1.Main Features
Video And Audio
H.264 High Profile video compression, real time recording( 25 fps(PAL) / 30 fps(NTSC)
for each channel. Frame rate adjustable for each channel.
AAC(Advanced Audio Compression) for audio.
D1 resolution for each channel, 720x480@30 fps(NTSC).
Support 4/2 channel video and 4/2 channel audio recording；
Power Input
Support from +8V DC to +32VDC. Applicable for vehicles with +12V or +24V battery.
When the power input connects in reverse polarity, the auto-protect function can
prevent the recorder and battery from damage.
The recorder provides each camera with stable +12V DC power; DVR can detect the
short cut on power circuit.
Can use ignition to control the power.
Recording mode
Recording can be set to start the engine
Support Motion detection recording.
Support alarm recording. recording can be set to star open the door
Support timer switch/temer recording
Speed and Vehicle status recording
Support 1 channel speed, 3-way universal sensor inputs, can be
simultaneously displayed and recorded license plate, vehicle speed,
braking, steering, Ming sirens and other traffic state
Support over-speed alarm
Achieve reversing video automatically switches
Built-in GPS model,Can record speed and Wheel Path.
SATA 1.8’’ hard drive and SD card for storage
Support SATA 1.8’’ hard drive （just for 5 mm Thickness）and SD card for storage,
external USB device (memory stick or hard drive) is ok .
NOTE
If you remove the SD card while recording or playing, it might cause the damage of the file
on SD card. While recording or playing, the yellow light on the front panel will be on. So
please stop recording or playing until the yellow light is off if you need to remove the SD
card.
Multiple player supported
You can use the following player to play back the record file.
