Sub
Overview Sonos Sub takes your audio
experience to the next level—
Instantly adds a dimension of deep bass impact to your
audio listening experience.
Allows placement anywhere because it’s wireless and
compact—position it vertically or horizontally on any floor
surface.
The top of the acoustic slot doubles as a handle so you
can lift it.
Sub (Gen. 3) is compatible with the Sonos S2 app (for
Android and iOS). Earlier Sub models are compatible
with either S1 or S2.
Sonos Sub is designed for use with most Sonos
speakers, except Sonos Roam, Roam SL, Connect, Port,
and Move. Make sure you set up at least one speaker
before adding Sub.
See Setup when you’re ready to add a Sub to your
Sonos system.
Controls and buttons
1Acoustic slot You can use the acoustic slot as a
handle to lift Sub.
2Status light Displays the product's connection to
WiFi, indicates when the volume is
muted, and signals errors. Learn
more
If the light is distracting, you can turn
it off in your room’s settings.
3Join button Press to connect during setup.
4Ethernet port Use an Ethernet cable if you want to
connect to a router (optional).
5AC power (mains) input Use only the supplied power cord to
connect to a power outlet (using a
third party power cord will void your
warranty). Be sure to use the proper
power adapter for your country. Push
the power cord firmly into Sub until it
is flush with the surface.
Select a location
Choose a location—Sub is designed to provide optimal sound wherever you place it.
Use the acoustic slot as a handle to lift Sub out of the box. You should always bend your
knees when lifting heavy objects to avoid undue stress on your back.
Make sure at least one side of the slot is free from obstruction. If you place it vertically
against a wall, don’t block the front opening.
If you place Sub horizontally on the floor, don’t put anything on top of it. Leave at least 1"
clearance along the top of Sub if placing under furniture.
Sub is designed to sit on the floor. You can place it in a corner, against the wall, behind,
under, or next to any piece of furniture on any kind of floor surface.
Position Sub either vertically or horizontally. If you’re going to use it horizontally, you can
attach permanent felt feet. See Attach feet (optional) for more information.
Connect the cables
1Attach the power cord and plug in
Sub. Be sure to push the power cord
firmly into Sub until it is flush with the
surface.
2Download the Sonos app from the
app store if you don't already have it.
You’ll use it to set up and control your
Sonos system. See Setup for more
information.
Note: Make sure you set up at least
one compatible speaker before
adding Sub.
Note: After Sub is paired with a Sonos speaker, you won’t see it displayed separately in your
system. Any changes you make to the speaker it's paired with, like volume, mute, or music
selection, will also affect Sub.
Attach feet (optional)
If you’re placing Sub horizontally on a floor, you can attach permanent felt feet (purchased
separately) to protect your floor. If you’re putting it on a rug or using it vertically, no need to
adhere the felt feet.
Note: The felt feet are not removable—a strong adhesive will keep them permanently
attached to Sub.
1. Lay Sub down so the Sonos logo is facing down. Make sure you adhere the felt feet to the
side that doesn’t have the Sonos logo.
2. Place the enclosed guide on one corner of the unit and fold the flaps over the edge.
3. Peel the backing off one of the feet.
4. Press the felt foot (sticky side down) onto the unit inside the circular portion of the guide.
5. Attach the other 3 felt feet the same way.
Product settings
To adjust Sub's settings, go to > System and select your Sub.
Sub Toggle On or Off to turn the sound from
Sub on and off.
Sub level
Use the slider to increase or decrease
volume. (You can use this setting to match
the subwoofer level to the level of your
main speakers.)
Phase control
Choose 0° or 180° to set the phase
control for your Sonos Sub or third-party
subwoofer (flip if you don't hear enough
bass in your usual listening position).
When a room with a Sonos Sub is tuned
using Trueplay, phase control is set and
can't be changed unless you disable
Trueplay.
Reset Resets all Sub audio settings to their
default values (0).
Change speaker pairing
You can easily change the Sonos speaker your sub is paired with.
If you’re moving it to a new room, wait for the status light to stop flashing after you plug the
sub back in.
1. Go to > System and choose the speaker your sub is paired with. It appears as
[speaker name (+Sub)] in your list of rooms.
2. Tap Remove Sub.
You can pair the sub with a different Sonos product or choose not to use it right now. It will
appear as "unused" in your list of products until you pair it with another Sonos speaker.
Connect a second Sub
You can easily connect a second Sub to your Sonos system.
Note: At least one Sub must be a Sub (Gen 3). If the button on the side is round instead of
square, it's a Sub (Gen 3). You cannot pair a Sub Mini with a Sub.
1. Go to > System and choose the speaker Sub is paired with. It appears as room
(+Sub) in your list of rooms.
2. Tap Connect Second Sub to get started.
Specifications
Feature Description
AUDIO
Amplifier Two Class-D digital amplifiers.
Speakers
Two force-canceling speakers positioned
face-to-face for deeper, richer sound and
zero cabinet buzz or rattle.
Dual acoustic ports Tuned to enhance Sub performance.
Frequency response Plays down to 25 Hz.
All digital sound
All filter settings, active equalization, and
time alignment are done digitally through
state-of-the-art DSP (Digital Signal
Processing) circuitry for zero-loss audio
quality and energy.
Automatic equalization
The system automatically adjusts audio
settings across all connected
components.
NETWORKING
Feature Description
Ethernet port
One 10/100 Mbps Ethernet port. You can
plug a Sonos product directly into your
router if your WiFi is unstable
Wireless connectivity
Using Sonos S2: Connects to WiFi
network with any 802.11a/b/g/n 2.4 or 5
GHz broadcast-capable router.
Using Sonos S1: Connects to WiFi
network with any 802.11b/g 2.4 GHz
broadcast-capable router. 802.11n only
network configurations are not supported
—you can either change the router
settings to 802.11b/g/n or connect a
Sonos product to your router.
GENERAL
Power supply Auto-switching 100 - 240V ~ 50-60 Hz 2 A
AC universal input
Dimensions (H x W x D) 15.3 x 6.2 x 15.8 in. (389 x 158 x 402 mm)
Weight Sub (Gen 3): 29 lb (13 kg)
Sub (Gen 2): 36 lb (16 kg)
Operating temperature 32 to 104 F (0 to 40 C)
Storage temperature -4 to 158 F (-20 to 70 C)
° ° °
° ° ° °
