +90° (max. speed 60°/second)

Horizontal viewing angle: 55.1° (wide-end)

Desktop or ceiling mountable with

E:Flip function

EVI-H100S

EVI-H100S/W

1080p HD Pan/Tilt/Zoom

Color Video Cameras

1/2.8-type Exmor CMOS image sensor

Superb picture quality

Full HD 1080p/30 resolution

Auto ICR function

HD-SDI video interface

Selectable image formats:

1080p / 1080i / 720p /SD (letter box)

at 59.94Hz, 50Hz, 29.97Hz and 25Hz

20x optical, 12x digital zoom lens

Wide D function (auto wide-D)

Wide-range, quiet and quick pan/tilt/zoom mechanism:

•Pan: -170º to +170º (max. speed 100º/second)

•Tilt: -20º to +90º (max.speed 90º/second)

Horizontal viewing angle: 55.4º (wide) to 2.9º (tele)

Desktop or ceiling mountable with E:Flip function

Available in white or black housing

Optional VISCA RM-BR300 Controller

EVI-H100V

EVI-H100V/W

1080p HD Pan/Tilt/Zoom

Color Video Cameras

1/2.8-type Exmor CMOS image sensor

Superb picture quality

Full HD 1080p/30 resolution

DVI video interface

Auto ICR function

Selectable image formats:

1080p / 1080i / 720p at 59.95Hz,

50Hz, 29.97Hz and 25Hz

20x optical, 12x digital zoom lens

Wide D function (auto wide-D)

Wide-range, quiet and quick pan/tilt/zoom mechanism:

•Pan: -170º to +170º (max. speed 100º/second)

•Tilt: -20º to +90º (max.speed 90º/second)

Horizontal viewing angle: 55.4º (wide) to 2.9º (tele)

Desktop or ceiling mountable with E:Flip function

Available in white or black housing

Optional VISCA RM-BR300 Controller

EVI-HD7V

1080p HD Pan/Tilt/Zoom

Color Video Camera

1/3-type CMOS image sensor

Superb picture quality

DVI video interface

Selectable image formats:

1080p / 1080i / 720p / 640x480

(letter box) at 59.94Hz and 50Hz

10x optical, 4x digital zoom lens

Wide-range, quiet and quick

pan/tilt/zoom mechanism:

• Pan: -100° to +100°

(max. speed 300°/second)

• Tilt: -25° to +25°

(max. speed 125°/second)

Wide horizontal viewing angle:

70° (wide) to 8° (tele)

Desktop mountable

Optional VISCA RM-BR300 Controller

EVI-HD3V

720p HD Pan/Tilt/Zoom

Color Video Camera

1/3-type CMOS image sensor

Superb picture quality

DVI video interface

Selectable image formats:

720p / 640x480 (letter box)

10x optical, 4x digital zoom lens

Wide-range, quiet and quick

pan/tilt/zoom mechanism:

• Pan: -100° to +100°

(max. speed 300°/second)

• Tilt: -25° to +25°

(max. speed 125°/second)

Wide horizontal viewing angle:

70° (wide) to 8° (tele)

Desktop mountable

Optional VISCA RM-BR300 Controller

EVI-HD1

Multi-format HD Pan/Tilt/Zoom

Color Video Camera

1/3-type CMOS image sensor

Superb picture quality

Multi-format video outputs from

NTSC/PAL to Full HD: HD-SDI, HD Analog

component (Y/Pb/Pr),VBS,Y/C

Selectable image formats:

1080i / 1080p / 720p / NTSC / PAL

10x optical, 4x digital zoom lens

Wide-range, quiet and quick

pan/tilt/zoom mechanism:

• Pan: -100º to +100º

(max. speed 300º/second)

•

Tilt: -25º to +25º

(max. speed 125º/second)

Wide horizontal viewing angle:

70º (wide) to 8º (tele)

Desktop mountable

Optional VISCA RM-BR300 Controller

EVI-H100V

EVI-H100V/W

1080p HD Pan/Tilt/Zoom

Color Video Cameras

1/2.8-type Exmor CMOS image sensor

Superb picture quality

Full HD 1080p/30 resolution

DVI video interface

Auto ICR function

Selectable image formats:

1080p / 1080i / 720p at 59.95Hz,

50Hz, 29.97Hz and 25Hz

20x optical, 12x digital zoom lens

Wide D function (auto wide-D)

Wide-range, quiet and quick pan/tilt/zoom mechanism:

•Pan: -170º to +170º (max. speed 100º/second)

•Tilt: -20º to +90º (max.speed 90º/second)

Horizontal viewing angle: 55.4º (wide) to 2.9º (tele)

Desktop or ceiling mountable with E:Flip function

Available in white or black housing

Optional VISCA RM-BR300 Controller

written permission is prohibited. Features and speciﬁcations are subject to change

without notice. Sony,Exmor, ExView HAD CCD,VISCA, and the Sony make.believe logo are

trademarks of Sony.

Printed in USA 5/13

Sony Electronics Inc.

1 Sony Drive

Park Ridge, NJ 07656

sony.com/ptz

IS-1255

sony.com/ptz

Autres manuels pour BRCH900

Ce manuel convient aux modèles suivants

Autres manuels Sony caméscope

Sony

Sony Handycam HDR-PJ810 Manuel utilisateur

Sony

Sony video Hi8 Handycam CCD-TR400 Manuel utilisateur

Sony

Sony Handycam Vision CCD-TRV3E Manuel utilisateur

Sony

Sony DCR-HC40 - Digital Handycam Camcorder Manuel utilisateur

Sony

Sony HXRNX30U Manuel utilisateur

Sony

Sony Handycam HDR-UX9E Manuel utilisateur

Sony

Sony Handycam HDR-CX7E Manuel utilisateur

Sony

Sony Handycam HDR-CX6EK Manuel utilisateur

Sony

Sony DXC-3000 Manuel utilisateur

Sony

Sony NEX-FS700R Manuel utilisateur

Sony

Sony DCR-SX41/R - Palm-sized Camcorder W/ 60x Optical... Manuel utilisateur

Sony

Sony DVR-TRV50 Manuel utilisateur

Sony

Sony CCD-CR1 - Video Camera Recorder 8mm Manuel utilisateur

Sony

Sony Handycam DCR-TRV940 Mode d’emploi

Sony

Sony Handycam HDR-XR100E Manuel utilisateur

Sony

Sony Handycam DCR-TRV80E Manuel utilisateur

Sony

Sony Handycam DCR-SR87 Manuel utilisateur

Sony

Sony CCD-TRV65E, CCD-TRV3E, CCD-TRV15E, CCD-TRV23E,... Manuel utilisateur

Sony

Sony NXCAM NEX-EA50UH Manuel utilisateur

Sony

Sony Handycam CCD-TR2300 Manuel utilisateur

Sony

Sony Handycam DCR-DVD7 Manuel utilisateur

Sony

Sony PXW-FS7M2 Mode d’emploi

Sony

Sony Handycam HDR-CX260V Manuel utilisateur

Sony

Sony MHS-CM1 Manuel utilisateur

Manuels caméscope populaires d'autres marques

Toshiba

Toshiba CAMILEO Z100 Manuel utilisateur

Panasonic

Panasonic NV-VS40B Manuel utilisateur

Canon

Canon RC 260 Manuel utilisateur

Brinno

Brinno TimeLapse TLC200 Manuel utilisateur

JVC

JVC GR-SXM68AC Guide de démarrage rapide

Panasonic

Panasonic AG-HMC152EN Manuel utilisateur

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manuel utilisateur

MYDLINK

MYDLINK DCS-6100LH Manuel utilisateur

SECURECOM

SECURECOM V-5014B Manuel utilisateur

Panasonic

Panasonic HDC-SD100 Manuel utilisateur

Sharper Image

Sharper Image U-VIDEO Manuel utilisateur

JVC

JVC AA-V15EG Manuel utilisateur

Canon

Canon LEGRIA HV40 Manuel utilisateur

RCA

RCA CC616 Manuel utilisateur

Panasonic

Panasonic NVM40 Manuel utilisateur

ATIK Cameras

ATIK Cameras Horizon Manuel utilisateur

Sharp

Sharp ViewcamZ VL-Z8H Manuel utilisateur

Philips

Philips M620/21 Manuel utilisateur
