Safety notes
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION:
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER(OR BACK).
The lightning flash with arrowhead symbol,with in an equilateral
triangle, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
Safe use only under elevaon 2000m.
12
Features
Use two sta516be digital power amplifier chips, output 230W per channel at 4
ohm,easy to drive most speakers.
Using NJRC's electronic volume control chip NJW1195 from Japan, precise volume
control and low distortion.
super bass preamp output for connecting active subwoofers to form a 2.1 audio
system,-30 ~ +10dB adjustment range.
Built-in multiple EQ modes and treble / bass adjustment for easy matching of a
variety of speakers and music.
Qualcomm Bluetooth 5.0 receiver, suport APTX, better sound quality, longer
transmission distance.
All aluminum alloy CNC precision processing shell, anodizing technology and
chamfering process, exquisite workmanship and delicate touch.
Using color LCD screen and newly developed user interface, full-function remote
control.
High quality gold-plated input and output terminals.
Perfect protection circuit for overheating, overcurrent, etc.
High quality power specially designed for audio.
13
14
Specification
Inputs ....................................................................................................................................................XLR , RCA , BT
THD+N .................................................................................................................................................................0.003%
SNR ...............................................................................................................................................................................96dB
Channel separation ...........................................................................................................................................94dB
Output Power ......................................................................................................230Wx2(4Ω) / 110Wx2(8Ω)
Power Consumption ..................................................................................................50W(Normal Volume)
Size ..................................................................................................................................210x235x48mm (WxHxD)
Weight
.......................................................................................................................................................................
.1.95kg
15
Remote Control
Install 2 x AAA batteries as instructions
When using the remote control, point it toward the remote con-trol signal receiver on the
main unit from a distance of 5 m (16 ft) or less. Do not place obstructions between the
main unit and the remote control.
The remote control might not work if the remote control signal receiver on the unit is
exposed to direct sunlight or bright light. If this occurs, try moving the unit.
Beware that use of this remote control could cause the unin-tentional operation of other
devices that can be controlled by infra.
Switch to control
SA400
Switch Function
Power ON/OFF
Mute
Menu
No function
No function
Volume up
Volume down
Input selection
Bluetooth
NOTE:
1. This remote controller use 2 x R03/AAA batteries;
2. When you first operate SA400,press the A key first.
Approximately 8m(26 ft)
30°
30°
16
Functions
Main unit front
21
3
1. Multi-function knob
2. Display
3. Remote window
Main unit back
4. Bluetooth antenna
5. XLR
8. Right speaker output
6. Line in
7. SW OUT
9. Left speaker output
10. Power input（100V-24V AC）
SW
OU T
A C I N 10 0 ~2 40 V
SP EA K ERS
SA4OO HI GH R ES OLUT ION POWE R AMPLIF IER
R L
9 10
8
7
4
56
5
17
18
Operation Instructions
Main Display
1. Input selection indication
2. Volume
3. Input status(Red when muted)
12 VOL
Balanced
1
2
3
There are 8 pages of settings
in this menu.
1. INPUT
2. EQ
3. BASS
4. MIDDLE
5. TREBLE
6. SUB WOOFER
7. BRIGHTNESS
8. VERSION
INPUTS
1. BALANCED
2. UNBA
LANCED
3. BLUETOOTH
EQ Setting
1. Direct
2. Tabebuia
3. Tone
4. SDB
5. Bass
6. Super Bass
7. Rock
8. Soft
9. Clear
SETTINGS
INPUT
EQ
BASS
MIDDLE
TREBLE
SUB WOOFER
BRIGHTNESS
VERSION
INPUTS
BALANCED
UNBALANCED
BLUETOOTH
EQ SETTING
Direct
Tabebuia
Tone
SDB
Bass
Super Bass
Rock
Soft
Clear
When the EQ mode is Direct or other EQ mode,
changing the MIDDLE will change the EQ to Tone
mode.
MIDDLE adjustment range：-12dB ~ +12dB
When the EQ mode is Direct or other EQ mode,
changing the Bass will change the EQ to Tone
mode.
Bass adjustment range：-12dB ~ +12dB
Brightness Level：1 ~ 6
VERSIONS
19
BASS
0dB
TREBLE
0dB
SUB SETTING
0dB
BRIGHTNESS
VERSIONS
HW ver：1.0
SW ver：1.0
（C）SMSL AUDIO 2020
MIDDLE
0dB
When the EQ mode is Direct or other EQ mode,
changing the Treble will change the EQ to Tone
mode.
Treble adjustment range：-12dB ~ +12dB
SW OUT adjustment range：-30dB ~ +7dB
Bluetooth operating instructionst
20
Connection:
Step 1: Switch the input source in the SETTING MENU or press the Bluetooth
button of the remote;
Step 2: Turn on the Bluetooth function of the mobile phone, search for
“SMSL BT5.0D", and tap to pairing. When the mobile phone displays
“connected", it has been successfully connected.
Re-connection:
When you had lost the connection with the SA400, for example,going out, and
back home, some phones will not re-connect the SA400 if the SA400 has not
been re-boot, so you can press the Bluetooth button (FN) on the remote to
Re-connect.
Clear pairing: Long press the“Bluetooth" button(FN)on the remote control. After clearing
the pairing, some phones may no longer be able to search for “SMSL BT5.0D". In
this case, you need to delete the Bluetooth device “SMSL BT5.0D" which saved in
the phone, and then search and pairing again.
This product is equipped with a Bluetooth
Short press: Switch directly to Bluetooth input, if Bluetooth loses connection, it is
a reconnect;
Long press: Disconnect the current device and allow pairing with other devices.
