Sonoff RF Bridge Manuel utilisateur
RF Bridge
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch • Manuel d'utilisation
2
English
3 –10
Čeština
11 –18
Slovenčina
19 –26
Magyar
27 –35
Deutsch
36 –43
Français
44 –51
3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Prague 7, www.alza.cz
4
Product Introduction
The device weight is less than 1 kg.
The installation height of less than 2 m is recommended.
LED indicator status instruction
LED indicator status
Status instruction
Blue LED flashes (one long and two short)
Quick Pairing Mode
Blue LED flashes quickly
Compatible Pairing Mode (AP)
Blue LED keeps on
Device is connected successfully
Blue LED flashes quickly once
Unable to discover the router
Blue LED flashes quickly twice
Connect to the router but fail to connect
to Wi-Fi
Blue LED flashes quickly three times
Upgrading
Red LED flashes quickly
Searching and adding …
Features
This is a 433MHz RF bridge with multiple features that allows you to connect a variety of
433MHz wireless devices through switching 433MHz to Wi-Fi. You can set schedules,
countdowns, alarm notifications and more.
Remote Control
Single/Countdown
Timing
Voice Control
Share Control
Sync Status
Alarm notification
Smart Scene
Camera Features
RF LED indicator (Red)
Wi-Fi LED indicator (Blue)
Input
Pairing button
5
Operating Instruction
1. Download “eWeLink” APP
2. Power on
Use the Micro USB cable to power the device. After powering on, the device will enter
the quick pairing mode during the first use. The Wi-Fi LED indicator changes in a cycle of
two short and one long flash.
The device will exit the quick pairing mode (Touch) if not paired within 3 mins. If you
want to enter this mode, please long press the pairing button for about 5s until the Wi-Fi
LED indicator changes in a cycle of two short and one long flash release.
3. Add Bridge
Tap “+” and select “Quick Pairing”, then operate following the prompt on the APP.
6
Compatible Pairing Mode
If you fail to enter Quick Pairing Mode, please try “Compatible Pairing Mode” to pair.
1. Long press Pairing button for 5s until the Wi-Fi LED indicator changes in a cycle of
two short flashes and one long flash and release. Long press Pairing button for 5s
again until the Wi-Fi LED indicator flashes quickly. Then, the device enters
Compatible Pairing Mode.
2. Tap “+” and select “Compatible Pairing Mode” on APP
Select Wi-Fi SSID with ITEAD-****** and enter the password 12345678, and then
go back to eWeLink APP and tap “Next”. Be patient until pairing completes.
Learn 433MHz codes
Click “+”, select the type of remote control. The device enters the learning mode when
you hear a beep from it, and the press the 433MHz remote control or trigger the sensor,
and you will hear two beeps to compete the learning process.
Learn up to 64 433MHz codes.
Specifications
Model
RF Bridge, RF BridgeR2
Input
5V 1A
RF
433MHz
Wi-Fi
IEEE 802.11 b/g/n 2.4GHz
Operating systems
Android & iOS
Working temperature
-10°C~40°C
Material
RF Bridge: ABS V0, RF BridgeR2: PC V0
Colors
RF Bridge: Black, RF BridgeR2: White
Dimension
62x62x20mm
7
Switch Network
If you need to change the network, long press the pairing button for 5s until the Wi-Fi
LED indicator changes in a cycle of two short and one long flash and release, then the
device enters quick pairing mode, and you can pair again.
Factory Reset
Deleting the device on the eWeLink app indicates you restore it to factory setting.
Common Problems
Q: Why my device stays “Offline”?
A: The newly added device needs 1-2 mins to connect Wi-Fi and network. If it stays
offline for a long time, please judge these problems by the blue Wi-Fi indicator status:
1) The blue Wi-Fi indicator quickly flashes once per second, which means that the
switch failed to connect your Wi-Fi:
a) Maybe you have entered a wrong Wi-Fi password.
b) Maybe there’s too much distance between the switch your router or the
environment causes interference, consider getting close to the router. If failed,
please add it again.
c) The 5G Wi-Fi network is not supported and only supports the 2.4GHz wireless
network.
d) Maybe the MAC address filtering is open. Please turn it off.
If none of the above methods solved the problem, you can open the mobile data
network on your phone to create a Wi-Fi hotspot, then add the device again.
2) Blue indicator quickly flashes twice per second, which means your device has
connected to Wi-Fi but failed to connect to the server.
Ensure steady enough network. If double flash occurs frequently, which means you
access and unsteady network, not a product problem. If the network is normal, try to
turn off the power to restart the switch.
8
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
9
EU Declaration of Conformity
Identification data of the manufacturer's / importer's authorized representative:
Importer: Alza.cz a.s.
Registered office: Jankovcova 1522/53, Holešovice, 170 00 Prague 7
CIN: 27082440
Subject of the declaration:
Title: RF Bridge
Model / Type: 433 MHz RF Bridge
The above product has been tested in accordance with the standard(s) used to
demonstrate compliance with the essential requirements laid down in the
Directive(s):
Directive No. 2014/53/EU
Directive No. 2011/65/EU as amended 2015/863/EU
10
WEEE
This product must not be disposed of as normal household waste in accordance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).
Instead, it shall be returned to the place of purchase or handed over to a public
collection point for the recyclable waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. Contact your local authority or the nearest collection point for further
details. Improper disposal of this type of waste may result in fines in accordance with
national regulations.
