Sofar SPOTTER Manuel utilisateur

User Guide

SPOTTER

User Guide

SPOTTER

SPO

W E

What’s Included

Sofar Spotter

Core Features

User Interface

Spotter Measurements

Product Speciﬁcations

Safety & Compliance

Getting Started

Scan the QR code to access

online Support page

SPOTTER

What is included in this box?

01 Spotter device

5mm hex key to open and close the lid of

the Spotter

Lanyard and magnet to switch from IDLE

to RUN mode

USB-C power charger to charge the

battery prior to deployment

SD card for data storage during

deployment (shipped with unit)

Marine-safe desiccant to reduce

moisture inside the Spotter

Spotter toolkit, including:

Bow shackle for attaching a mooring line

User Guide

Spotter is an integrated solution for collecting ocean data. The Spotter

platform consists of a globally-connected Spotter Device (“Spotter”), the

online Spotter Dashboard, and the Spotter Data API.

The Dashboard allows you to congure your Spotter remotely and provides

access to real-time Spotter ocean and tracking data, system status and

alerts, and data visualization.

Sofar Spotter

CORE SYSTEM FEATURES

2-Way Communication Remotely change settings on Spotter through

the online Dashboard.

Alerts + Notiﬁcations Set watch perimeter and receive alerts when

Spotter moves outside of it.

Spotter API Access Spotter via our API for seamless

application integration.

Track Mode Fast positional updates for tracking Spotter

through the Dashboard.

SPOTTER

MARINE GRADE MATERIALS

The Spotter device is a compact and lightweight instrument consisting of

a waterproof hull, solar panel array, and electronics package.

The Spotter is completely solar-powered so you don’t have to replace or

recharge the battery during deployment. The solar-battery power system is

designed to support Spotter at higher latitudes in limited light conditions.

Core Features

VISIBILITY LIGHT

Flashes amber for nighttime

visibility

TRANSPARENT LID

LEDs provide clear visual

indication of system status,

and can be removed

to access electronics

enclosure and SD card

CAPTIVE LID SCREWS

5mm hex - will not get lost

when lid is removed

HARDWARE INTERFACE

Integrated bottom

attachment point

SURFACE

Use a magnet to switch

modes without opening

the unit and risking water

intrusion

For mooring applications see p. 16

User Guide

User Interface

GO LED

Displays status of GPS

connectivity and solar

charging system

SIGNAL LED

Indicates whether

a cellular network is

present

USB-C

Charger and data

transfer

ON/OFF

switch

SD CARD

Cover provides

retention

and splash

protection

SPOTTER ID #

MAGNET

Hold here for 3

seconds to switch

between IDLE and

RUN modes

QR CODE

Scan for quick access

to Spotter Dashboard

SYSTEM LED

Communicates system

health status

VISIBILITY LIGHT

SPOT-3333

SPOTTER

Getting Started

STEP 01 Set up your account and Spotter

STEP 02 Set up Spotter device

STEP 03 Deploy Spotter in the water

STEP 04 Check your Spotter Dashboard

STEP 05 Retrieve and store Spotter

p. 11

p. 12

p. 16

p. 17

p. 18
