SOMFY TAHOMA RTS Guide de configuration rapide
INTEGRATION GUIDE
INTEGRATION for
TAHOMA®RTS
VERSION 1.2 |AUGUST 2021 |Prepared by PROJECT SERVICES
SMARTTHINGS INTEGRATION for TAHOMA® RTS
INTEGRATION GUIDE
TABLE OF CONTENTS
I. OVERVIEW ------------------------------------------------------- 3
INTRODUCTION
RESOURCES & APPLICATIONS
II. SETUP ----------------------------------------------------------- 4
SMART PHONE & TABLET REQUIREMENTS
CONNECTIONS & INDICATORS
SYSTEM CONFIGURATION
LINK TAHOMA TO SMARTTHINGS
EDIT TAHOMA DEVICES
CONTROL TAHOMA DEVICES
CREATE SCENES
CREATE AUTOMATIONS
DELETE SCENES OR AUTOMATIONS
UNLINK TAHOMA FROM SMARTTHINGS
APPENDIX ------------------------------------------------------------ 13
A. AVAILABLE ACTIONS
2of 13
The Somfy Organization strength has been demonstrated with 50 years of experience in motorization. As
leaders in the shading industry with innovation and modernization solutions for homes and commercial
buildings, Somfy offers the widest range of strong, quiet motors and controls for all types of applications and
technologies.
Who is this Guide for?
This guide is aimed at providing support and guidance to homeowners, installers and dealers for achieving
complete automation of Radio Technology Somfy® (RTS) motors and TaHoma® Smartphone and Tablet
Interface.
What does this Guide contain?
The sections of this guide contain walkthroughs and methods of controlling RTS motors using the TaHoma®
Smartphone and Tablet Interface as the bridge between SmartThings and Smart Shading by Somfy.
This guide discusses the method of integration with SmartThings.
For questions or assistance please contact technical support:
(800) 22-SOMFY (76639)
technical[email protected]
How should this Guide be used?
This guide is intended to be used as a reference manual.
I. OVERVIEW
INTRODUCTION
Visit the Google Play or iOS App Store for the following SmartThings App:
RESOURCES & APPLICATIONS
Visit www.somfypro.com for the following guides:
•Somfy TaHoma Smartphone and Tablet Interface Programming Guide
•Somfy RTS Pocket Programming Guide
Subscribe to the Somfy YouTube Channel www.youtube.com/somfysystems
iOS App Store
Google Play Store
iOS App Store
Google Play Store
Visit the Google Play or iOS App Store for the Somfy TaHoma North America App:
3of 13
II. SETUP
CONNECTIONS & INDICATORS
Configuration Button
Press to enter Wi-Fi Mode
for setup
Micro USB Port
Connect power
or Ethernet Adaptor
LED BEHAVIOR:
BLUE
DIRECTLY CONNECTED
Wi-Fi MODE
RED
POWERED,
NOT CONNECTED
TO CLOUD SERVER
ORANGE
STARTING UP
GREEN
CONNECTED TO NETWORK
SMART PHONE & TABLET REQUIREMENTS
SYSTEM CONFIGURATION
A fully operational TaHoma system is required prior to SmartThings programming. The TaHoma Interface supports up to 40 channels of RTS. RTS
devices programmed to an RTS channel will only receive commands from the associated TaHoma Interface.
Interfaces must be placed within 25-35’ of the RTS devices they control.
•Confirm with Shade Commissioning Agent that the TaHoma Interface firmware is up to date
•Must have one Samsung SmartThings account per TaHoma system or project
•Confirm that a SmartThings enabled hub is powered on and connected to a network with internet
REAR FRONT
TaHoma® Ethernet Adaptor
#1870470 (Sold Separately)
Connect for a wired local area
network connection
Micro USB
Connect to TaHoma interface
for power and Ethernet
Micro USB Port
Connect power through
Ethernet Adaptor
Ethernet Port
Connect to network
router or switch
The SmartThings app is compatible with the following operating systems and software versions:
IOS 11.0+
Android 7.0+
The Somfy TaHoma® Smartphone and Tablet Interface provides a single platform for Somfy RTS and future
ecosystems with a wide range of interior and exterior applications.
•The TaHoma® Interface supports up to 40 RTS channels
•Install up to 10 interfaces as zone controllers to increase the RTS range
•The TaHoma® can support a maximum of 40 scenes with schedules per install
Each TaHoma Interface is connected to Wi-Fi or directly to the local area network by an optional Ethernet Adaptor
for IP Integration with third-party control systems. TaHoma® is compatible with the Somfy Synergy™ API.
Details of this controller and commissioning instruction are available in the
Somfy TaHoma Smartphone and Tablet Interface Programming Guide.
4of 13
1) From the Favorites Screen,
SELECT the “+” icon
2) SELECT “Device”
3) SELECT the magnifying
glass to search for “Somfy” or
SCROLL to find Somfy
4) SELECT “Somfy,” SELECT
“Window Treatment”
5) SELECT “Somfy without
SmartThings Hub”
6) SELECT a Location and Room
for the Somfy device
Add Somfy to any room or the room
where TaHoma Interface is installed.
Discovered devices can be moved to the
respective rooms later.
Example: “Bedroom 1”
LINK TAHOMA TO SMARTTHINGS
To enable scene and automation control from the SmartThings app, follow the steps below:
From the SmartThings App, ensure the correct account is enabled prior to Linking TaHoma.
5of 13
TaHoma has been linked to SmartThings.
All paired devices in TaHoma will appear in the room initially selected.
To disconnect TaHoma North America refer to the Unlink TaHoma from SmartThings section of this Guide.
7) Enter the TaHoma Login credentials used to
Register during TaHoma Programming
8) SELECT “LOG IN”
9) SELECT “YES” to authorize SmartThings access
to the Somfy account
The display will read, "Connection between
SmartThings and TaHoma North America is
successful."
10) SELECT “X” to finish the setup
11) SELECT “Done”
6of 13
EDIT TAHOMA DEVICES
1) From the Devices screen,
SELECT a Room, SELECT a
Device
Example:
Room: Bedroom 2
Device: Bedroom blackouts
2) SELECT a command to
Open or Close the blind
SmartThings does not keep a record
of last commands sent for Somfy
RTS motors.
To command RTS shades to Open or Close, follow the steps below:
1) SELECT the Device to edit,
SELECT the Options icon
from the top right corner
2) SELECT “Edit” to:
•Change name of the device
•Change location or room of
device
•Set as favourite
•Add device to Home screen
•Delete the device
A portal to Linked Services is located
under each device’s edit menu, used
to disconnect from TaHoma.
3) SELECT “Save”
This integration does not allow a Stop command. If an RTS blind has a MY position programmed,
this can be triggered in a SmartThings Scene and/or Automation by selecting Pause.
Pause command = MY Position.
CONTROL TAHOMA DEVICES
7of 13
To make changes to linked devices, follow the steps below:
CREATE SCENES
1) From the Favorites screen
SELECT “+”
2) SELECT “Scene”
3) Enter a name for the Scene,
SELECT “+” under Actions
Optional: Select “Change icon”
to change the Scene’s icon
4) SELECT "Control Devices,"
SELECT the Device
Example: Bedroom blackouts
5) SELECT “Next”
The Scene has been created.
Set Scenes as a favorite by clicking the options icon and selecting the Scenes to be favorited.
To add the Scene to an Automation, refer to the Create Automations section of this Guide.
6) SELECT “Curtain,” SELECT a
Command:
•Open/Up
•Close/Down
•Pause/Stop
7) SELECT “Run” to test the
Scene
Optional: Set as favourite
8) SELECT “Save”
Scenes allow multiple devices to be controlled with various actions.
To trigger Scenes with the tap of a finger, follow the steps below:
TaHoma supports 40 Scenes with schedules.
8of 13
CREATE AUTOMATIONS
To trigger automations based on a set of conditions such as specific times, days of the week or when
another device is activated (such as detecting motion or mobile presence), follow the steps below:
An Automation has been created.
1) From the Automation
Screen, SELECT “+”
2) SELECT “Add Automations”
3) Under “If” SELECT “+” to
choose conditions that will
start the Automation
Multiple conditions can be
added. Example: Time
•Specific time and day
•Period of time (a start and an
end time)
•Any time (once per day)
•Sunrise or Sunset
3) SELECT “Save”
4) Under “Then” SELECT “+” to
choose what happens when
conditions are met
5) SELECT “Control devices”
6) SELECT the device and set
the command
Example: Bedroom
blackouts(Close)
7) SELECT “Save”
8) Name the Automation,
SELECT “OK”
Automations can be turned on and
off anytime using the toggle button
next to the Automation.
9of 13
DELETE SCENES OR AUTOMATIONS
If a Scene or Automation is no longer required, follow the steps below:
DELETE A SCENE -
1) From the Automation
Screen, SELECT the
Options icon button
from the top right corner
2) SELECT “Delete”
3) SELECT “-” next to the
scene to be deleted
4) SELECT “Delete”
DELETE AN AUTOMATION -
1) From the Automation
Screen, SELECT the
Options icon button from
the top right corner
2) SELECT “Delete”
3) SELECT “-” next to the
scene to be deleted
4) SELECT “Delete”
The Scene or Automation has been deleted.
10 of 13
