Smeg FD541MNED Manuel utilisateur

EN NO FROST REFRIGERATOR

Freezer - Fridge

User manual

FD541MNED

DE NO-FROST-KÜHLSCHRANK

Gefrierschrank - Kühlschrank

Bedienungsanleitung

FR RÉFRIGÉRATEUR SANS GIVRE

Congélateur - Réfrigérateur

Manuel d’utilisation

Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Smeg

FD541MNED o cerca il tuo prodotto tra le migliori offerte di Frigoriferi e Congelatori

Index

BEFORE USING YOUR FRIDGE.....................................3

General warnings...................................................................... 3

Old and out-of-order fridges...................................................... 5

Safety warnings ........................................................................ 6

Installing and operating your fridge........................................... 7

Before Using your Fridge.......................................................... 8

Information about NO FROST Technology ............................... 8

PARTS AND PIECES OF YOUR FRIDGE ....................... 9

Parts of the water dispenser.....................................................11

(A ) Outside the door (water dispenser's tank group) ...........11

(B) Inside the door (Water dispenser's tank group) ..............11

USAGE INFORMATION..................................................12

Display and control panel ........................................................ 12

Operating your fridge............................................................... 14

Super freeze mode .............................................................. 14

Super cool mode ................................................................ 14

Economy mode.................................................................... 15

Holiday mode....................................................................... 15

Drink cool mode................................................................... 16

Screen saver mode.............................................................. 17

Function of Child lock ......................................................... 17

Freezer temperature settings................................................... 18

Cooler temperature settings .................................................... 18

Warnings about temperature adjustments............................... 19

Accessories ............................................................................. 20

Icemaker .............................................................................. 20

Quick Freezer Compartment ............................................... 20

Chilled Room Compartment ................................................ 21

Water dispenser (If available) .................................................. 22

Mounting of the water tank group ....................................... 22

Cleaning the Water Tank...................................................... 23

CLEANING AND MAINTENANCE.................................. 25

Replacing the bulb................................................................... 26

PLACING THE FOODS................................................... 27

Where to place in the............................................................... 27

Freezer Compartment.............................................................. 28

SHIPMENT AND REPOSITIONING................................ 33

Repositioning the Door ............................................................ 33

BEFORE CALLING SERVICE........................................ 34

TIPS FOR SAVING ENERGY.......................................... 39

BEFORE USING YOUR FRIDGE

General warnings

WARNING: Keep vantilation openings, in the

appliance enclosure or in the built-in structure, clear

of obstruction.

WARNING: Do not use mechanical devices or other

means to accelerate the defrosting process, other

than those recommended by the manufacturer.

WARNING: Do not use electrical appliances inside

the food storage compartments of the

appliance, unless they are of the type recommended

by the manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: To avoid a hazard due to the instability



the instructions.

If your appliance uses R600 as a refrigerant –

you can learn this information from the label on

the cooler- you should be careful during shipment

and montage to prevent your appliance’s cooler

elements from being damaged. Although R600a

is a environmental friendly and natural gas, as it



due to a damage in the cooler elements move



ventilate the room where the appliance is located

for a few minutes.

While carrying and positioning the fridge, do not

give damage to the cooler gas circuit.

      



appliance.

This appliance is intended to be used in

household and similar applications such as;

-         

environments

- farm houses and by clients in hotels, motels and other

residential type environments

- bed and breakfast type environments;

- catering and similar non-retail applications

If the socket does not match the refrigerator plug, it must

be replaced by the manufacturer, its service agent or



This appliance is not intended for use by persons

(including children) with reduced physical, sensory or



unless they have been given supervision or instruction

concerning use of the appliance by a person responsible

for their safety. Children should be supervised to ensure

that they do not play with the appliance.

A specially grounded plug has been connected to the

power cable of your refrigerator. This plug should be used

with a specially grounded socket of 16 amperes. If there is

no such socket in your house, please have it installed by

an authorized electrician.

This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or



they have been given supervision or instruction concerning

use of the appliance in a safe way and understandt the

hazard involved. Children shall not play with the appliance.

Cleaning and user maintenance, shall not be made by

children without supervision.

If the supply cord is demaged, it must be replaced by the



in order to avoid a hazard.

BEFORE USING YOUR FRIDGE

Old and out-of-order fridges

 If your old fridge has a lock, break or remove the lock

before discarding it, because children may get trapped

inside it and may cause an accident.

 Old fridges and freezers contain isolation material and

refrigerant with CFC. Therefore, take care not to harm

environment when you are discarding your old fridges.

 Please ask your municipal authority about the disposal of

the WEEE for the reuse, recycle and recovery purposes.

Notes:

 Please read the instruction manual carefully before

installing and using your appliance. We are not responsible

of the damage occurred due to misuse.

 Follow all instructions on your appliance and instruction

manual, and keep this manual in a safe place to resolve

the problems that may occur in the future.

 This appliance is produced to be used at houses and it can



is not suitable for commercial or common use. Such use

will cause the guarantee of the appliance to be cancelled

and our company will not be responsible for the losses to

be occurred.

 This appliance is produced to be used in houses and it is

only suitable for cooling / storing foods. It is not suitable for

commercial or common use and/or for storing substances

    

losses to be occurred in the contrary case.

BEFORE USING YOUR FRIDGE

Safety warnings

 

 Do not plug in damaged, torn or old plugs.

 Do not pull, bend or damage the cord.

 This appliance is designed for use by adults, do not allow

children to play with the appliance or let them to hang over

the door.

 Do not plug-in or out the plug from the receptacle with wet

hands to prevent electrocution!

 Do not place glass bottles or beverage cans in the freezer



 

for your safety. Place drinks with higher alcohol amount

vertically and by closing their necks tightly in the fridge

department.

 When taking ice made in the freezer department, do not

touch it, ice may cause ice burns and/or cuts.

 Do not touch frozen goods with wet hands! Do not eat ice-

cream and ice cubes immediately after you take them out

of the freezer department!

 Do not re-freeze the frozen goods after being melted. This

may cause health issues like food poisoning.

 Do not cover the body or top of fridge with lace. This affects

the performance of your fridge.

 

prevent damage to accessories.

BEFORE USING YOUR FRIDGE

Installing and operating your fridge

Before starting to use your fridge, you should pay attention to

the following points:

 Operating voltage for your fridge is 220-240 V at 50Hz.

 Mains cord of your fridge has a grounded plug. This plug

should be used with a grounded receptacle that has a

16 ampere fuse minimum. If you don’t have a receptacle

         

electrician.

 We do not take the responsibility of the damages that

occur due to ungrounded usage.

 

to direct sunlight.

 Your appliance should be at least 50 cm away from stoves,

Gas ovens and heater cores, and should be at least 5 cm

away from electrical ovens.

 Your fridge should never be used outdoors or left under

the rain.

 

should be at least 2 cm between them to prevent humidity

on the outer surface.

 Do not place anything on your fridge, and install your fridge

in a suitable place so that at least 15 cm is available on the

upper side.

 The adjustable front legs should stabilized in an appropriate

height to allow your fridge operate in a stable and proper

way. You can adjust the legs by turning them clockwise

(or in the opposite direction). This should be done before

placing food in the fridge.

 Before using your fridge, wipe all parts with warm water

added with a tea spoonful of sodium bicarbonate, and

then rinse with clean water and dry. Place all parts after

cleaning.

 Install the distance adjustment plastic (the part with black



to prevent the condenser from touching the wall.

8BEFORE USING YOUR FRIDGE

Before Using your Fridge

 

keep your fridge in the upright position for 3 hours and



damage the compressor.

 Your fridge may have a smell when it is operated for the



to cool.

Information about NO FROST Technology

No-Frost fridges differ from other static fridges in their operating

principle.

In normal fridges, the humidity entering the fridge in the door

openings and the humidity of the food causes freezing in

the freezer compartment. To defrost the snow and ice in the

freezer compartment, you should turn off the fridge, take the

food that needs to be kept in a constant temperature off the

fridge, and remove the ice gathered in the freezer compartment

periodically.

The situation is completely different in no-frost fridges. Dry

and cold air is blown to the fridge and freezer compartments

homogeneously from several points via a blower fan. Cold air

dispersed homogeneously even between the shelves cools all

your food equally and uniformly, thus prevents humidity and

freezing.

Therefore your no-frost fridge allows you ease of use, besides

its huge volume and stylish appearance.

PARTS AND PIECES OF YOUR FRIDGE

The purpose of this presentation is informing you about the parts of

your appliance.

The parts may vary depending on the model of the appliance.

Table des matières

Autres manuels Smeg Réfrigérateur

Smeg

Smeg FR 320 P Manuel utilisateur

Smeg

Smeg Inox FD70EN4HX Manuel utilisateur

Smeg

Smeg CF33SF Manuel utilisateur

Smeg

Smeg FA160X Manuel utilisateur

Smeg

Smeg FA350X Manuel utilisateur

Smeg

Smeg FA326X Guide de démarrage rapide

Smeg

Smeg FAB5RWH5 Manuel utilisateur

Smeg

Smeg D8140F Manuel utilisateur

Smeg

Smeg FI167A Manuel utilisateur

Smeg

Smeg CR324A7 Manuel utilisateur

Smeg

Smeg FAB38 Manuel utilisateur

Smeg

Smeg 50's Style FAB38RPB Manuel utilisateur

Smeg

Smeg FA490RAN Manuel utilisateur

Smeg

Smeg Integrated Refrigerator with Freezer... Manuel utilisateur

Smeg

Smeg FA40X5 Guide de démarrage rapide

Smeg

Smeg FC18EN4 Manuel utilisateur

Smeg

Smeg FC370A Manuel utilisateur

Smeg

Smeg FC335BNF Manuel utilisateur

Smeg

Smeg FR150SE Instructions de fonctionnement

Smeg

Smeg FR205A Manuel utilisateur

Smeg

Smeg FL102A Manuel utilisateur

Smeg

Smeg FD43PSNF4 Manuel utilisateur

Smeg

Smeg C3172NP1 Manuel utilisateur

Smeg

Smeg FAB28RDBB5 Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
