P.18 P.19
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS
Speed Wash: This procedure is suitable for washing few and not very dirty clothes quickly.
Sanitary: This cycle is specially set in this machine to clean the drum and tube. It will provide
an extra high temperature sterilization to make the clothes washing more green.
When proper amount of chlorine bleaching agent is put in, the barrel cleaning effect will be
better. The customer can use this procedure regularly according to the need.
NOTE: Do not use this cycle with clothes, and do not add detergent or fabrics softener.If you
use this cycle on a monthly basis, the wash drum will be kept clean.
Rinse ＆ Spin: Select this option to rinse and spin a load separately from a regular cycle.
This can be helpful in preventing fresh stains from setting in fabrics.
Refresh: During this cycle, there is only hot air rather than water ejecting from inside the drum
to wash the clothing. Also it can be used to dry clothes weighs less than 0.5kg.For example:
a shirt or a short.
Spin: Separate Spin Procedure. Soap water or rinse water shall be drained out before spinning.
Cotton/Normal Dry: This is a normal drying procedure. Moisture content of the clothes
after drying is -3%~3%.The load of drying is not more than 3.5kg
NOTE: The drying time according to the weight.
OPTION BUTTONS
Drying: This option will add a drying cycle to the selected cycle.
Extra Rinse: This option will add an extra rinse cycle to the selected cycle.
My Cycle: When this button is pressed continuously, this cycle will be remembered.
You can quickly choose this cycle only by press this button at the washer next start.
Delay: The delay start light will flash to indicate the delay time.It will start the cycle
after【xx】hours.
Soil level: It's divided into three levels. Choose the right soil level before the washer
started is necessary.
Spin speed: The washer drum spins at up to 1200 RPM. This reduces drying time
and saves energy. Press the SPIN SPEED button until the indicator light for the desired
setting is lit. Some fabrics, such as delicates, require a slower spin speed.
Temp.: Press this button to select the temperature you need. And here are four
temperature can be selected.
Pre-wash: Select this option to add a prewash and spin cycle to the chosen cycle.
This is especially useful for heavily soiled items.
Washing Clothes at first time
Before washing clothes at first time, the washing machine shall be operated in
one round of the whole procedures without clothes in as follows:
1.Connect power source and water.
2.Put a little detergent into the box and close it.
3.Press the button “Power”.
4.Press the button “Start/Pause”.
The drawer is separated as follows:
I: Pre-detergent or washing powder.
II: main detergent, softener, pre-dip,
bleaching or decontaminating products.
: washing additive, such as fabric softener or tackifier.
Put detergent into washing machine.
1.Pull out the drawer.
2.Fill pre-detergent into Case I (when necessary).
3.Fill detergent into Case II.
4.Fill softener into Case (when necessary).
Notes:
As for the agglomerated or ropy detergent or additive, before they are poured into the detergent box,
it is suggested to use some water for dilution to prevent the inlet of detergent box from being blocked
and overflowing while filling water.
Do not use bleach. Hazardous fumes can form
Start up washing machine
Connect the power. Check if water pipes are connected properly. Open the tap completely.
Put in the clothes to be washed and fill in the detergent and tackifier. Then press the button
“Power”,Select the proper procedures and functions and press the button “Start/Pause”.
Select the procedure
The proper washing procedures shall be selected according to the types, quantities, and
dirtiness of the clothes to be washed in combination with the following washing
temperature table.
Ⅰ
Ⅱ
Extra Hot
Hot
Warm
Seriously besmirched, pure white cotton or flax (for example: coffee
table cloths, canteen table cloths, towels, bed sheets)
Moderately besmirched, colorful flax, cotton and synthetic articles
with certain decolorizing degree (for example: shirts, night pajamas;
Slightly besmirched, pure white flax (for example: underwear)
Normally besmirched articles (including synthetic and wool)
Note:
When choose the drying cycle, it can be achieved by cooling water.
Pre-wash Wash Rinse Spin Drying
Add garment: This operation can be executed during the washing procedure.
When the basket of the washing machine is still rolling and there is large amount of water with high
temperature in the basket, The state is unsafe; the door cannot be opened forcefully.
