SONAB CLOUD 9 RANGE
CLS, Loudspeaker
The CLS is equipped with the GLOBAL trac Multi adapter GA 69 which suits almost
every 3-phase tracks on the market. The CLS is made for mounting direct into the
tracks for optimum convenience. The CLS can receive it´s audio signal either wirelessly
from the CTX transmitter, or wired from a CGV or another CLS or CSW speaker.
CSW, Subwoofer
The CSW should be mounted on the wall with the included wall bracket. If possible on
the same height as the CLS speakers. The CSW have both wireless and wired capa-
bilities, so both installation options are available. For a convenient set up of the volume
adjustment in wired mode there is an IR remote included with the subwoofer.
CTX, Wireless transmitter
The CTX connects directly to the Mac or PC through the USB interface. All audio avail-
able on the computer (also streaming services like Spotify or Youtube) can be wireless
transmitted. If there are no computer available as source the CTX has the option to also
receive an analogue signal through the 3,5mm line input. The 3,5 mm line in can be
connected to any analogue source.
CVM Wireless volume control
The CVM must be used if the installation should be wireless or be a combination
of wireless and wired. The CVM controls the master volume and the different zone
volumes.
CVX, Volume control extender
The CVX, wired volume extender is available to extend the master volume from the
CVM or CGV to a more convenient placement. Using the CVX also prevents unwanted
tampering with the CVM or CGV, where also different zone volumes can be set (CVM),
or switching of inputs (CGV).
CEX, Wireless range extender
The CEX wireless extender is used to extend the wireless network, or to go around
difficult wifi conditions.
CGV, Wired volume control
The Sonab CGV should be used if a wired only installation is intended. The CGV has
inputs for 2 different analogue sources. The CGV unit contains the master volume for
the complete system.
CLS optional wallbracket
Optional wall bracket/table stand for CLS loudspeaker. Use if location don´t have
tracks for power. Comes with power cord to connect to AC outlet.
This is an overall general description of the Sonab Cloud 9 music system. For product
specifications of the Sonab products please see the specific user manual that comes with
each of the products. Following products are available in the Sonab Cloud 9 series:
