SoClean 3 Manuel utilisateur

Automated Supplemental Sleep

Equipment Maintenance System

USER MANUAL

SC1400

SoClean 3 must be

activated to operate.

Read this manual,

complete the setup

checklist included and

follow the instructions

to activate.

CONTAINS ONE SOCLEAN ADAPTER

PLUS, 2 - Hose Sleeves [For use with 12 mm hose]

Adapter

Included

THANK YOU FOR

CHOOSING SOCLEAN!

We hope you enjoy making SoClean 3

part of your daily maintenance routine.

TABLE OF

CONTENTS

Overview 4

Warnings and Precautions 6

Learn About Ozone 9

Your SoClean 3: Parts, Buttons & Indicator Lights 11

Setting Up Your SoClean 3 19

Powering Your SoClean 20

Installing the Filter 22

Wash, Rinse and Dry Your

Sleep Equipment Hose and Mask 24

Connecting the Adapter 26

Setup Checklist & Device Activation 28

Using Your SoClean 3 29

Operating a Maintenance Cycle 29

Using the Hose Sleeve 32

Setting a Delay for Your Maintenance Cycle 34

Fresh Air Cycle 36

Canceling a Cycle 37

Reconnecting Your Sleep Equipment 38

Maintenance 40

General Troubleshooting 42

Warranty Information 50

SoClean.com [email protected]| 866-501-3705 |

OVERVIEW

Indications for Use, Contraindications, and Speciﬁcations

CONTRAINDICATIONS FOR USE

Persons with underlying lung diseases, such as asthma and chronic obstructive pulmonary disease (also

known as COPD, which includes emphysema and chronic bronchitis), and those with cardiovascular

disease may be sensitive to ozone and should consult with their health care professional before using

this product.

CAUTION: Safety in pregnant or breastfeeding women and children under the age of 22 have not

been established. Consult with your health care professional before using this product.

Read this instruction manual before operating this device.

The SoClean 3 device should be used only according to the procedures described in this manual. If it

is used in a manner not speciﬁed by SoClean®

, the safety protection provided by the equipment may

be impaired.

INDICATIONS FOR USE

The SoClean 3 device is intended to be used to supplement maintenance procedures for home use

sleep equipment masks and hoses.

Ozone Cycle

75 minutes

Ozone Concentration

440 ppm maximum from ozone generator

Electromagnetic Compatibility

The SoClean 3 complies with all applicable

electromagnetic compatibility requirements (EMC)

according to IEC 60601-1-2:2014, for residential,

commercial, and light industry environments. If

electrical interference is suspected during operation,

contact SoClean Customer Care.

Sleep Equipment Hose

Dimensions Compatibility

For use with hose outside diameter dimensions

between 0.715 and 0.935 inches (18.15 and

23.75 mm) and lengths up to 6 feet 6 inches

(3.07 meters).

A 12 mm hose diameter will require a SoClean

Hose sleeve.

USB Port

This port is provided only for USB charging.

Maximum USB charging cord length: 10 ft. (3 m).

Model Number

SC1400

Operating Environmental Conditions

Indoor use only.

Temperature:50°F to 100°F (10°C to 38°C)

Relative Humidity: 15% to 75%

Altitude: sea level to 8,500’ (2,591 m);

Air Pressure Range 101.3 kPa to 73.8 kPa

Physical Characteristics

Dimensions: 9.49” x 7.12” x 7.36”

(241 x 181 x 187 mm)

Weight: 3.65 lbs. (1.65 kg)

Cord Length: 4’ 11” (1.5 m)

Electrical Characteristics

AC Adapter Input: AC 100~240V, 50/60HZ, 0.5A

AC Adapter Output: DC 12V, 1.5A Max

Power Consumption: 18W Max

USB Charging Port Output: DC 5V, 0.5 A Max

Storage and Transport Conditions

Temperature: -4°F to 131°F (-20°C to +55°C)

Humidity: 15% to 95% non-condensing humidity

Pressure: 106kPa to 70kPa

[Sea level to 10,000’ (3048m)]

SPECIFICATIONS

FCC Notice Part 15:

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a class B digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in

a particular installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult SoClean Customer Care for help.

FCC CAUTION: Changes or modiﬁcations not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

CAUTION: This equipment complies with FCC/IC RSS-102 radiation exposure limits set forth for an

uncontrolled environment. To maintain compliance with the FCC and IC RF exposure guidelines, place

the unit at least 20 cm away from nearby persons.

OZONE LEAKAGE

The SoClean 3 meets 21 C.F.R. § 801.415 for the maximum allowable ozone accumulation of not more than

0.05 parts per million when operated in a room larger than 70 square feet with 8-foot or higher ceilings.

OVERVIEW

DISPOSAL INFORMATION: Safe disposal of the device: Follow the local, state, and national governing

ordinances and recycling instructions regarding disposal or recycling of the device and device components

at the end of the expected service life.

No Liquid

in SoClean

Chamber

Do Not Use

If Package Is

Damaged

Storage and

Transport

Conditions

Consult

Manual

Waste Electrical and Electronic Equipment

(WEEE). It is the responsibility of the end user

to dispose of this equipment at a designated

collection point.

Date of

Manufacture

General

Caution/

Warning

Not Made With

Natural Rubber

Latex

Serial

Number

Federal

Communications

Commission

PACKAGING SYMBOLS

4 5

CAUTION: Do not place any flammable or ignitable items on top of the SoClean 3

device. Do not use in explosive air environments, near gas vapors, or other

flammables, etc.

CAUTION: Discontinue use of your SoClean 3, consult your health care professional,

and contact SoClean Customer Care if acne or a rash develops along the mask

contact line.

CAUTION: Ensure all tubing and hoses are free of kinks prior to operating the

SoClean 3.

CAUTION: Rest the ﬂexible part of the sleep equipment hose, not the rigid mask

connector, in the Hose Slot to ensure a proper seal.

CAUTION: Inspect the SoClean 3 Lid and Hose Gaskets for visible damage before

operating a Maintenance Cycle.

CAUTION: Do not share a SoClean 3 between sleep equipment users. Your

SoClean 3 is to be used by one user.

CAUTION: In the event of loss of power, rerun the entire Maintenance Cycle to make sure

the sleep equipment hose and mask have been maintained properly.

CAUTION: Wash your sleep equipment mask and hose according to the sleep

equipment manufacturer’s recommended method and interval. Use the SoClean 3

for daily supplemental maintenance of your sleep equipment mask and hose.

CAUTION: Do not use incompatible materials in the SoClean 3 such as memory foam,

natural rubber, or nylon. Headgear often contains incompatible materials for your

SoClean 3. Remove headgear before placing mask in the Maintenance Chamber.

CAUTION: Ensure there are no obstructions to the ﬁlter exhaust. Keep the area behind

the SoClean 3 clear of clutter and soft objects.

WARNING: Discontinue use and call your health care professional in the event that

you experience any respiratory or cardiac symptoms.

WARNING: Keep away from children.

WARNING: When operating your SoClean 3 per the instructions for use, if there is a

noticeable scent of ozone or other unfamiliar odor or you experience headache,

cough, or shortness of breath, leave the room for 4 hours. Contact SoClean Customer

Care before running your machine again.

WARNING: The Ozone Tube must always be connected to the SoClean Adapter and the

back of the SoClean 3 unit when operating the SoClean.

WARNING: Do not inhale from the Ozone Tube or the Ozone Outlet on the back of

the device. Do not breathe through the mask if the SoClean 3 is operating a

Maintenance Cycle.

WARNING: Do not forcibly open the SoClean 3 Lid before the Cycle completes.

WARNING: Do not submerge the SoClean 3 device in water or use chemical cleaners

on or in your SoClean 3. Keep away from water sources, including rain, bathtubs,

sinks, and pools. To clean, wipe inside and outside with a damp cloth.

WARNING: Do not put liquids into the SoClean Chamber.

WARNING: Do not disassemble or modify your SoClean device or accessories.

WARNING: If the SoClean system is dropped, it may become damaged. Regularly

inspect the SoClean 3 for physical damage, such as cracks or broken structure,

damaged gaskets, and cracks in the Ozone Tube or sleep equipment hose. Discontinue

use if damage is detected and contact SoClean for assistance.

WARNING: To reduce the chance of tripping, place your sleep equipment and SoClean

along with all cords, tubes and hoses out of the way of any area you may walk.

Warnings

and Precautions

6 7

SoClean 3 uses ozone. Ozone is contained within the system and is in contact

with your sleep equipment hose and mask during the Maintenance Cycle.

SoClean 3 is designed to produce a sucient level of ozone for maintenance

of your sleep equipment hose and mask. The smell of ozone is detectable at

low concentrations by some people and you may smell ozone brieﬂy during

the Maintenance Cycle.

Ozone naturally breaks down into oxygen in a short amount of time. Your

SoClean 3 safely contains ozone within the system until it has converted back

to oxygen. The Filter accelerates the process of converting ozone in your

SoClean 3 Chamber and your sleep equipment hose and mask into fresh air

before the completion of a Maintenance Cycle.

WARNING: When operating your SoClean 3 per the instructions for use, if

there is a noticeable scent of ozone or other unfamiliar odor or you experience

headache, cough, or shortness of breath, leave the room for 4 hours. Contact

SoClean Customer Care before running your machine again.

WARNING: If you are experiencing headaches/migraines, or symptoms such

as cough or discomfort in your nose or throat discontinue use and call your

health care provider.

WARNING: Discontinue use and call your health care provider if you

experience any cardiopulmonary symptoms.

WARNING: If the SoClean system is dropped, it may become damaged.

Regularly inspect the SoClean 3 for physical damage, such as cracks or

broken structure, damaged gaskets, and cracks in the Ozone Tube or sleep

equipment hose. Discontinue use if damage is detected and contact SoClean

for assistance.

CAUTION: Discontinue use of your SoClean 3, consult your health care

provider and contact SoClean Customer Care if acne or a rash develops along

the mask contact line.

Sleep equipment masks and hoses are made from a variety of materials.

SoClean has tested sleep equipment masks and hoses for material

compatibility with the ozone maintenance process.

While most sleep equipment masks and hoses are made of compatible

materials, the following materials should not be used with the SoClean 3:

memory foam, natural rubber, or nylon.

Sleep equipment mask and hose materials may discolor naturally over

time and with use, which is why the sleep equipment manufacturers

recommend replacing these components at regular intervals. The

SoClean 3 is safe to use with sleep equipment masks and hoses even if

you notice some discoloration.

CAUTION: Do not use incompatible materials in the SoClean 3 such

as memory foam, natural rubber, or nylon. Headgear often contains

incompatible materials for your SoClean 3. Remove headgear before

placing mask in the Maintenance Chamber.

MATERIAL COMPATIBILITY

How does my SoClean 3 Work?

Learn About Ozone

SLEEP EQUIPMENT HOSE COMPATIBILITY

For use with hose diameters of 15 mm and 19 mm and length up to 6’ 6”.

A 12 mm hose diameter will require a SoClean Hose sleeve [included].

Hose

Sleeve

Compatible

Masks and Hoses

8 9

HOSE SLOT

Your sleep equipment

hose rests here during

the Maintenance Cycle.

LID

Opens for access

to the Chamber.

CONTROL PANEL

Houses all the buttons

and icons for operating

your SoClean 3.

Your SoClean 3: Parts,

Buttons & Indicator Lights

WHAT’S INCLUDED

OZONE TUBE

SOCLEAN 3 DEVICE

FILTER

POWER SUPPLY

SOCLEAN ADAPTER

Compatible with most sleep

equipment hoses.

FILTER

The Filter converts ozone in your SoClean 3

and sleep equipment mask and hose into fresh

air as it exhausts from the unit. This component

must be replaced at least every 6 months. Your

SoClean 3 reminds you when it needs

replacement.

OZONE TUBE

One end of the Ozone Tube connects to your SoClean

Adapter, and the other end comes already attached to the

back of the SoClean 3. This tube is what circulates ozone or

air through your sleep equipment mask and hose during the

Maintenance Cycle and Fresh Air Cycle.

POWER INPUT

The cable from

the Power Supply

provided with your

SoClean 3 plugs

in here.

PHONE

CHARGING

PORT

A USB port is

provided on the back

of your SoClean 3 to

conveniently charge

your cell phone when

your SoClean 3 is

connected to power.

FILTER DOOR

Your Filter goes in here.

The SoClean 3 unit will

not operate a Maintenance

Cycle or Fresh Air Cycle

if the Filter Door is open.

YO U R S O C L E A N 3 : PA R T S & I C O N S

LID LATCH

Keeps the Lid of the SoClean 3 closed

securely during the Maintenance Cycle

and Fresh Air Cycle.

LID GASKET

Seals the Lid in order

to contain ozone

within the Chamber.

HOSE DETECT

SENSOR

Your SoClean 3 will

only operate when

properly conﬁgured.

A Maintenance Cycle

or a Fresh Air Cycle

will not begin unless

a sleep equipment

hose is detected and

the Lid is closed.

MAINTENANCE

CHAMBER

Place your mask,

while still connected

to the hose, inside

the Chamber before

running a Maintenance

Cycle. The inside of the

Chamber is illuminated

for visibility in low-light

settings.

NOTE:

SoClean 3 Lid can only

be opened when the

device is plugged in.

12 13

YO U R S O C L E A N 3 : PA R T S , B U T TO N S & I C O N S

YO U R S O C L E A N 3 : PA R T S B U T TO N S & I C O N S

CONTROL PANEL

Get to know the buttons used to control the device operation and the icons

that will tell you what is happening.

A B C

MAINTENANCE CYCLE

Starts the maintenance process with a single push of the button.

Your mask and hose must be present in the SoClean 3 with the

Lid closed to operate the Maintenance Cycle.

FRESH AIR CYCLE

Runs air through the system to freshen your sleep equipment mask

and hose with the push of a button.

NOTE: The Fresh Air Cycle does not maintain your sleep equipment

mask and hose.

Your mask and hose must be present in the SoClean 3 with the

Lid closed to operate the Fresh Air Cycle.

BUTTONS

There are 4 buttons on the Control Panel that are used to operate your

SoClean 3. Buttons illuminate blue when any one button is pressed to help

with visibility in low-light conditions.

CYCLE DELAY

Used to set a 2, 4, or 8 hour delay to the start of your Maintenance Cycle.

NOTE: The system automatically returns to the default setting of

No Delay after each use.

LID OPEN

Opens the Lid when the device is connected to power. This button

can also be used to cancel an active Maintenance Cycle by pressing

and holding for 5 seconds.

NOTE: If canceling a Cycle, Lid cannot be opened until Cycle

Complete Icon illuminates.

There is no power button on your SoClean 3. The device is connected

to power and “on” when the Power Supply is plugged into your

SoClean 3 and the electrical outlet.

14 15

YO U R S O C L E A N 3 : PA R T S & I C O N S

INDICATOR LIGHTS

There are 7 illuminated indicator lights on the Control Panel that the SoClean

3 uses to communicate with you. The icons are o if the device is idle and

operating normally. See the notes to follow about why these icons may

illuminate and when you can expect to see them.

ab c d e

Solid Green

Indicates that either a Maintenance Cycle or Fresh Air Cycle is

complete and that the Lid can be opened.

aCYCLE COMPLETE

Solid Red/Flashing Red

Indicates when your SoClean 3 has detected an internal issue.

See troubleshooting guide.

bFAULT/UNABLE TO RUN

Flashing Amber

Indicates that it is time to order a new Filter. From the time it

begins to ﬂash amber, you have 30 days or 30 uses (whichever

comes ﬁrst) to replace the Filter. You can still use your SoClean 3

to maintain your sleep equipment hose and mask during this time.

Solid Amber

See troubleshooting guide.

cFILTER ISSUE

FILTER DOOR ISSUE

Solid Amber

Indicates that the Filter Door is not completely closed.

Check your Filter Door and open/close it securely.

HOSE NOT DETECTED

Solid Amber

Indicates that your sleep equipment hose is not present or

detected when the Lid is closed.

Flashing Amber

Indicates an error detecting the hose or in process of detecting a

hose. This may be the ﬁrst time the SoClean 3 has been powered

on or there has been loss of power to the device. Open and

close Lid with mask and hose installed to continue.

NOTE: Your SoClean 3 will not operate a Maintenance Cycle

or Fresh Air Cycle if your mask and hose are not installed or

detected in the unit with the Lid closed.

16 17

CYCLE PROGRESS BAR

Progressive Blue

Gradually turns blue from left to right as an indication of

progress for a Maintenance Cycle or Fresh Air Cycle.

Flashing Blue

A Cycle cancellation is in progress.

Solid Red

Indicates that an active Maintenance Cycle has been

interrupted (example: temporary loss of power).

NOTE: During this time, your SoClean 3 is pumping air

through the system to remove ozone.

2, 4, 8 HOUR CYCLE DELAY INDICATOR LIGHTS

Flashing Blue

Indicates that the Cycle Delay can be changed by pressing

the Cycle Delay button .

NOTE: Your mask and hose must be installed with the Lid closed

to modify and activate the Cycle Delay.

Solid Blue

Indicates if a Cycle Delay has been programmed.

Three indicator lights are provided.

One light illuminated = 2 hr delay selected

Two lights illuminated = 4 hr delay selected

Three lights illuminated = 8 hr delay selected

No lights illuminated = no cycle start delay selected (default)

YO U R S O C L E A N 3 : PA R T S & I C O N S

Setting Up

Your SoClean 3

18 19

Autres manuels pour 3

Table des matières

Autres manuels SoClean Produit de soins personnels

SoClean

SoClean 3 Manuel utilisateur

Manuels Produit de soins personnels populaires d'autres marques

Pretika

Pretika ST102 Mode d’emploi

Beurer

Beurer FC 76 Manuel utilisateur

Pebble Grey

Pebble Grey 500.40.70-75 Manuel utilisateur

PUSH

PUSH ortho Manuel utilisateur

Dermlite

Dermlite DL3N Manuel utilisateur

DERMAPEN

DERMAPEN SEMI Manuel utilisateur

HiB

HiB Spectre 50 Manuel utilisateur

Carex

Carex SunLite Manuel utilisateur

Roper Rhodes

Roper Rhodes Intense Manuel de la liste des pièces

Interacoustics

Interacoustics Titan IMP440 Instructions d'utilisation et de sécurité

ReTrak

ReTrak VS001 Manuel utilisateur

LED Technologies

LED Technologies dpl PAIN RELIEF Joint Wrap Manuel utilisateur

Casa Lusso

Casa Lusso MVL1000x450PR Manuel utilisateur

Quoizel

Quoizel QR3326 Instructions de montage

Beurer

Beurer EM 37 Manuel utilisateur

BERTSCHAT

BERTSCHAT HEATED HOODIE PRO - DUAL HEATING Manuel utilisateur

ACP

ACP OMNISTAND Manuel utilisateur

Scarlett

Scarlett VitaSpa SC-CA304PS11 Manuel utilisateur
