AMC 730

IN-WALL VERSION OF OUR ACCLAIMED K7

PERFECT FOR MUSIC, AND 5.1 HOME THEATER

The AMC730 is Snell’s K7 monitor, re-engineered for ﬂush-mount use. As you

would expect, many of the features developed by Snell over the past 30 years,

are in full use. To achieve the performance capabilities of a freestanding

monitor, this new design overcomes the three factors limiting all in-wall

speakers. First, to insure predictable response, regardless of placement or wall

type, the AMC730 has been designed with an integrated and sealed,

aluminum enclosure, which, like all conventional loudspeakers, determines

the speaker’s bass response. Second, superior materials are used in the

AMC730 to control resonance. Where other in-walls are open-backed and

made of plastic, we mount our K7 drivers to a specially damped MDF bafﬂe,

constructed in three layers to enhance bass/midrange clarity and deaden wall

resonance. The bafﬂe secures to a well damped, heavy gauge aluminum

enclosure. Third, most ﬂush mount speakers can not reproduce a proper

soundstage. To assure the spacial realism found only in high-performance

monitors, the AMC730’s low-resonance, silk dome tweeter has incredible

dispersion, well into the voice range. For enhanced performance a new cross-

over was designed to “tune” the AMC730 to its in-wall boundary, and uniquely

extend bass in a small volume cabinet. The precision crossover is hand tuned to

guarantee performance to within a remarkable 0.5dB of the Reference Master.

AMC Series

AMC 730

Design Infinite Baffle, Back-Boxed, In-Wall Monitor

Frequency Response

78Hz-20kHz+3dB

Sensitivity 87dB

Nominal Impedance 8 Ohms

Crossover Frequency 2.5kHz

Recommended Amplifier Power 50-125 Watts

Maximum Output (per pair) 105dB

Placement 2" x 4" Stud Wall or Ceiling

Drive Units Tweeter: 1-inch SEAS Silk Dome

Woofer: 5.25-inch Poly, 5mm Excursion

Input Connection Spring Loaded, Push Post, Accepts 12 Gauge Wire

Dimensions Finish: Height: 14-inches

Width: 9.5-inches

Depth: 3.75-inches

Rough Opening: Height: 12.82-inches

Width: 8.32-inches

Mounting System 4 "dog-Leg" clamps

Finishes Cabinet: White

Grille: White, Perforated Metal 53% Open

Manufactured by Snell Acoustics, PO 3717, Peabody MA 01960

www.snellacoustics.com 978-538-6262 978-538-6266fax
