Model SWH-4100
and 4200 Contactless Multi-
Technology 125 KHz and 13.56
MHz Reader Installation Guide
Version H0
Part Number UM-090
May 2012
2
DRAFT
Tyco CONFIDENTIAL
CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installation Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Configuration Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Model SWH-4100 and SWH-4200 Technical Specifications . . . . . . . . . 16
FCC Digital Device Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
UL Standards Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
CE Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3
DRAFT
Tyco CONFIDENTIAL
INTRODUCTION
The SWH-4100 and SWH-4200 Contactless readers read Prox and Smart
Cards at frequencies of both 125 kHz and 13.56 MHz. The reading
capability includes, for Smart Cards, both unencrypted serial numbers and
encrypted MIFARE® programmed sectors. Refer to Table 1 and Table 2
for a complete list of compatible standards and data.
The SWH-4200 reader has a built-in keypad with 12 keys, including CMD/
ENTER and CE (Clear Entry). The reader outputs the PIN code in the 8-bit
burst Wiegand. It also has the ability to read and verify the PIN on a Smart
Card. This feature is enabled with the use of program cards. Please contact
Software House® for more information on the PIN-on-Card function.
4
DRAFT
Tyco CONFIDENTIAL
MODEL SWH-4100 & 4200 PROXIMITY
(125 KHZ) FORMATS SUPPORTED
TABLE 1. Proximity (125 KHz) Formats Supported
Proximity (125 KHz) Formats
Supported As Shipped: Default
Mode (On)
HID® 26 Bit Yes
HID® Corporate 1000 Yes
HID® 36 Bit Wiegand Yes
HID® 37 Bit Wiegand Yes
Other HID® Pass-through Formats Yes
Deister Prox SmartFrame® Yes
(GE) Casi Rusco ProxLite Yes
Kantech ioProx No
5
DRAFT
Tyco CONFIDENTIAL
MODEL SWH-4100 & 4200 SMART CARD
(13.56 MHZ) FORMATS SUPPORTED
TABLE 2. Smart Card (13.56 MHz) Formats Supported
Smart Card (13.56 MHz) Formats
Supported Enabled by Default?
MiFARE® Sector No
MiFARE® Serial number, 32 Bit Yes
MiFARE® Serial number, 56 Bit Yes
MiFARE® Plus Serial number, 56 Bit Yes
MiFARE® DesFire Serial number,
56 Bit No
MiFARE® DesFire® EV1 Serial
number, 56 Bit No
iCLASS® ISO 15693 Serial number,
64 Bit Yes
* PIV, TWIC, CAC, FASC-N Read Yes* (200-bit output)
* PIV-I, 128 Bit, GUID Yes* (if 200-bit output is
enabled)
* PIV-C, 128 Bit, GUID Yes* (if 200-bit output is
enabled)
* Refers to cards issued under the U.S. Government Smart Card
Initiative, HSPD-12.
6
DRAFT
Tyco CONFIDENTIAL
FEATURES
Universal compatibility with most 125 kHz Prox (including all HID®
Prox formats), all ISO 15693, and ISO 14443A credentials (badges, disk
tags and key fobs). Reads both 125 kHz and 13.56 MHz credentials in
the same reader.
Reads U.S. Government PIV, TWIC, and CAC cards simultaneously
with PIV-I (PIV Interoperable) and PIV cards.
Electrical protection (reverse polarity diode protection on power lines).
Data lines: high-speed transient voltage suppressor diodes.
IP65-rated sealed electronics for deployment in both interior and
exterior environments.
Integrated reader tamper protection.
PIV-I Support - The reader supports reading of a PIV-I (PIV-
Interoperable) card. With a PIV-I card, the Agency code, System code
and Credential number are all set to 9s. The reader senses this and
outputs the full UUID (Universally Unique Identifier), which is a 128-
bit long number. The firmware only supports PIV-I when the 200-bit
FASC-N output is selected.
PIV-C Support - The reader supports reading of a PIV-C (PIV-
Credentials) card.
CAC 5.5 Support - The firmware supports reading the new CAC card
from Oberthur, v5.5 and outputs the FASC-N according to the firmware
FASC-N setting.
MIFARE 7-byte CSN Support - The reader firmware will be able to
distinguish between a legacy MIFARE Classic card and a “next-
generation” MIFARE classic card. The next generation MIFARE cards
have a unique 7-byte serial number, not 4-byte. When presented to a
reader, the next-gen card causes the reader to output a 56-bit CSN.
Older cards still output a 32-bit CSN.
7
DRAFT
Tyco CONFIDENTIAL
MOUNTING
Mount the single-gang backplate (with tamper magnet installed) onto the
wall.
FIGURE 1. Model SWH-4x00 Reader Backplate
(includes tamper switch magnet)
NOTE
Mounting holes fit standard U.S. single-width electrical box and
standard European (EMEA) electrical box hole patterns.
Mount the reader module directly to the backplate and then snap the front
cover in place as indicated in Figure 2.
8
DRAFT
Tyco CONFIDENTIAL
FIGURE 2. Mounting Assembly
(including 1 optional isolation spacer)
Please note that Figure 2 shows the SWH-4100 reader and cover plate.
Although the SWH-4200 keypad reader and front cover plate differ, the
mounting assembly is the same as the SWH-4100.
9
DRAFT
Tyco CONFIDENTIAL
INSTALLATION CONSIDERATIONS
An isolation spacer available from Software House may be used to
improve the read range when mounting the reader to a metal surface.
Part number: SWH-SPACER-BLK or SWH-SPACER-LGR
To optimize reader range use the number of back plates as indicated in
Table 3. Use of Isolation Spacers is optional and not required for non-metal
mounting surfaces
Installation of two SWH-4100 and SWH-4200
readers side-by-side and back-to-back
Read range is not affected if the center-to-center distance between two
readers is greater than or equal to four (4) inches (101.6 mm). Two readers
can simultaneously read the same badge or tag if the distance between the
two readers is less than 4 inches, center-to-center. If the distance between
the two readers is less than four inches, field interference between the two
readers may result in a double-badge read.
TABLE 3. Isolation spacer recommended for mounting SWH-4100
and 4200 reader on metal
Distance Reading Distance
No metal plate 100%
4.5 cm 100%
2.7 cm (3 tamper plates) 85%
1.8 cm (2 tamper plates) 70%
0.9 cm (1 tamper plate) 50%
0 cm 10%
10
DRAFT
Tyco CONFIDENTIAL
NOTE
If two readers are being placed back-to-back on a wall less
than 4 inches thick, maximum performance can be achieved
by using a metal separation plate and then using isolation
spacers as necessary.
WIRING
SWH-4100 and 4200 models have twelve terminals as noted in Table 4.
The terminal strip is removable for easy installation and wiring. When
attaching wires to the connector, strip off only the minimum insulation
required (approx. 1/8'') and push the wire into the connector until the
insulation is flush or inside the connector body. This is particularly critical
for outdoor readers. While the reader itself is designed and protected to
IP65 standards, the cable wires can potentially corrode and short together if
not carefully mounted and tightly fastened in the connector body.
TABLE 4. Connector Pins for Model SWH-4100 and 4200
Pin Description Pin
1 External Beeper Control 7 External Green LED Control
2 Ground 8 External Red LED Control
3 Power (9.4 to 16 VDC) 9 A - RS485 - used for Flash upgrade
4 D1 Wiegand 10 B - RS485 - used for Flash upgrade
5 D0 Wiegand 11 Tamper (Normally Closed)
6 Reserved for Future Use 12 Tamper (Normally Closed)
