Functional test and visual inspection
A functional test involves triggering the local smoke detector, observing the
deployment of the system, and retracting the curtain. Locate the service
record at the back of this manual and fill it out as you proceed. You are
responsible for reporting any required adjustments to Smoke Guard or the
distributor who installed the unit.
1. Locate the status LEDs on the outside of the control box and verify
that the system is in standby state by the presence of one
continuously-lit, green LED. (If all LEDs flash sequentially, the system
is running a normal system check.)
2. Activate the smoke detector or other initiating device connected to the
unit per manufacturer’s recommendations.
3. Observe curtain deployment to ensure smooth motion. If motion is
jerky, check the guides for obstruction.
4. While deployed, verify that there is one continuously-lit, green LED on
the control box indicating successful deployment.
5. Visually inspect the curtain assembly for damage to the curtain
material or bottom bar at the floor. If any damage is present,
immediately contact Smoke Guard or local distributor for repair
procedures.
6. Retract the curtain by clearing the smoke detector.
7. Observe curtain retraction to ensure smooth motion.
8. Again, verify that the system is in standby state by the presence of
one solid green LED. (If all LEDs flash sequentially, the system is
running a normal system check.)
If there is an optional door activation switch:
9. Activate the smoke detector a second time to deploy the system.
10. Press the door activation switch. The curtain should retract, pause,
and re-deploy.
11. If present, press the other door activation switch. The curtain should
retract, pause, and re-deploy.
12. Verify that the system is in standby state by the presence of one solid
green LED. (If all LEDs flash sequentially, the system is running a
normal system check.)
13. Retract the curtain by clearing the smoke detector.
