Raising Audio to an Art Form

QUINTETTE

THE HEIGHT OF

ARTISTIC EXPRESSION.

Life is richer with sound. It sings. It waltzes. It dances

with energy. And Sonance Quintette™series in-ceiling

speakers were designed to bring that sound to life

with outstanding audio reproduction and exquisite

finesse. No distracting boxes or towers. No unruly

speaker wires. Just the artistic expression you’ve

infused into your room and throughout your home—

and the music you choose to accompany it. In fact,

Quintette speakers were specifically designed for

background music, bringing out its true notes through

sophisticated design and nearly a quarter century

of Sonance innovation.

QUINTETTE™SERIES

SPEAKERS FROM

SONANCE.

HEAR MORE. SEE LESS.

A paintable aluminum grille blends high performance with a small unobtrusive size. A

5-1/4" polypropylene cone woofer with rubber surround produces strong, low-distortion

bass, while dome tweeters deliver crisp, high-frequency performance to a wide

listening area. Further, pivoting tweeters on the 522QR direct sound at listeners

for clear audio even when placement options are limited. And thanks to Quintette’s

high-sensitivity, fewer speakers can cover a larger area when it comes to distributed

audio applications. With a footprint resembling can lighting and the RotoLock®

mounting system, installation is quick and easy.

HIGH-QUALITY DETAILS.

At Sonance, great looks and great sound go hand-in-hand. The result is an unparalleled audio experience.

It’s apparent in everything from the paintable grillework and the high-quality crossover components to unadulter-

ated sound quality.

QUINTETTE 522QR

Tweeter: 3/4" (19mm) Cloth dome pivoting

Woofer: 5-1/4" (133mm) Black polypropylene cone with a rubber surround

Frequency Response: 55Hz – 20kHz ±3dB Sensitivity: 90dB (2.83V / 1 meter)

Power Handling: 5 watts minimum; 60 watts maximum

Impedance: 8 ohms nominal; 6 ohms minimum

Grille: Perforated aluminum Dimensions (Dia x D): 8" x 3-1/4" (203mm x 83mm)

Cutout Diameter: 6-3/4" (171mm) Weight: 7.0 lbs (3.2kg) per pair

QUINTETTE 521QR

Tweeter: 5/8" (16mm) Polycarbonate dome

Woofer: 5-1/4" (133mm) Black polypropylene cone with a rubber surround

Frequency Response: 60Hz – 20kHz ±3dB Sensitivity: 88dB (2.83V / 1 meter)

Power Handling: 5 watts minimum; 45 watts maximum

Impedance: 8 ohms nominal; 6 ohms minimum

Grille: Perforated aluminum Dimensions (Dia x D): 8-1/4" x 3-1/4" (210mm x 83mm)

Cutout Diameter: 6-7/8" (175mm) Weight: 6.0 lbs (2.7kg) per pair

BREAKING SOUND

BARRIERS SINCE 1983.

What began with a set of high-fidelity speakers master-

fully built into the wall, has resulted in one of the most

innovative and respected architectural audio companies

in the world. Sonance has since kept its edge in the

market by developing some of today’s most brilliant and

inspired audio products that let you savor your music

among family, friends and guests. From in-wall and

in-ceiling home theater systems to whole-house-yard

and distributed audio, all Sonance innovations are

designed to seamlessly blend sonically superior music

into any home or environment. Our talented engineers

utilize our state-of-the-art anechoic chambers, listening

rooms, and laboratories to create superior product

performance that gives you an unsurpassed audio

experience wherever you enjoy music.

212 Avenida Fabricante

San Clemente, CA 92672-7531

TEL 800-582-7777 | 949-492-7777

FAX 800-538-5151 | 949-361-5151

www.sonance.com

RotoLock are trademarks of Dana Innovations. 33-4012 9/05
