Parts Manual fo
r
Revision 1,
20" STEEL DECK LIGHT WEIGH
T
SERIES 0
COPYRIGHT
©
2005
McDonough, GA, 30253 U.S.A.
TP 400-5103-1-WB-N
9/22/2005 Manual No. 7006040
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
(
Standard & OPP
)
WALK BEHIND MOWERS
MODEL
D20380
EDLW400R
2
ELW400
R20400
Table Of Content
s
TP 400-5103-1-WB-N
Manual No. 700604020" STEEL DECK LIGHT WEIGHT
SERIES 0 3
PAGE GROUP
4Handles & Controls
6Cutting Deck, Blade, Interlock
8Cutting Deck, Blade, Interlock (OPP Models Only)
10 Wheels, Guards, Axles
12 Wheels, Guards, Axles (OPP Models Only)
14 Decals
16 Accessory - Grass Bag
18 Accessory - Side Chute, Adapter
20 Accessory - Snapperizer
22 Accessory - Recycling Kits
Handles & Controls
TP 400-5103-1-WB-N
Manual No. 7006040 20" STEEL DECK LIGHT WEIGHT
SERIES 0
4
Handles & Controls
Footnotes:
TP 400-5103-1-WB-N
Manual No. 700604020" STEEL DECK LIGHT WEIGHT
SERIES 0 5
Part No Descri
p
tionItem Qt
y
Note
1 7074384 1 HANDLE, Upper Was 33473
7033477 1 HANDLE, Upper Was 33474 (For OPP Models
Only)
2 7036350 1 HANDLE, Middle
7033406 1 HANDLE, Middle (For OPP Models Only)
3 7046502 1 HANDLE, Lower Left Hand Was 38467
4 7035342 1 HANDLE, Lower Right Hand Was 38466
5 7017072 1 CONTROL, Blade
6 7033904 1 CLIP, Blade Control Was 32829
7 7023765 1 CABLE, Blade Control (Briggs & Robin 4-Cycle)
7027475 1 CABLE, Blade Control (Robin 2-Cycle) Was 24146
8 7014343 1 BUSHING
9 7023813 1 CLIP, Wiring Harness
10 7019254 1 CONTROL, Throttle (Briggs & Robin 4-Cycle)
7024140 1 CONTROL, Throttle (Robin 2-Cycle)
11 7090095 1 NUT, 1/4-28 Hex Was 91024
12 7016544 2 PLUG (For OPP Models Only)
13 7023735 4 KNOB, 5/16-18
14 7091740 4 SCREW, 5/16-18 x 2" Curved Head Was 91189
15 7024088 1 DECAL, Blade Control
15A 7023745 1 DECAL, Blade Control (Used On Models Without Foam
Grip Handles)
15B 7024211 1 DECAL, Blade Control
16 7090898 1 SCREW, #10-32 x 5/16" Sems
17 7090799 4 BOLT, 5/16-18 x 5/8" Short Neck Carriage Was 91026
18 7091601 4 NUT, 5/16-18 Hex Flange Lock Was 91070
19 7090112 1 SCREW, 1/4-28 x 2" Hex Head Cap Was 90963
20 7090053 1 WASHER, 1/4 Internal Tooth Lock Was 91023
21 7090391 1 WASHER, 5/16 Internal Tooth Lock Was 91068
22 7049753 1 FENDER, Weldment Structure (For European Models)
Cutting Deck, Blade, Interlock
TP 400-5103-1-WB-N
Manual No. 7006040 20" STEEL DECK LIGHT WEIGHT
SERIES 0
6
Cutting Deck, Blade, Interlock
Footnotes:
TP 400-5103-1-WB-N
Manual No. 700604020" STEEL DECK LIGHT WEIGHT
SERIES 0 7
Part No Descri
p
tionItem Qt
y
Note
1 7057662 1 DECK, Mower Was 47972 (Includes painted
deck with decals)
7057662 1 ASSEMBLY, Tall Mower Deck Was 53087 (Includes 1, 13A, 5
& 14)
2 7017031 1 BLADE, Cutter
7017167 1 BLADE, Cutter (For Recycling Models Only)
3 7090167 1 SCREW, 3/8-24 x 2" Hex Head Cap (Gr. 5)
4 7012063 2 WASHER, Cone
5 7013847 2 RETAINER, 3/8 Bolt
6 7015626 1 HUB, Drive Blade
7 7033408 1 SPRING, Interlock
7032137 1 SPRING, lnterlock
8 7012048 1 INSULATOR, Interlock
9 7090385 1 WASHER, #8 Tab
10 7090379 1 SCREW, #8-18 x 3/4" Self-Tapping
11 7090071 1 SCREW, 1/4-20 x 3/4" Hex Flange Lock
12 7091584 2 NUT, 1/4-20 Hex Flange Was 91065
13 7090324 3 SCREW, 3/8-16 x 1" Self-Tapping
13A 7091088 3 SCREW, 3/8-16 x 2" Self-Tapping
14 7041346 1 RING, Spacer Structure
15 7011762 1 COVER, Spark Plug (Not Shown)
7061151 1 AIRLIFT, Hardware Bag (Includes Airlifts); Not shown
Cutting Deck, Blade, Interlock (OPP Models Only)
TP 400-5103-1-WB-N
Manual No. 7006040 20" STEEL DECK LIGHT WEIGHT
SERIES 0
8
Cutting Deck, Blade, Interlock (OPP Models Only)
Footnotes:
TP 400-5103-1-WB-N
Manual No. 700604020" STEEL DECK LIGHT WEIGHT
SERIES 0 9
Part No Descri
p
tionItem Qt
y
Note
1 7057662 1 DECK, Mower Was 52502 (Includes painted
deck with decals)
2 7022396 1 BLADE, Cutter
3 7090167 1 SCREW, 3/8-24 x 2" Hex Head Cap (Gr. 5)
4 7012063 2 WASHER, Cone
5 7022390 1 HUB, Blade Drive (Tecumseh 2-Cycle)
6 7033408 1 SPRING, Interlock
7 7012048 1 INSULATOR, Interlock
8 7090385 1 WASHER, #8 Tab
9 7090379 1 SCREW, #8-18 x 3/4" Self-Tapping
10 7090071 2 SCREW, 1/4-20 x 1/2" Hex Head Cap Was 91145
11 7091584 2 NUT, 1/4-20 Hex Flange Was 91065
12 7090324 3 SCREW, 3/8-16 x 1" Self-Tapping
13 7011762 1 COVER, Spark Plug (Not Shown)
Wheels, Guards, Axles
TP 400-5103-1-WB-N
Manual No. 7006040 20" STEEL DECK LIGHT WEIGHT
SERIES 0
10
