Contents

1INSTRUCTIONS FOR SAFE AND PROPER USE ______________________ 4

2POSITIONING OF THE HOB ______________________________________ 6

3ELECTRICAL CONNECTION______________________________________ 7

4GAS CONNECTION _____________________________________________ 8

5ADJUSTMENT FOR DIFFERENT TYPES OF GAS ____________________ 10

6FINAL OPERATIONS ___________________________________________ 14

7USING THE HOB ______________________________________________ 16

8CLEANING AND MAINTENANCE _________________________________ 18

THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIE

WHOSE IDENTIFICATION SYMBOLS APPEAR ON THE COVER OF THI

MANUAL.

INSTRUCTIONS FOR THE INSTALLER: these are for the qualified

technician who must carry out a suitable check of the gas system, install

the appliance, set it functioning and carry out an inspection test.

INSTRUCTIONS FOR THE USER: these contain user advice, descriptio

of the commands and the correct procedures for cleaning an

maintenance of the appliance.

Introduction

1 INSTRUCTIONS FOR SAFE AND PROPER USE

THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND

THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN

ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE

COOKING HOB. WE ADVISE READING THIS MANUAL AND ALL THE

INSTRUCTIONS THEREIN BEFORE USING THE COOKING HOB. ALSO

KEEP THE SERIES OF NOZZLES SUPPLIED. INSTALLATION MUST

BE CARRIED OUT BY QUALIFIED PERSONNEL IN ACCORDANCE

WITH THE REGULATIONS IN FORCE. THIS APPLIANCE IS INTENDED

FOR DOMESTIC USES AND CONFORMS TO CURRENT

REGULATIONS IN FORCE. THE APPLIANCE HAS BEEN BUILT TO

CARRY OUT THE FOLLOWING FUNCTIONS: COOKING AND

HEATING-UP OF FOOD. ALL OTHER USES ARE CONSIDERED

IMPROPER. THE MANUFACTURER DECLINES ALL RESPONSIBILITY

FOR IMPROPER USE.

DO NOT LEAVE THE PACKING IN THE HOME ENVIRONMENT.

SEPARATE THE VARIOUS WASTE MATERIALS AND TAKE THEM TO

THE NEAREST SPECIAL GARBAGE COLLECTION CENTRE.

IT IS OBLIGATORY FOR THE ELECTRICAL SYSTEM TO BE

GROUNDED ACCORDING TO THE METHODS REQUIRED BY SAFETY

RULES.

THE PLUG TO BE CONNECTED TO THE POWER CABLE AND THE

SOCKET MUST BE THE SAME TYPE AND MUST CONFORM TO

CURRENT REGULATIONS.

THE SOCKET MUST BE ACCESSIBLE AFTER THE APPLIANCE HAS

BEEN BUILT IN.

NEVER UNPLUG BY PULLING ON THE CABLE.

IMMEDIATELY AFTER INSTALLATION CARRY OUT A BRIEF

INSPECTION TEST OF THE COOKING HOB, FOLLOWING THE

INSTRUCTIONS BELOW. SHOULD THE APPLIANCE NOT FUNCTION,

DISCONNECT IT FROM THE SUPPLY AND CALL THE NEAREST

TECHNICAL ASSISTANCE CENTRE.

NEVER ATTEMPT TO REPAIR THE APPLIANCE.

ALWAYS CHECK THAT THE CONTROL KNOBS ARE IN THE

POSITION "ZERO" (OFF) WHEN YOU FINISH USING THE HOB.

Introduction

THE IDENTIFICATION PLATE, WITH TECHNICAL DATA, SERIAL

NUMBER AND MARKING IS CLEARLY VISIBLE UNDER THE CASING.

THE PLATE ON THE CASING MUST NOT BE REMOVED.

BEFORE CONNECTING THE DEVICE, MAKE SURE THAT IT HAS

BEEN REGULATED FOR THE TYPE OF GAS THAT WILL FEED IT,

CHECKING THE LABEL UNDER THE HOB.

DO NOT PUT PANS WITHOUT PERFECTLY SMOOTH AND FLAT

BOTTOMS ON THE COOKING HOB GRIDS.

DO NOT USE PANS OR GRIDDLE PLATES THAT EXTEND BEYOND

THE EXTERNAL PERIMETER OF THE HOB.

THE HOB IS TO BE USED BY ADULTS ONLY. DO NOT LET

UNSUPERVISED CHILDREN PLAY WITH THE HOB.

REPLACED APPLIANCES MUST BE TAKEN TO A SPECIAL GARBAGE

COLLECTION CENTRE.

The manufacturer declines all responsibility for damage to persons o

things caused by non-observance of the above prescriptions or b

interference with any part of the appliance or by the use of non-origina

spares.

Instructions for the installer

2 POSITIONING OF THE HOB

The following operation requires building and/or carpentry work so mus

be carried out by a competent tradesman.

Installation can be carried out on various materials such as masonry,

metal, solid wood or plastic laminated wood as long as they are hea

resistant (T 90°C).

2.1 Attachment to support structure

Create an opening with the dimensions

shown in the figure in the top surface of

the counter, keeping a minimum

distance of 50 mm from the rear border.

This appliance can be mounted against

walls higher than the work surface on

condition that a certain distance “X” be

kept between the appliance and the wall

as shown in the figure so as to avoid

damage from overheating.

Make sure there is a minimum of 750 mm between the hot plate flames

and any shelf that may be installed directly above them. Accurately

position the gasket provided all around the outer edge of the hole in the

top surface as shown in the figures below, pressing it down so as to

make it adhere properly. Refer to the dimensions shown in the diagram,

bearing in mind that the sides A must be flush with the hole. Fix the hob

to the unit using the brackets B provided.

Carefully trim any excess from border C of the gasket. The distances in

the following drawing refer to the hole on the inner side of the gasket.

Instructions for the installer

3 ELECTRICAL CONNECTION

Make sure that the voltage and capacity of the power line conform to the

data shown on the plate located under the casing. Do not remove this

plate for any reason.

The plug on the end of the supply cable and the wall socket must be the

same type and conform to the current electrical system regulations.

Check that the power line is adequately grounded.

On the power line, install an omnipolar cut-off device with contact cut-off

distance greater than or equal to 3 mm, located in an easily accessible

position near the unit.

Do not use reducers, adapters or shunts.

If the power cable is replaced, the wire section on the new cable must

not be less than 1.0 mm 2

(3 x 1.0 cable), keeping in mind that the end to

be connected to the hob must have the ground wire (yellow-green)

longer by at least 20 mm. Use only H05V2V2-F cable or similar which

has a maximum temperature of 90°C. Any replacement needed should

be carried out by a specialised technician who should make the mains

connections according to the following diagram.

L= brown

N= blue

= yellow-green

The manufacturer will not be liable for any damage to persons o

property caused by non-observance of the above instructions o

deriving from the tampering of even a single part of the hob.

Instructions for the installer

4 GAS CONNECTION

Connection to the gas mains may be made with a rigid copper pipe or

with a flexible pipe and conforming to the provisions defined by

standard regulations in force.

To facilitate connection, fitting Aon the rear of the appliance may be

adjusted laterally. For this purpose, undo the hexagonal nut B, turn the

union A into the position required and retighten the hexagonal nut B to

a torque of at least 20 Nm. An annealed aluminium gasket provides the

seal.

If the gasket is removed it may NOT be reused and must be

replaced with another of exactly the same type.

Use a soapy solution to check for proper tightness. Never use a free

flame.

The hob has been inspected for G20 (2H) natural gas at a pressure of

20 mbar. For use with other types of gases, see Section “5.

ADJUSTMENT FOR DIFFERENT TYPES OF GAS”. The gas intake

fitting is ½” gas external tapered thread (ISO 7-1).

Always place a suitable sealing medium (such as Teflon tape) between

union A and pipe C/D.

Connection with rigid copper pipe: the

connection to the gas mains must not

provoke stress of any kind on the hob.

Connection may be made by using biconical

adapter D.

Connection with flexible pipe: use only

flexible pipes conforming to standard

regulations in force.

The flexible pipe has to be installed so that pipe length does not excee

the maximum extension allowed by the regulations in force. Make sur

that the pipe does not touch any moving parts or become damaged.

Instructions for the installer

4.1 Connection to LPG

Use a pressure regulator and make the connection to the tank according

to the provisions of standards regulations in force. Make sure that feed

pressure conforms to the levels shown in the table in paragraph “5.2

Regulation for LPG”.

4.2 Ventilation of rooms

The hob may be installed only in rooms with permanent ventilation, as

required by standards regulations in force. The room in which the hob is

installed must have sufficient air flow to satisfy the requirements of

normal gas combustion and of necessary air exchange in the room. The

air intakes, protected by screens, must be appropriately sized

(regulations in force) and placed so as not to be blocked in any way.

The room where the oven is installed should be suitably ventilated to

avoid overheating or excess humidity produced by cooking, and in the

case of lengthy use a window should be opened or the speed of any

ventilators should be increased.

4.3 Discharge of combustion products

Discharge of combustion products must be guaranteed by means of

hoods connected to a natural draught flue with certain efficiency, or by

means of forced aspiration.

An efficient aspiration system requires careful planning by a specialist

capable of installing it, respecting the positions and distances prescribed

by standards. After installation, the installer must issue a certificate of

conformity.

Instructions for the installer

5 ADJUSTMENT FOR DIFFERENT TYPES O

GAS

Before performing any cleaning or maintenance work, disconnect th

appliance from the electrical socket.

A label on the bottom enclosure of the hob declares for which type of

gas the appliance has been adjusted. For functioning with other types of

gas the nozzles must be replaced and the primary air adjusted.

To replace the nozzles and regulate the burners, operate as described

in the following paragraph.

5.1 Removing the hob

1. Remove all the knobs, the grids, the burner caps and the flame-

caps;

2. Remove the screws and the nuts A that secure the burner supports;

3. Remove plates B;

4. Lift the hob from its seat;

5. Replace the burner nozzles in accordance with the relevant gas

table;

6. adjust the primary air as described in paragraph “5.2 Nozzle

replacement and primary air adjustment

Instructions for the installer

5.2 Nozzle replacement and primary air adjustment

Loosen screw A and push support B all the way. Use a double head

wrench to remove nozzle C and assemble the suitable one, following

the values indicated in the tables relevant to the type of gas to use. The

screwing torque of the nozzle should never exceed 3 Nm. Reposition

support B so that nozzle C is covered perfectly.

Move the Venturi tube D to regulate the air flow until distance “X” is

reached indicated in the table “Regulation of primary air” and then

secure the tube by means of screw A. After the regulations have been

carried out, restore the seals with sealing wax or equivalent material.

Burner

Rated

heating

capacity

LPG – G30/G31 2.8 kPa

Nozzle

diameter

1/100 mm

By-pass

1/100 mm

Reduced

flowrate

(W)

Flowrate

g/h G30 Flowrate

g/h G31

Auxiliary 1.05 48 30 (1) 380 76 75

Semi-rapid 1.65 62 30 (1) 380 120 118

Rapid 2.55 76 37 (2) 750 185 182

Rapid large 3.1 85 45 800 225 222

Fish pan 1.8 65 43 (3) 750 145 143

Ultra rapid 3.3 87 65 1700 240 236

Internal 0.8 42 26 (1) 380 58 57

Double

crown External 3.3 87 55 1200 240 236

(1)= 33 for appliances without flame failure device.

(2)= 40 for appliances without flame failure device.

(3)= 45 for appliances without flame failure device.

Instructions for the installer

Burner

Rated

heating

capacity

Natural gas – G20 2.0 kPa

Nozzle diameter

1/100 mm Reduced flowrate

(W)

Auxiliary 1.05 73 380

Semirapid 1.65 92 380

Rapid 2.55 115 750

Rapid large 3.1 126 800

Fish pan 1.8 95 100

Ultra rapid 3.3 130 1400

Internal 0.8 67 380

Double

crown External 3.3 130 900

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Smeg Plaque

Smeg

Smeg KF24.1 Manuel utilisateur

Smeg

Smeg SIM3844D Manuel utilisateur

Smeg

Smeg SE2542 Manuel utilisateur

Smeg

Smeg Hob Mode d’emploi

Smeg

Smeg SE2664ID Manuel utilisateur

Smeg

Smeg SE435XT Manuel technique

Smeg

Smeg Gas Cooktop PA106SX Manuel utilisateur

Smeg

Smeg SE2664TCX Manuel utilisateur

Smeg

Smeg PGFA95F Manuel utilisateur

Smeg

Smeg SER63LPG Manuel utilisateur

Smeg

Smeg SIM1963DS Manuel utilisateur

Smeg

Smeg Dual Fuel Range Cooker A3A-5 Manuel utilisateur

Smeg

Smeg PV375CN Manuel utilisateur

Smeg

Smeg PV373LCN Manuel utilisateur

Smeg

Smeg PGF30T-1 Manuel utilisateur

Smeg

Smeg SI5632D Manuel utilisateur

Smeg

Smeg PV164CN2AU Manuel utilisateur

Smeg

Smeg SE2642TC Manuel utilisateur

Smeg

Smeg PGA32G Manuel utilisateur

Smeg

Smeg SIM581B Manuel utilisateur

Smeg

Smeg SI1F7645B Manuel utilisateur

Smeg

Smeg SE2664ID Manuel utilisateur

Smeg

Smeg Hob Manuel utilisateur

Smeg

Smeg SE2541 Manuel utilisateur

Manuels Plaque populaires d'autres marques

Siemens

Siemens EX875KYV1E Fiche technique

AEG

AEG CERAMIC HOB 6010 K Manuel utilisateur

VALERA

VALERA CT 70A Manuel utilisateur

Zanussi

Zanussi ZGF 6420 Manuel utilisateur

Gaggenau

Gaggenau CI 273 Manuel utilisateur

G3 Ferrari

G3 Ferrari Energy Manuel utilisateur

Pkm

Pkm IN4B Manuel utilisateur

Award

Award H903BG Manuel utilisateur

Zanussi

Zanussi VCH 5005 RZ Manuel utilisateur

Miele

Miele KM 523 Manuel utilisateur

Hotpoint

Hotpoint IS67V8CCXT/E Manuel utilisateur

AEG

AEG HK854870XB Manuel utilisateur

Cookology

Cookology SEP600BK Manuel utilisateur

Bauknecht

Bauknecht Hob Manuel utilisateur

Zanussi

Zanussi ZGM 782 Manuel utilisateur

dipo INDUCTION

dipo INDUCTION DIBK218S Manuel utilisateur

Miele

Miele KM 5987 Manuel utilisateur

Miele

Miele KM 360 G Manuel utilisateur
