Sonos Beam Gen 2 Manuel utilisateur
Beam
(Gen 2)
Gui…
Beam (Ge…
Overview The smart, compact soundbar for your
TV—
Feel sound all around you with the spacious 3D
experience of Dolby Atmos.
Stream music, radio, podcasts, and more when the TV is
off.
Effortless setup with just two cables and smart
Trueplay™ tuning.
Flexibility to expand your system over time and enjoy true
surround sound and multi-room listening.
Set up and control with the Sonos app (for Android and
iOS).
See Setup when you’re ready to add Beam (Gen 2) to
your Sonos system.
Controls and lights
Volume control
Touch for small
adjustments or hold to
quickly adjust the volume.
Note: You can also use
the Sonos app, your voice,
or your TV remote.
Play/Pause
Next/Previous
(music only)
Note: You can’t skip
forward or go back when
listening to a radio station.
Volume up (right)
Volume down (left)
Touch to play or
pause.
Hold to group with
other rooms and
products in your Sonos
system.
Swipe right to skip to
the next song.
Swipe left to go to the
previous song.
Microphone
Tap to turn the
microphone on or off:
Note: If you’ve installed a
voice service and the
microphone is off, you can
still use voice commands.
Just press and hold —
no need to start with a
wake word. When you
release the microphone
button, voice control turns
off again.
Status light
Displays the product's
connection to WiFi,
indicates when the volume
is muted, and signals
errors. Learn more
Note: If you don’t want to allow playback or volume adjustments using the speaker touch
controls, you can disable them in the room’s settings.
When the microphone
light is on, voice
control is on and your
voice service is ready
to respond.
When the light is off,
voice control is off.
Connector panel
1AC (mains) power input Use only the supplied power cord
(using a third-party power cord will
void your warranty).
Note: Insert the power cord firmly
until it is flush with the soundbar.
2Join button Press to connect during setup.
3Ethernet port Use an Ethernet cable if you want to
connect to a router, computer, or
network-attached storage (NAS)
device (optional).
4HDMI port Use to connect the soundbar to your
TV.
Select a location
You can wall mount Beam above or below your TV, or place it on a TV stand.
Place on a TV stand
Wall mount
You can secure the soundbar to a wall with a compatible wall mount. We recommend the
custom-designed Sonos Beam Wall Mount. See Wall mount for more information.
Place horizontally on a stable and level surface at least 2" (50mm) from the TV.
Don’t place vertically or on its side.
Don’t block the TV’s IR sensor.
If put on a shelf, place at the front and keep 2" (minimum) clearance on both sides for
best sound quality.
Keep 1" (25mm) space (minimum) above Beam so you can reach the touch controls.
For best sound quality, keep both ends of Beam at least 1" (30cm) from a wall or other
obstruction.
Connect the cables
Before you start
1Connect the power cord and plug in
Beam.
Note: Use only the supplied power
cord (using a third-party power cord
will void your warranty).
2Connect the HDMI cable (included) to
Beam's HDMI port.
Disconnect existing home theater or surround sound equipment from your TV.
Connect any external devices, like a cable box or DVD player, directly to your TV.
Turn your TV on.
3Connect the HDMI cable to your TV: HDMI cable to TV
Optical adapter to TV
If your TV has an HDMI ARC (or
eARC) port, connect the HDMI
cable to it.
(HDMI ARC is a special port that
looks like a standard HDMI port—
it may be on the back or side of
your TV. The ports look similar, but
the ARC port will be labeled ARC,
eARC, or ARC/eARC. If you
connect Sonos Beam to a
standard HDMI port instead, you
won’t hear any sound.)
If your TV doesn’t have an HDMI
ARC or eARC port, you'll need to
use the optical adapter:
Remove the protective cap
from the optical adapter, then
attach the optical adapter to
the HDMI cable.
Connect the optical adapter to
your TV’s optical digital OUT
port.
(The TV's optical adapter’s
port is “D-shaped”—make
sure the connector aligns
correctly into the port.
Inserting the adapter
incorrectly may damage the
cable.)
Voice services
Use your voice to control your Sonos system with any voice-enabled Sonos product—play
and control content, turn the volume up or down, and more.
Note: Voice control isn’t supported in every country yet—this feature will be available as soon
as Sonos and a voice service launch together in your region.
Microphone on/off
The microphone is used for voice control and for microphone-dependent features like
Trueplay tuning. Press to turn the microphone on or off—the microphone LED light will let
you know when your voice assistant is listening.
When the microphone light is on:
When the microphone light is off:
Sonos Voice Control: control your whole Sonos system with hands-free ease and
unmatched privacy. Sonos Voice Control comes ready to use—it only takes a few
seconds to add when you set up your speakers. More information
Amazon Alexa: you’ll need the Sonos app and the Alexa app with the Sonos skill
enabled. You’ll make some changes in both apps during setup. Learn more
Google Assistant: you’ll need the Sonos app and the Google Assistant app. You’ll make
some changes in both apps during setup. Learn more
Siri: you’ll need the Apple Home app. Add your AirPlay2-compatible Sonos speakers to
the Apple Home app and then use an iPhone, iPad, or Apple TV to ask Siri to play music
(currently limited to Apple Music). Learn more
If you set up a voice service, voice control is on and ready to respond.
Microphone-dependent features like Trueplay are available.
If you set up a voice service, voice control is off.
Microphone-dependent features like Trueplay are unavailable.
Trueplay
Every room is different. Trueplay tuning measures how sound reflects off walls, furnishings,
and other surfaces in a room, then fine tunes your Sonos speaker to make sure it sounds
great no matter where you've placed it.
Trueplay works on iOS mobile devices running iOS 8 or later. During tuning, you'll move
around the room holding your mobile device.
1. Select > System, and pick the room you want to tune.
2. Choose Trueplay Tuning to get started.
Note: Trueplay tuning isn’t available if VoiceOver is enabled on your iOS device. Turn
VoiceOver off in your device settings before tuning your speakers.
Auto Trueplay
Portable Sonos products like Sonos Roam and Move can tune themselves automatically. Auto
Trueplay uses your speaker’s microphone to detect the environment and make periodic tuning
adjustments so you get great sound wherever your speaker is and whatever you're listening
to.
Go to > System, and select your portable speaker to turn on auto Trueplay.
