S P E C F C A T O N S
N O T E S
FCC/IC Complian e
This device complies with FCC Part 15 Rules and C RSS-213 Rules. Operation of
this is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference that may be received, including
interference that may cause undesired operation.
FCC/IC RF Exposure Warning
• This product complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
• This product may not be collocated or operated in conjunction with any
other antenna or transmitter.
•To comply with FCC RF exposure requirements, the base unit must be installed
and operated 20cm (8 inches) or more between the product and any person’s
body (excluding extremities of hands, wrist and feet).
Te hni al Spe
Weight.......................................................0.5lb (0.23 Kg)
RF
- Range: 1600 feet line of sight
- Digital encoding for secured communications
- Any combination of up to 60 radio-transmit and non-radio transmit headsets
connected to single and multiple headset bases can operate simultaneously,
in close proximity to each other, with interference free communications.
Power
- 3.7V rechargeable lithium polymer battery
- >12 hours battery life when operating @25°C
- Over voltage, under voltage, over current and over temperature protection
- AC Charge source: supplied 12v, 500mA wall charger
- DC Charge source: 5v to16v, 1.5A minimum
- Charge time: 2 hours
Environmental
- Operating temperature -40°F (-40°C) to +158°F (+70°C)
- Storage temperature -40°F (-40°C) to +185°F (+85°C)
- Charging Temperature 32°F (0°C) to +104°F (+40°C)
MIL SPEC
- Humidity per M L-STD 810F and 810G
- Temperature Shock per M L-STD 810F and 810G
- Chemical Exposure per M L-STD 810F and 810G
SAE
- Salt Spray per J1455, Sec. 4.3
- Conducted mmunity per J1113-11
- Electrostatic Discharge per J1113-13
- Radiated Emissions per J1113-41
- Radiated mmunity per J1113-21
ISO
- Conducted Transients per 7637-2
W A R R A N T Y
Soneti s Standard Limited Warranty
Sonetics Corporation (“Sonetics”) warrants to the original purchaser of its prod-
ucts that products will be free from defects in materials and workmanship under
normal and proper use for the period of two years from date of purchase.
Sonetics Corporation will repair or replace, at its option, any products showing
factory defects during this warranty period, subject to the following provisions
and obligations:
1. This warranty applies only to a new product sold through authorized
channels of distribution.
2. All work under warranty must be performed by Sonetics Corporation.
3. All returned products must be shipped to our address, freight prepaid and
Sonetics will return products to customer via ground freight. Any expedite
fees or additional freight charges will be charged to customer.
4. Any attempt to repair, service, or alter the product in any way voids this
warranty.
5. This warranty does not apply in the event of accident, abuse, misuse,
liquid contact, improper installation, unauthorized repair, tampering,
modification, fire, earthquake, or damage from other external sources –
including damage caused by user-replaceable parts.
6. This warranty does not apply: (a) to consumable parts such as batteries,
ear seals, intercom bags, cables, external power supplies, parts listed as
accessories to a system, or other parts designed to diminish in function
over time unless a failure is due to a defect in materials or workmanship;
(b) to cosmetic damage or to defects caused by normal wear and tear or
aging of the product; (c) to damage caused by use with non-Sonetics
products; (d) to damage caused by operating the product outside the
permitted or intended uses or environments described by Sonetics; (e) to
damage caused by service performed by anyone who is not a representative
of Sonetics or an Sonetics Authorized Service Provider; (f) to a product or
part that has been modified without the written permission of Sonetics;
(g) if any Sonetics serial number has been removed or defaced.
7. This warranty does not extend to any other equipment, apparatus, vehicle,
aircraft, or watercraft to which this product may be attached or connected.
THE FOREGO NG S YOUR SOLE REMEDY FOR FA LURE N SERV CE OR DEFECTS.
SONET CS CORPORAT ON SHALL NOT BE L ABLE UNDER TH S OR ANY MPL ED
WARRANTY FOR NC DENTAL OR CONSEQUENT AL DAMAGES, NOR FOR ANY
NSTALLAT ON OR REMOVAL COSTS OR OTHER SERV CE FEES. TH S WARRANTY
S N L EU OF ALL OTHER WARRANT ES, EXPRESS OR MPL ED, NCLUD NG
THE WARRANTY OF MERCHANTAB L TY OR F TNESS OF USE, WH CH ARE
HEREBY EXCLUDED. TO THE EXTENT THAT TH S EXCLUS ON S NOT LEGALLY
ENFORCEABLE, THE DURAT ON OF SUCH MPL ED WARRANT ES SHALL BE
L M TED TO TWO YEA S FROM DATE OF PURCHASE. NO SU T FOR BREACH
OF EXPRESS OR MPL ED WARRANTY MAY BE BROUGHT AFTER TWO YEA S
FROM DATE OF PURCHASE.
Subject to the terms and limitations of this Sonetics Standard Limited Warranty,
this warranty covers any new covered product found to be defective within the
applicable warranty period. Sonetics reserves the right to examine the alleged
defective covered product to determine whether this Sonetics Standard Limited
Warranty is applicable, and final determination of warranty coverage lies solely
with Sonetics. f Sonetics determines that warranty coverage applies, Sonetics
reserves the right to either repair or replace a covered product or any part
thereof, as determined by Sonetics in its sole discretion. f the product has
been subjected to conditions which exclude coverage under the warranty,
customer will be so advised. Customer may then authorize paid repair service
or other disposition of the product. Notwithstanding any other provision of this
warranty, if you sell or otherwise transfer ownership of your covered product,
this Sonetics Standard Limited Warranty shall automatically terminate.
