Sony TA-VE610 Manuel utilisateur

3-861-069-11(1)

1997 by Sony Corporation

Integrated AV

Amplifier

Operating Instructions

Mode d’emploi

Gebruiksaanwijzing

Bruksanvisning

TA-VE610

2EN

WARNING

To prevent fire or shock

hazard, do not expose

the unit to rain or

moisture.

To avoid electrical shock,

do not open the cabinet.

Refer servicing to

qualified personnel only.

Do not install the

appliance in a confined

space, such as a bookcase

or built-in cabinet.

Precautions

On safety

• Should any solid object or liquid fall

into the cabinet, unplug the amplifier

and have it checked by qualified

personnel before operating it any

further.

On power sources

• Before operating the amplifier, check

that the operating voltage is identical

with your local power supply. The

operating voltage is indicated on the

nameplate at the rear of the amplifier.

• The amplifier is not disconnected

from the AC power source as long as

it is connected to the wall outlet, even

if the amplifier itself has been turned

off.

• If you are not going to use the

amplifier for a long time, be sure to

disconnect the amplifier from the

wall outlet. To disconnect the AC

power cord, grasp the plug itself;

never pull the cord.

• One blade of the plug is wider than

the other for the purpose of safety

and will fit into the wall outlet only

one way. If you are unable to insert

the plug fully into the outlet, contact

your dealer.

• AC power cord must be changed only

at the qualified service shop.

On placement

• Place the amplifier in a location with

adequate ventilation to prevent heat

buildup and prolong the life of the

amplifier.

• Do not place the amplifier near heat

sources, or in a place subject to direct

sunlight, excessive dust or

mechanical shock.

• Do not place anything on top of the

cabinet that might block the

ventilation holes and cause

malfunctions.

On operation

• Before connecting other components,

be sure to turn off and unplug the

amplifier.

On cleaning

• Clean the cabinet, panel and controls

with a soft cloth slightly moistened

with a mild detergent solution. Do

not use any type of abrasive pad,

scouring powder or solvent such as

alcohol or benzine.

If you have any question or problem

concerning your amplifier, please

consult your nearest Sony dealer.

3EN

TABLE OF CONTENTS

Getting Started

Unpacking 4

Hookup Overview 4

Audio Component Hookups 5

Speaker System Hookups 5

TV/VCR Hookups 7

AC Hookups 8

Before You Use Your Amplifier 9

Basic Operations

Selecting a Component 9

Indexing Program Sources 12

Recording 13

Using the Sleep Timer 14

Dolby Surround Setup

Dolby Pro Logic 14

Sound Adjustment

Using Pre-programmed Sound Fields 16

Customizing the Sound Fields 17

Advanced Remote Operations

Operating One Component While Using Another (background operation)

Changing the Factory Setting of a FUNCTION Button 20

Additional Information

Troubleshooting 21

Specifications 22

Glossary 23

Table of Functions of the SET UP Button 24

Rear Panel Descriptions 25

Remote Button Descriptions 26

Index 28

Quick Reference Guide 29

About This Manual

The instructions in this manual are for

model TA-VE610.

Conventions

• The instructions in this manual

describe the controls on the amplifier.

You can also use the controls on the

remote if they have the same or

similar names as those on the

amplifier.

• A “Quick Reference Guide” is

supplied on page 29.

• The “Remote Button Descriptions”

section on page 26 provides an

overview of the remote buttons.

• The following icons are used in this

manual:

ZIndicates that you can use only

the remote to do the task.

zIndicates hints and tips for

making the task easier.

This amplifier incorporates the Dolby*

Pro Logic Surround system.

* Manufactured under license from

Dolby Laboratories Licensing

Corporation. DOLBY, the double-D

symbol aand “PRO LOGIC” are

trademarks of Dolby Laboratories

Licensing Corporation.

4EN

Getting Started

Front

speaker

(L)

Front

speaker

(R)

Rear

speaker

(L)

Rear

speaker

(R)

CD player

Tuner

Tape deck

MD deck

Turntable

Center

speaker

Unpacking

Check that you received the following items with the

amplifier:

• Remote commander (remote) RM-U501 (1)

• Size AA (R6) batteries (2)

Inserting batteries into the remote

Insert two size AA (R6) batteries with the + and – on

the battery compartment. When using the remote,

point it at the remote sensor gon the amplifier.

}

]]

zWhen to replace batteries

Under normal use, the batteries should last for about 6

months. When the remote no longer operates the

amplifier, replace both batteries with new ones.

Notes

• Do not leave the remote in an extremely hot or humid

place.

• Do not use a new battery with an old one.

• Do not expose the remote sensor to direct sunlight or

lighting apparatuses. Doing so may cause a malfunction.

• If you don’t use the remote for an extended period of time,

remove the batteries to avoid possible damage from

battery leakage and corrosion.

VCR

LD player

Speaker

System

Hookups

(5) TV/VCR Hookups (7)

Hookup Overview

The amplifier allows you to connect and control the

following audio/video components. Follow the

hookup procedures for the components that you want

to connect to the amplifier on the pages specified. To

learn the locations and names of each jacks, see “Rear

Panel Descriptions” on page 25.

Before you get started

• Turn off the power to all components before making

any connections.

• Do not connect the AC power cords until all of the

connections are completed.

• Be sure to make connections firmly to avoid hum

and noise.

• When connecting an audio/video cable, be sure to

match the color-coded pins to the appropriate jacks

on the components: Yellow (video) to Yellow; White

(left, audio) to White; and Red (right, audio) to Red.

Getting Started

Wireless

rear

speaker

5.1

INPUT

VIDEO FUNCTION AUDIO FUNCTION

GENRE

TONE

SUR INDEX

SET UP

DIRECT

PASS

MODE

DIRECT PASS

SOUND FIELD

ON / OFF

BASS

BOOST

BALANCE

5.1 INPUT

•

PHONES

POWER

SPEAKERS

DPC

MODE

OFF

MASTER VOLUME

VIDEO 1 VIDEO 2 VIDEO 3 TV/LD TAPE/MD CD TUNER PHONO

DISPLAYDIMMER

S VIDEO RLVIDEO AUDIO

VIDEO 3 INPUT

Video camera

recorder

Video game

Audio Component

Hookups (5)

Active

woofer

5EN

Getting Started

Audio Component Hookups

Overview

This section describes how to connect your audio

components to the amplifier.

WIRELESS

REAR

SPEAKER

FRONT SPEAKERS

SURROUND SPEAKERS

IMPEDANCE USE 4–16 Ω

REAR

IMPEDANCE USE 4–16 Ω

–

++––

–

WOOFER

AUDIO

OUT

VIDEO

OUT

INOUT

VIDEO

OUT

VIDEO

OUT

VIDEO

RECOUTINININ

FRONT

CENTER

REAR

SIGNAL

GND

WOOFER

AUDIO

RAUDIO

OUT

AUDIO

OUT

AUDIO

5.1 INPUT

PHONO

TAPE / MD

MONITORVIDEO 1VIDEO 2

TV / LD

CENTER

TUNER

AC OUTLET

SWITCHED 100W MAX

PHONO CD

TAPE/MDTUNER

What cords will I need?

Audio cords (not supplied) (1 for each CD player, tuner, and

turntable; 2 for each tape deck or MD deck)

White (L) White (L)

Red (R) Red (R)

Hookups

The arrow çindicates signal flow.

CD player

Amplifier CD player

LINE

OUTPUT

Tuner

Amplifier Tuner

TUNER

LINE

OUTPUT

Tape deck or MD deck

Amplifier Tape deck or MD deck

LINE

OUTPUT

LINE

INPUT

INRECOUT

TAPE/MD

Turntable

Amplifier Turntable

PHONO

LINE

OUTPUT

If your turntable has an earth lead

To prevent hum, connect the earth lead to the ySIGNAL

GND terminal on the amplifier.

Speaker System Hookups

Overview

This section describes how to connect your speakers to

the amplifier. Although front (left and right) speakers

are required, center and rear speakers are optional.

Adding center and rear speakers will enhance the

surround effects. Connecting an active woofer will

increase bass response.

WIRELESS

REAR

SPEAKER

FRONT SPEAKERS

SURROUND SPEAKERS

IMPEDANCE USE 4–16 Ω

REAR

IMPEDANCE USE 4–16 Ω

–

––

–

WOOFER

AUDIO

OUT

VIDEO

OUT

INOUT

VIDEO

OUT

VIDEO

OUT

VIDEO

RECOUTINININ

FRONT

CENTER

REAR

SIGNAL

GND

WOOFER

AUDIO

RAUDIO

OUT

AUDIO

OUT

AUDIO

5.1 INPUT

PHONO

TAPE / MD

MONITORVIDEO 1VIDEO 2

TV / LD

CENTER

TUNER

AC OUTLET

SWITCHED 100W MAX

WOOFER

FRONT SPEAKERS A WIRELESS

REAR SPEAKER

SURROUND

SPEAKERS REAR SURROUND

SPEAKERS CENTER

What cords will I need?

• Speaker cord (not supplied) (1 for each speaker)

(+) (+)

(–) (–)

Twist the stripped ends of the cord about 2/3 inch (15

mm). Be sure to match the speaker cord to the appropriate

terminal on the components: + to + and – to –. If the cords

are reversed, the sound will be distorted and will lack

bass.

• Monaural audio cord (not supplied) (1 for an active

woofer)

Black Black

6EN

Getting Started

Hookups

Front speakers

]]}}

FRONT SPEAKERS

IMPEDANCE USE 4–16 Ω

++––

To connect the speaker cords

]}

√

Rear and center speakers

SURROUND SPEAKERS

IMPEDANCE USE 4–16 Ω

REAR

–

CENTER

]]

}]}

}

Active woofer

Amplifier Active woofer

WOOFER

AUDIO

OUT

INPUT

Wireless rear speaker

When using an optional Sony wireless rear speaker system,

connect the transmitter to the WIRELESS REAR SPEAKER

jack.

Note

Do not connect any other component to the WIRELESS

REAR SPEAKER jack.

zIf you have an additional front speaker system

Connect them to the FRONT SPEAKERS B terminals.

Note

If you use front speakers with low maximum power input,

adjust the volume carefully to avoid excessive output on the

speakers.

Rear speaker

(R) Rear speaker

(L)Center speaker

Amplifier

Front speaker

(R) Front speaker

(L)

Amplifier

Set SPEAKERS selector to

A+B

To drive

Speaker system A (connected

to the FRONT SPEAKERS A

terminals)

Speaker system B (connected

to the FRONT SPEAKERS B

terminals)

Both speaker systems A and B

(parallel connection)

Speaker placement

For optimum surround sound effect, place your

speakers as shown below.

Selecting the speaker system

If you connect only one set of front speakers, set the

SPEAKERS selector on the front panel to A. If you

connect two sets of front speakers, see the following:

Rear speaker

60 - 90 cm

Front speaker

45°

7EN

Getting Started

TV/VCR Hookups

Overview

This section describes how to connect video

components to the amplifier.

WIRELESS

REAR

SPEAKER

FRONT SPEAKERS

SURROUND SPEAKERS

IMPEDANCE USE 4–16 Ω

REAR

IMPEDANCE USE 4–16 Ω

–

––

–

WOOFER

AUDIO

OUT

VIDEO

OUT

INOUT

VIDEO

OUT

VIDEO

OUT

VIDEO

RECOUTINININ

FRONT

CENTER

REAR

SIGNAL

GND

WOOFER

AUDIO

RAUDIO

OUT

AUDIO

OUT

AUDIO

5.1 INPUT

PHONO

TAPE / MD

MONITORVIDEO 1VIDEO 2

TV / LD

CENTER

TUNER

AC OUTLET

SWITCHED 100W MAX

VIDEO 1TV/LD

VIDEO 2 MONITOR

What cables will I need?

• Audio/video cable (not supplied

) (1 for each TV or LD

player; 2 for each VCR)

Yellow Yellow

White (L) White (L)

Red (R) Red (R)

• Video cable (not supplied) (1 for a TV monitor)

Yellow Yellow

zIf you want to watch higher quality video images

You can connect an S-VIDEO cable (not supplied) to the

VIDEO 1, VIDEO 3, or MONITOR jack.

Hookups

The arrow çindicates signal flow.

TV monitor

If you use a TV monitor, do not connect anything to the TV/

LD VIDEO IN jack.

Amplifier TV monitor

VIDEO

INPUT

VIDEO

OUT

MONITOR

VCR (via the VIDEO 1/2 jacks)

If you have two VCRs, connect the second one to the VIDEO

2 jacks. Amplifier

OUTPUT INPUT

VIDEOVIDEO

AUDIO

INOUT

VIDEO

OUT

AUDIO

OUT

VIDEO 1

Video camera recorder or video game

Use the VIDEO 3 INPUT jacks on the front panel.

OUTPUT

VIDEO

AUDIO

S VIDEO RLVIDEO AUDIO

VIDEO 3 INPUT

TV or LD player

If you have an additional TV or LD player, connect it to the

VIDEO 2 jacks.

Amplifier TV or LD player

OUTPUT

TV/LD

VIDEO

AUDIO

VIDEO

AUDIO

(Continued)

Amplifier

Video camera recorder or

video game

VCR

8EN

Getting Started

zYou can play decoded Dolby Digital (AC-3)

soundtracks through the speakers connected to the

amplifier

If you have a Dolby Digital (AC-3) decoder, you can use

the amplifier to amplify a decoded Dolby Digital (AC-3)

soundtrack with the following connections. Refer to the

instruction manual supplied with your Dolby Digital

(AC-3) decoder.

VIDEO

FRONT

CENTER

REAR

WOOFER

5.1 INPUT

REAR

CENTER

WOOFER

PRE OUT

FRONT

R AUDIO L

LINE OUT

VIDEO

DIGITAL

OUT

Dolby Digital

(AC-3) decoder

etc.

Amplifier

DVD player

AC Hookups

Connecting the AC power cord

Connect the AC power cord from this amplifier and

from your audio/video components to a wall outlet.

If you connect another audio component to AC

OUTLET on the amplifier, the amplifier can supply

power to the connected component so you can turn

on/off whole system when you turn on/off the

amplifier.

WIRELESS

REAR

SPEAKER

FRONT SPEAKERS

SURROUND SPEAKERS

IMPEDANCE USE 4–16 Ω

REAR

IMPEDANCE USE 4–16 Ω

–

++––

–

WOOFER

AUDIO

OUT

VIDEO

OUT

INOUT

VIDEO

OUT

VIDEO

OUT

VIDEO

RECOUTINININ

FRONT

CENTER

REAR

SIGNAL

GND

WOOFER

AUDIO

RAUDIO

OUT

AUDIO

OUT

AUDIO

5.1 INPUT

PHONO

TAPE / MD

MONITORVIDEO 1VIDEO 2

TV / LD

CENTER

TUNER

AC OUTLET

SWITCHED 100W MAX

AC OUTLET

to a wall

outlet

Caution

Make sure that the power consumption of the component

connected to amplifier’s AC OUTLET does not exceed the

wattage stated on the rear panel. Do not connect high-

wattage electrical home appliances such as electric irons,

fans, or TVs to this outlet.

9EN

Getting Started

Basic Operations

Before You Use Your Amplifier

Before you start using your amplifier, make sure that

you have:

• Turned MASTER VOLUME to the leftmost position

(0).

• Selected the appropriate speaker system. (For

details, see “Selecting the speaker system” on

page 6.)

• Set BALANCE to the center position.

Turn on the amplifier and check the following

indicator.

• Press MUTING on the remote if “MUTING” appears

in the display.

Clearing the amplifier’s memory

Before you use your amplifier for the first time or

when you want to clear the amplifier’s memory,

do the procedure below.

5.1

INPUT

VIDEO FUNCTION AUDIO FUNCTION

GENRE

TONE

SUR INDEX

SET UP

DIRECT

PASS

MODE

DIRECT PASS

SOUND FIELD

ON / OFF

BASS

BOOST

BALANCE

5.1 INPUT

•

PHONES

POWER

SPEAKERS

DPC

MODE

OFF

MASTER VOLUME

VIDEO 1 VIDEO 2 VIDEO 3 TV/LD TAPE/MD CD TUNER PHONO

DISPLAYDIMMER

S VIDEO RLVIDEO AUDIO

VIDEO 3 INPUT

POWER AUDIO FUNCTION

VIDEO FUNCTION MODE

1Turn off the amplifier.

2Press down VIDEO FUNCTION , AUDIO

FUNCTION , MODE, and POWER

simultaneously.

The contents of the memory (e. g., parameter

settings) are erased.

Getting Started

Selecting a Component

To listen to or watch a connected component, first

select the function on the amplifier or with the remote.

Before you begin, make sure you have:

• Connected all components securely and correctly as

indicated on pages 4 to 8.

• Turned MASTER VOLUME to the leftmost position

(0) to avoid damaging your speakers.

5.1

INPUT

VIDEO FUNCTION AUDIO FUNCTION GENRE

TONE

SUR INDEX

SET UP

DIRECT

PASS

MODE

DIRECT PASS

SOUND FIELD

ON / OFF

BASS

BOOST

BALANCE

5.1 INPUT

•

PHONES

POWER

SPEAKERS

DPC

MODE

OFF

A+B

MASTER VOLUME

VIDEO 1 VIDEO 2 VIDEO 3 TV/LD TAPE/MD CD TUNER PHONO

DISPLAYDIMMER

S VIDEO RLVIDEO AUDIO

VIDEO 3 INPUT

POWER SET UPDIRECT PASS

VIDEO/AUDIO

FUNCTION

MASTER VOLUME

5.1 INPUT BASS

BOOST BALANCE

PHONES

DIMMER

SPEAKERS

1Press POWER to turn on the amplifier.

The STANDBY indicator turns off.

2Select the component you want to use:

To watch or

listen to To light up

VIDEO

FUNCTION

AUDIO

FUNCTION

VIDEO

FUNCTION

VIDEO

FUNCTION

AUDIO

FUNCTION

Press

(repeatedly)

Digital processing

control buttons

Video tapes

Laser discs

TV programs

Audio tapes

Compact Discs (CD)

VIDEO 1 or VIDEO 2

TV/LD

TAPE/MD

VIDEO

FUNCTION

Video camera

recorder or video

game

VIDEO 3

MiniDiscs (MD) AUDIO

FUNCTION TAPE/MD

Basic Operations

(Continued)

10EN

Basic Operations

AUDIO

FUNCTION

AUDIO

FUNCTION

3Turn on the component, for example, a CD player,

and then start playing.

4Turn MASTER VOLUME to adjust the volume.

To adjust the volume of the TV’s speakers, use the

volume control on the TV.

To play the decoded Dolby Digital (AC-3) program

source connected to the 5.1 INPUT jacks

Press 5.1 INPUT so that the 5.1 INPUT indicator lights

up.

Radio programs

Records

TUNER

PHONO

To watch or

listen to To light upPress

(repeatedly)

To Do this

Mute the sound ZPress MUTING on the remote. Press

again to restore the sound.

Reinforce the bass Press BASS BOOST to turn on the

BASS BOOST indicator

Adjust the balance of

front speakers Turn BALANCE left or right

zWhen you listen with headphones

Connect the headphones to the PHONES jack and set

SPEAKERS to OFF.

zWhen you want to enjoy high quality sound

Press DIRECT PASS (or DIRECT on the remote) to

bypass the tone controls, bass reinforcement, and

surrround effects.

The DIRECT PASS indicator lights up.

zTo select another component when a decoded Dolby

Digital (AC-3) program source is selected

Press VIDEO/AUDIO FUNCTION to turn off the 5.1

INPUT indicator.

Note

BASS BOOST, DIRECT PASS, and SOUND FIELD ON/

OFF buttons do not operate when the 5.1 INPUT

indicator is on.

zYou can adjust the brightness of the display

Press DIMMER repeatedly to select the brightness.

Watching TV/video programs

To watch Do this

TV programs Turn on both the TV and the amplifier

and press VIDEO FUNCTION

repeatedly until the TV/LD indicator

lights up

Videos or laser discs 1Press VIDEO FUNCTION

repeatedly to select the component

(for example, VIDEO 1).

2Turn on the TV and set the TV’s

video input to match your video

component.

3Turn on the component (VCR or LD

player), and start playback.

zWhen you watch TV or video programs

We recommend you play audio portion through the

amplifier instead of your TV’s speakers. This lets you

take advantage of the amplifier’s surround sound

effects, like Dolby Surround, and lets you use the

amplifier’s remote to control the audio.

Turn off the speakers on your TV before you start so

you can enjoy the surround sound from your amplifier.

Table des matières

Langues :

Autres manuels Sony Amplificateur

Sony

Sony XM-405EQX2 Manuel utilisateur

Sony

Sony TA-FA777ES Manuel utilisateur

Sony

Sony SRP-P50 Manuel utilisateur

Sony

Sony XM-2150GSX Marketing Specifications Manuel utilisateur

Sony

Sony TA-E9000ES - Stereo Preamplifier Manuel utilisateur

Sony

Sony XM-D500X Operating & Mounting Manuel utilisateur

Sony

Sony XM-2002GTW - Stereo Amplifier Manuel utilisateur

Sony

Sony XM-404EQX Manuel utilisateur

Sony

Sony XM-SW1 Manuel utilisateur

Sony

Sony XM-1252GTR - Power Stereo Amplifier Manuel utilisateur

Sony

Sony XM-1600GSD Marketing Specifications,... Manuel utilisateur

Sony

Sony XM-ZR604 - AMPLIFIER 4 CHANNEL Manuel utilisateur

Sony

Sony TA-F530ES Manuel utilisateur

Sony

Sony PHA-3 Mode d’emploi

Sony

Sony XM-CD61X Manuel utilisateur

Sony

Sony XM-2002GTR - Stereo Amplifier Manuel utilisateur

Sony

Sony XM-D500X Operating & Mounting Manuel utilisateur

Sony

Sony F519R Manuel utilisateur

Sony

Sony XM-2100GTX - Stereo Power Amplifier Manuel utilisateur

Sony

Sony TA-DA9000ES Manuel utilisateur

Sony

Sony TA-N80ES Manuel utilisateur

Sony

Sony XM-1600GSD Marketing Specifications,... Manuel utilisateur

Sony

Sony XM-552ZR Manuel utilisateur

Sony

Sony TA-F4A Manuel utilisateur

Manuels Amplificateur populaires d'autres marques

ASTRO

ASTRO HVO V40 P Manuel utilisateur

Marantz

Marantz SUPERSCOPE BLA-545 Instructions de montage

NAD

NAD CI980 Manuel utilisateur

Technics

Technics SE-CH770 Manuel utilisateur

Harman Kardon

Harman Kardon HK6300 Manuel utilisateur

NAD

NAD T975 Manuel utilisateur

McIntosh

McIntosh MA6850 Manuel utilisateur

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manuel utilisateur

Viatron

Viatron Autrix Manuel utilisateur

GME

GME GA9800 Manuel utilisateur

Atlas

Atlas CP700 Manuel utilisateur

Roland

Roland KC-1000 Manuel utilisateur

Pyle

Pyle PFMRA350BW Manuel utilisateur

Advantage

Advantage S-250 Manuel utilisateur

IRT Electronics

IRT Electronics DVA-3007 Manuel utilisateur

Dimavery

Dimavery BA-100 Series Manuel utilisateur

Schertler

Schertler ROY X Manuel utilisateur

Phonic

Phonic XP 3000 Manuel utilisateur
