OVERVIEW

This guide provides you with everything you need to get

started. If you need additional information on features and

services, please select one of these helpful options:

nVisit the support forums at http://forums.t-mobile.com,

nVisit www.sonyericsson.com/support,

nVisit www.t-mobile.com, or

nOn your phone, select Menu >

Settings > Help & My Acct..

TablE Of COnTEnTs

Introducing Your Phone ................................................... 4

Service Activation............................................................. 5

SIM Card and Battery....................................................... 6

Memory Card ................................................................... 8

Setup Wizard.................................................................... 9

Call Functions .................................................................. 9

Mobile Backup ............................................................... 10

Contacts......................................................................... 11

E-mail Setup................................................................... 13

myFaves®Setup ............................................................ 14

Bluetooth®Setup............................................................ 21

Emergency Dialing......................................................... 22

Caring for Your Phone.................................................... 23

Tips for Safety ................................................................ 24

Having Fun

Turn to the Having Fun section of this booklet to learn

what else your new phone can do.

sERVICE aCTIVaTIOn

If you are a new T-Mobile customer and your service

has not been activated, simply call Customer Care at

1-800-937-8997 from your landline phone and a T-Mobile

activations representative will assist you.

You will need the following information when activating service:

nService Agreement and agent code on your

Agreement

nYour name, home address, home phone, and billing

address

NOTE: For business and government accounts, please provide the name

of your company or government agency, address, and tax ID.

nYour Social Security number, current driver’s license

number, and date of birth for credit check purposes

nYour choice of T-Mobile rate plan and services

(see www.t-mobile.com for latest plan information)

nSIM serial number and IMEI number (located on the

box bar code label)

By activating service, you acknowledge that you have read, understand,

and agree to be bound by each of the Terms and Conditions of the

Service Agreement.

InTROduCIng YOuR PhOnE

Sony Ericsson EquinoxTM

Left Soft key Right Soft key

End / Power key

Press and hold to turn

phone on/off.

Send key

Clear / Back key

Volume keys

Shortcuts key

Charging Port

Navigation key

with Center Select

Pound key

Press and hold to turn

Silent mode on/off.

Back cover release slot

3. Slide the SIM card into

the SIM card slot with the

golden contacts facing

down and the angled

corner on the SIM facing

into the SIM card slot.

4. Align the golden contacts

on the battery with the

contacts in the battery

compartment. Snap the

battery into place and

replace the battery cover.

5. Plug the charger into

the phone and into an

electrical outlet to charge.

When charging is com-

plete, disconnect the

charger from the phone.

To power on, press and

hold the red End key.

sIm CaRd and baTTERY

Your Subscriber Identity Module (SIM) card identies you to

the wireless network. Your phone will not work without the

SIM card. To insert the SIM and battery:

1. Detach your SIM card by

pushing from the back to

detach.

2. To remove the battery

cover put your ngernail

in the cover release slot.

Lift up to release the cover

and then lift up and away.

sETuP WIzaRd

After you power on your phone, scroll to and select the desired

language. Once you select your language, you will see the

Setup Wizard. Follow the prompts to set basic settings on your

phone.

Call funCTIOns

To make a call, open the phone, enter the number, and then

press the green Send key.

To answer a call, open the phone or press the green Send key

if the phone is already open.

To end a call, close the phone or press the red End key.

Set up and call voicemail

To set up voicemail, press and hold the 1key and follow the

tutorial.

To reset the password to the last 4-digits of your phone number,

enter #PWD# or #793# and press the green Send key.

To call voicemail, press and hold the 1key.

mEmORY CaRd

Your phone is capable of using a removable Memory Stick

MicroTM (M2) memory card, allowing you to easily store

pictures, videos, and sound les.

NOTE: Your phone does not come with a memory card.

1. Remove the back battery cover.

2. Insert the memory card into the memory card slot with

the golden contacts facing down toward the phone.

Press until the memory card clicks into place.

mObIlE baCkuP

Mobile Backup lets you store your phone book on your phone

and on the my.t-mobile.com Web site. This service is included

at no additional charge. Your address book is backed up by

T-Mobile the rst time you turn on your phone and each time

you make a change. Your contacts are available for you to

view and manage on the web. You can manage your options

with the Mobile Backup service at my.t-mobile.com. You may

opt out of this service. However, if you choose certain services

(like myFaves), your address book may still be backed up in

order to deliver these specic services. With Mobile Backup,

you don’t have to worry about losing contact information if you

lose your phone. See the FAQs on my.t-mobile.com for more

details.

COnTaCTs

Add contacts using your phone

1. From the main screen, enter the contact’s phone number

and select Save.

2. Select New contact.

3. Select Mobile,Mobile (private),Mobile (work),Home,

Work,Fax, or Other.

4. At Name, enter the contact’s name.*

5. Select OK when done.

6. To add additional contact information, press the

Navigation key right to scroll through the tabs, then

scroll down and select Add to enter information.

7. Select Save when done.

To turn off predictive mode, press and hold the *key

when typing the contact’s name.

*The default text entry mode is T9®predictive mode.

Predictive mode predicts what you want to enter and

displays a list of letter combinations. Scroll to the letter

or combination that you want and press the Center

Select key to select. To insert a space, press the #key.

Add contacts using your computer

You can also add and manage contacts on my.t-mobile.com

and changes are synchronized with your phone.

1. Log in to the site with your phone number and password.

2. Under Connect with MobileLifeSM, click Contacts.

3. Under Contacts, click Click here to manage.

4. Click Add / Import Contacts.

5. Enter the contact’s information and click SAVE. You will

see the sync symbol next to the newly created contact.

6. At the top of the Contacts box, click Synchronize Now.

When the contact has successfully exported to your

phone, the sync symbol will disappear.

Call contact from the phone book

1. Press the Navigation key down to access the

phone book.

2. Scroll to the contact and press the green Send key.

E-maIl sETuP

1. From the main screen, select Menu.

2. Scroll to and select Messaging.

3. Scroll to and select Email.

4. Enter your name and e-mail address.

5. Select Continue.

6. Scroll down and enter your password.

7. Select Continue.

8. Select Yes.

9. Your phone will search for the

appropriate server settings. When it has nished, select

Yes again to update your inbox.

10. When your messages have completed downloading to

your inbox, select OK.

11. Select Yes to turn on push messaging for IMAP accounts.

To set up additional e-mail accounts, select Menu >

Messaging > Email > Accounts > New account.

Separate charges may apply to send/receive/read domestic/international e-mails.

If your phone is unable to nd the server settings you must set

up the account manually. To set up the account manually you will

need the connection type, POP or IMAP server address, and SMTP

server address.

sETuP

myFaves® is an optional calling plan. Benets of signing up

to myFaves:

nUnlimited nationwide calling

to any ve U.S. numbers,

on any network (even landlines)*

nOne-touch calling, text

messaging, e-mail, and

photo sharing**

nNo domestic roaming or

domestic long-distance

charges

nPersonalize contacts

with favorite pictures and

downloadable icons**

* Capable handset required. myFaves only applies to calls directly

between two people and allows unlimited nationwide calling to 5 U.S.

numbers. You can change myFaves numbers once/month.

** Separate purchase/download charges may apply. Separate charges

apply to send/receive domestic/international text/picture messages

and and to send/receive/read domestic/international e-mail.

Subscribe to myFaves

To subscribe, go to www.t-mobile.com. When you have

subscribed to myFaves, you will see ve circles on the main

screen a few minutes after you power on your phone.

Add myFaves contacts

1. From the main screen, scroll to

and select an unassigned circle.

2. Select one of the following:

nNew contact: Enter the

contact’s name and select

OK. Scroll down and enter the

contact’s phone number and

select OK.

nGet from Contacts

: Scroll to

and select the contact.

3. Select Save now or go to Step 4 to assign an icon and

Step 7 to assign a ringtone.

Assign icon to myFaves

4. Scroll to Picture and select Add.

5. Select one of the following:

nTake picture: Frame your subject and select TakePic

to capture.

nIcons: Scroll to and select the icon.

nCamera album: Scroll to and select the picture. Move

the circle to the desired location and select

Crop.

Pictures: Scroll to and select the picture. Move the circle

to the desired location and select Crop.

Download: Select myFaves icons. Select the desired

category and image le and continue on to download a

new icon.

6. Select Save now or go to Step 7 to assign a ringtone.

Assign ringtone to myFaves

7. Scroll to Ringtone and select Add.

8. Locate and select the ringtone.

9. Select Save when you are done.

10. Select Yes to conrm adding a new myFaves contact.

An hourglass displays in the circle while the contact is

being added to the phone book. You can use your phone

during this time. Once the contact is added, you will receive

a conrmation and the hourglass is replaced by your new

contact.

Now you are ready to call your contact. From the main

screen, scroll to the contact and press the green Send key

to call or press the Center Select key to see options to send

messages, audio postcards, IM, and e-mail messages.

Each original icon/ringtone selection and each change to an icon/ringtone may incur

a separate download charge.

Autres manuels pour Equinox

Table des matières

Autres manuels Sony Ericsson Téléphone portable

Sony Ericsson

Sony Ericsson T610i Manuel utilisateur

Sony Ericsson

Sony Ericsson Z500a Guide de référence rapide

Sony Ericsson

Sony Ericsson W64S Manuel utilisateur

Sony Ericsson

Sony Ericsson Cyber-shot K850i Guide de référence rapide

Sony Ericsson

Sony Ericsson Walkman W350a Manuel utilisateur

Sony Ericsson

Sony Ericsson W660i Manuel utilisateur

Sony Ericsson

Sony Ericsson P910i Manuel utilisateur

Sony Ericsson

Sony Ericsson XPERIA X8 Manuel utilisateur

Sony Ericsson

Sony Ericsson Cyber-Shot K770 Manuel du propriétaire

Sony Ericsson

Sony Ericsson Z200 Manuel utilisateur

Sony Ericsson

Sony Ericsson Amber TM506 Guide de référence rapide

Sony Ericsson

Sony Ericsson Mix Walkman phone Manuel de service

Sony Ericsson

Sony Ericsson K800i Instructions d'installation

Sony Ericsson

Sony Ericsson Z600 Manuel utilisateur

Sony Ericsson

Sony Ericsson K608i Manuel utilisateur

Sony Ericsson

Sony Ericsson T300 Manuel utilisateur

Sony Ericsson

Sony Ericsson XPERIA acro HD IS12S Mode d’emploi

Sony Ericsson

Sony Ericsson IIDA G11 Guide d'installation

Sony Ericsson

Sony Ericsson WT13i Manuel de service

Sony Ericsson

Sony Ericsson W302 Walkman Mode d’emploi

Sony Ericsson

Sony Ericsson Xperia Mini Pro Manuel utilisateur

Sony Ericsson

Sony Ericsson G502c Manuel utilisateur

Sony Ericsson

Sony Ericsson PLAY Manuel utilisateur

Sony Ericsson

Sony Ericsson P900 Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
