SOGEDIS D4 Series Manuel utilisateur

Manuel de service

Séries D4

Table of Contents

1. Safety Precautions ..................................................................................................................................................4

2. Specifications..........................................................................................................................................................5

3. Control Panel and Acronyms ...................................................................................................................................6

4. Test Mode...............................................................................................................................................................7

4.1. Autotest.......................................................................................................................................................................... 7

5. Service Mode ..........................................................................................................................................................9

5.1. Service Autotest............................................................................................................................................................... 9

5.2. Failure Codes .....................................................................................................................................................10

6. Critical Torque Values ...........................................................................................................................................10

7. Disassembly and Assembly Instructions.................................................................................................................11

7.1. Top Plate ....................................................................................................................................................................... 11

7.2. Door.............................................................................................................................................................................. 11

7.3. Spring Wire.................................................................................................................................................................... 12

7.4. Detergent Drawer.......................................................................................................................................................... 12

7.5. Control Panel................................................................................................................................................................. 13

7.6. Electronic Card & Fuse ................................................................................................................................................... 14

7.7. Front Panel .................................................................................................................................................................... 15

7.8 Dryer Card ...................................................................................................................................................................... 16

7.9 Dryer Unit....................................................................................................................................................................... 16

7.10 Support Bracket............................................................................................................................................................ 18

7.11 Detergent Drawer Housing............................................................................................................................................ 18

7.12 Power Cable Group and EMI Filter................................................................................................................................. 18

7.13 Electronic Pressure Switch (EPS).................................................................................................................................... 19

7.14 Door Lock* ................................................................................................................................................................... 19

7.15 Drain Pump................................................................................................................................................................... 20

7.16 Front Counterweight*................................................................................................................................................... 20

7.17 Heater .......................................................................................................................................................................... 20

7.18 Tub Bellow Seal*........................................................................................................................................................... 21

7.19 Transport Screw............................................................................................................................................................ 21

7.20 Upper Counterweight* ................................................................................................................................................. 21

7.21 Washing Group............................................................................................................................................................. 22

7.22 Shock Absorber Pin....................................................................................................................................................... 22

7.23 Driven Pulley................................................................................................................................................................. 22

7.24 Driven Pulley................................................................................................................................................................. 22

7.25 Motor........................................................................................................................................................................... 23

7.26 Tub............................................................................................................................................................................... 23

8. Component Specifications.....................................................................................................................................24

8.1. Drain Pump.................................................................................................................................................................... 24

8.2. Heater ........................................................................................................................................................................... 25

8.3. Washer NTC................................................................................................................................................................... 26

8.4. Valve ............................................................................................................................................................................. 27

8.5. Electronic Pressure Sensor (EPS)* .................................................................................................................................. 28

8.6. Motor............................................................................................................................................................................ 29

8.7. Door Lock* .................................................................................................................................................................... 30

8.8. Fan Group...................................................................................................................................................................... 31

8.9. Dryer Heater.................................................................................................................................................................. 32

8.10. Dryer NTC .................................................................................................................................................................... 33

8.11 Component Control on PCB........................................................................................................................................... 34

9. Wiring Diagram* ...................................................................................................................................................37

10. Troubleshooting..................................................................................................................................................38

About Content

This service bulletin is prepared for all OEM products within D4 range. Therefore you may encounter information

about some optional components that may not exist in your product. As this is a generic service bulletin covering all

range, please ignore and skip extra/optional component information. Sections marked with asterisk (*) sign contain

information about optional components.

Information already exists in user manuals is not included in this service manual. Please refer to user manual of your

product for basic installation, operating, maintenance and troubleshooting issues.

Contact

For your inquiries please send an email to:

WashingMachineCustomerSupport@vestel.com.tr

You can also open a support ticket using Service Support Page:

https://www.vestelservice.com/VestelService/

Acronyms:

WM : Washing Machine

W&D : Washer & Dryer

WMCS : Washing Machine Customer Support

TJ : Twinjet

UI : User Interface

SI : Service Interface

A : Available

NA : Not Available

1. Safety Precautions

Important:

This service information is designed for experienced repair technicians only and is not designed

for use by the general public. It does not contain warnings or cautions to advise non-technical

individuals of potential dangers in attempting to service a product. Products powered by

electricity should be serviced or repaired only by experienced professional technicians. Any

attempt to service or repair the product or products dealt with in this service information by

anyone else could result in serious injury or death.

Warning:

Before any disassembly/repair operation make sure appliance is unlplugged water tap is closed

and heating elements are cooled down. There is electrical shock, burning and flood risk.

Warning:

Please replace whole cable group even in case there is any minor failure with cables / terminals /

sockets. Never try to repair nor to solder cable group. It may cause smoke, ignition and there is

major risk of electrical shock.

Important:

Always use insulator gloves to prevent injury by metal edges or to prevent electrical shock during

electrical tests.

Work with uniforms having long sleeves to protect your arms from metal edges.

Always use original spare parts. You may harm appliance, end user, environment or yourself

using untested and unapproved 3rd party spare parts.

Use right tools to prevent any wear or damage to components during assembly/disassembly.

2. Specifications

Here you will find descriptions of generic specifications for the range specified for this service manual. Please refer to

product fiche and user manual for detailed technical specifications.

*Twinjet System:

Twinjet system is designed to obtain a better washing performance by directly injecting water

with detergent using a recirculation system and two nozzles connected to it. With twinjet

system, water consumption is decreased by 30%, energy consumption is decreased by 10% and

washing time is decreased by 15%

Twinjet system is valid for all programs except spin and drain mode. The system dos not function

during Water inlet, heating, spinning, drain phases.

Even with a large load of 8 kg. the washing machine will have the minimum energy consumption

by the help of Twinjet system.

Washing machines with Twinjet system are very environment-friendly by having maximum

washing performance with minimum water consumption.

Eco-Logic System:

Half load detection system, thus using less water and power accordingly. This system is available

for cotton programs only.

Foam Protection System:

Foam Protection System is a safety algorithm that interrupts normal program flow and reduces

foam level by taking water and draining. This algorithm protects machine and environment

avoiding over foaming inside tub in case any customer misuse such as detergent overdose or use

of foamy cleaning agents.

Overflow Protection System:

Overflow protection is another safety algorithm in case of a flood risk. If there is more water in

tub than expected by algorithm, it will start to the drain routine giving E04 failure code. For

example this may happen in case of a valve failure and the machine constantly takes water. This

algorithm will keep drain routine, keeps water leveled and protects environment and machine

avoiding any flood risk.

Unbalanced Load Detection and Control System:

Unbalance Control System is another safety algorithm that protects the machine and

environment avoiding machine movement due to vibration during spinning profile. The

algorithm tries to balance load by a special balancing agitation, postponing spin profile till it is

balanced. This avoids spinning while load is unbalanced and prevents any possible physical harm

both to the appliance and to surroundings.

3. Control Panel and Acronyms

Program selector 16 programs including off position

SW1

Switch 1, Start / Pause

SW2

Switch 2, Option 1 (Delay Timer)

SW3

Switch 3, Option 2 (Drying Level)

SW4

Switch 4, Spin Speed Selection

SW5

Switch 5, Temperature Selection

LED 1, Start/Pause LED

LED 2, Drying Level 1 LED

LED 3, Drying Level 2 LED

LED 4, Drying Level 3 LED

LED 5, Drying Level Option LED

LED 6, Delay Time LED

SW5

SW4

SW3

SW2

SW1

4. Test Mode

4.1. Autotest

4.1.1. Autotest Steps

1. Press and hold SW5.

Autotest follows a predefined flowchart in order. Unlike

service autotest, autotest automatically skips to next step

upon completing one. The steps of the test are as follows:

Step1:

The drain pump is checked.

Step2:

Motor ramps to max spin speed while valves are activated

in order.

Step3:

Motor stops, both valves are activated simultaneously.

Step4:

The motor turns to right. Also, dryer valve is activated.

Step5:

The motor turns to left.

Step6:

Both valves are activated. (Water intake for heating)

Step7:

Washer NTC is checked.

Step8:

Washer Heater is checked.

Step9:

Dryer resistance I and I&II are checked.

Step10:

Dryer NTC is checked for 2sec.

Step11:

Fan is checked.

In case of no failure test ends after this step and “End” is

displayed. In case of an error detection EXX and error

definition will pop up on display. (where XX is the error

number 1 to 10 )

Please see following autotest chart for details.

2. While pressing SW5, turn PR to 1st position

(Cotton). Wait 3 seconds and release SW5. During

test “AU” is visualized on display.

3. When autotest is finished, END screen is

visualized.

AUTOTEST

Time in seconds (to be adjusted)

EV1 + EV2 valves up to first level frequency (Depends on the water level)

Washer NTC check

Washer heater resistance

EPS measurement

Motor Ramp to max spin (max. is 20 sec.)

EV1 (flowrate dependent of washer)

EV2 (flowrate dependent of washer)

Dryer valve

Time until motor is stopped (Depends on the motor stop time)

Motor Preferred Run (Direction to Right)

Motor Inverse Run (Direction to Left)

100

Entering autotest

Changing power to 220 50Hz

Main Voltage 50 Hz

Door Lock Powered (Depends on door lock)

Pump

EPS measurement: It checks the EPS and if it OK, it continues the autotest; if it is NOK then cancel the Autotest and go to the selection mode. Also if any frequency can not be detected, then it means there is problem with connecion

or EPS, so it gives E10 which is EPS error and cancels the autotest & goes to the selection mode.

Dryer Ntc detection : Software will detect NTC's resistance value and will check if the temperature is between 0°C < Tdetected < 50°C. If it is inside the range, heating step will be done.

Washer Ntc detection : Software will detect NTC's resistance value and will check if the temperature is between 5°C < Tdetected < 40°C. If it is inside the range, heating step will be done.

If temperature value is outside the range, then it means NTC is detecting the temperature in a wrong way and heating step will be skipped. Additionally if NTC connector disconnected it should shows NTC failure code(E05) on display.

Dryer resistance I

Dryer resistance I + II

Dryer NTC

Fan

End Visualization

5. Service Mode

5.1. Service Autotest

5.1.1. Service Autotest Steps

1. Press and hold SW4.

If you turn knob position to other program between 1st to

3rd it will skip current test and start the selected one. It is

recommended not to skip any steps for a detailed

checkup. Unlike autotest, service autotest starts next test

step manually by rotating program selection knob.

Step1:

There will be a certain amount of water intake and then washer heater is

activated for 8 minutes. Washer NTC values are checked in this period.

In case of a washer heater/NTC failure, it pops up E05 error displaying

“E05” on SW3.

At the end of heating, "SAU" visualization should make slow blink to

indicate that the step is over. You can turn program knob to 2nd position

to continue with step2.

*During this step if EPS detects high water level, overflow algorithm is

applied and E04 is released.

Step2:

Drain pump is activated; in case of a pump failure it pops up E03 error.

At the end of pump activation, "SAU" visualization should make slow

blink to indicate that the step is over. You can turn program knob to 3rd

position to continue with step3.

Step3:

Dryer Heater I and fan is activated. After 3 mins if there will be no

temperature change (ΔT< 10°C), it will release E14 failure.

If temperature increases accordingly (ΔT > 10°C), "SAU" visualization

should make slow blink to indicate that the step is over. You can turn

program knob to 4th position to continue with step4.

Step4:

Dryer Heater II and fan is activated. After 3 mins if there will be no

temperature change (ΔT< 10°C), it will release E14 failure.

If temperature increases accordingly (ΔT > 10°C), "SAU" visualization

should make slow blink to indicate that the step is over. You can turn

program knob to 5th position to continue with step5.

Step5:

Rapid 15’program algorithms is run to test all washing components, the

only difference is error codes are displayed which normally are not

displayed to end user.

If no error found in test program ”SAU" visualization should make slow

blink to indicate that the step is over. You can turn program knob to 6th

position to continue with step6.

Step6:

A 5 mins drying program is run to test all drying components.

If case of no error service autotest ends and "End" is displayed.

*If user changes the selector position, machine will do what is defined

for the new selected position.

2. While pressing SW4, turn PR to 1st position

(Cotton). Wait 3 seconds and release SW4. Step 1 of

service autotest will start. During test “SAU” is

visualized on display. Please see details about steps

in right column.

3. When autotest is finished, END screen is

visualized.

5.2. Failure Codes

Error Indication

Error Number

Indication in UI

Indication in SI

Door/Door Lock Failure

E01

Lack of water

E02

Pump failure

E03

Overflow

E04

NTC or Heater Failure

E05

Motor Failure

E06

Configuration Failure

E07

Motor Triac Failure

E08

Voltage Error

E09

Electronic Pressure Sensor

E10

Dryer Board Connection Failure

E11

Dryer Thermostat Failure

E14

Twinjet Failure

E15

Dryer Overheated Failure

E16

Flowmeter Failure

E17

Dryer NTC Failure

E18

6. Critical Torque Values

Assembly Locatıon

Bolt/Nut/Screw

Torque

Min. (Nm)

Torque

Nom. (Nm)

Torque

Max.

(Nm)

Air Pressure

Wrench

Speed (rpm)

Transport Screw Assembly

Transport Screws

6.50

7.00

1000

Motor Assembly

Motor Screws

6.00

6.50

7.50

800

Front Concrete Weight - Front

Tub Assembly

Front Counterweight

Screws

14.00

14.50

14.75

600

Upper Counter Weight

Assembly

Upper Counterweight

Screws

25.00

27.50

30.00

440

Pulley –Drive Shaft –

Washing Group Assembly

Pulley –Drive Shaft

Assembly Bolt

39.50

40.00

40.50

440

Washer Heater Assembly

Heater Assembly Nut

3.85

4.00

970

The bolts/nuts above are important for product safety purposes. Please tighten screw, bolts and nuts

according to the torque values given in table above.

Autres manuels pour D4 Series

Table des matières

Autres manuels SOGEDIS Rondelle

SOGEDIS

SOGEDIS T0 Series Manuel utilisateur

SOGEDIS

SOGEDIS D4 Series Manuel utilisateur

SOGEDIS

SOGEDIS BANDEAU HP F2 Manuel utilisateur

Manuels Rondelle populaires d'autres marques

Tricity Bendix

Tricity Bendix AW 1000 W Guide produit

Panasonic

Panasonic NA-F60L5WRB Manuel utilisateur

GE WSLP1500 Manuel

Electrolux

Electrolux EWF1284EDW Manuel utilisateur

Bosch

Bosch WAN2829BSN Manuel utilisateur

LG TV2516DV3B Manuel utilisateur

LG TH2517DSAV Manuel utilisateur

VESTEL

VESTEL CMH-XL 7510 TE Manuel utilisateur

AEG

AEG 74335 Manuel d'utilisation

Johnson

Johnson JWF721A Manuel utilisateur

Beko

Beko WTE7604XLW0 Manuel utilisateur

Danby

Danby DTT100A1WDB Instructions de montage

Amica

Amica WA 14 Ex Manuel utilisateur

Daewoo

Daewoo DWD-F1222 Manuel utilisateur

Bosch

Bosch WAS28461AU Manuel utilisateur

Miele

Miele PW 6080 Vario Manuel utilisateur

Finlux

Finlux FLX108CF220 Manuel utilisateur

Whirlpool

Whirlpool 3LBR5132AN0 Manuel utilisateur
