Smeg ECF01 Manuel utilisateur

Description

ENITEN

2 Description

2.1 Product Description

Model ECF01 - Espresso Machine

1 Cup warmer tray

2 Grouphead

3 Filter holder

4 Steel cup tray

5 Floater

6 Stainless steel drip tray

7 Hot water and steam wand/Cappuccino

frother

8 Steam valve

9 ON/OFF switch

10 Water tank cover

11 Water tank (1 liter)

12 Measuring scoop/tamper

13 Soft pod filter basket

14 1-cup ground coffee filter basket

15 2-cup ground coffee filter basket

16 Water softener filter (optional)

17 1-cup coffee button (white light)

18 2-cup coffee button (white light)

19 Steam button (white light)/Descaler

button (orange light)

20 Non-slip feet

17 18 19

Use

3 Use

3.1 Before first use

1. Remove any labels and stickers from the

espresso machine.

2. Thoroughly wash and dry the espresso

machine’s parts (see “4 Cleaning and

maintenance”).

3. Remove the cover (1) by pulling it

upwards and then pull out the tank (2).

4. Fill the tank (2) with fresh, clean water

directly from the faucet or by using a

pitcher, being careful not to exceed the

maximum level indicated on the tank.

Risk of accident

• Do not operate the espresso machine

without water in the tank or without the

tank in place.

The parts that may come into

contact with food are made of

materials that comply with all legal

provisions in force.

Use

ENITEN

3.2 First use

1. Turn on the espresso machine using the

ON/OFF switch (1): the lights of the

three buttons (2), (3) and (4) will flash in

sequence.

2. Lights (2) and (3) will flash to indicate

that the machine is reaching the pre-set

temperature. The espresso machine is

ready for use as soon as the lights stop

flashing.

3. Place a container under the hot water/

steam wand (4).

4. Turn the steam valve (5) to the

position and dispense 1/2 cup of water.

5. Turn the steam valve (5) back to the

position.

6. Attach the filter holder by aligning the

handle with and turning it to the

right to the position.

7. To rinse the machine’s internal circuits,

place a container under the coffe spout

and press the button.

8. Repeat this procedure 5 times.

2 3 4

Make 4-5 espressos or 4-5

cappuccinos to obtain a

satisfactory result.

Use

Then proceed with rinsing the “steam”

circuit:

9. Place a container under the hot water

spout and turn the steam valve to the

position. Hot water is delivered.

10. When the appliance automatically

stops the hot water delivery, turn the

steam valve back to the position.

11. Repeat this procedure 1 more time (if

necessary, refill the tank).

Filters

The coffee machine comes with three filters:

a one-cup filter, a two-cup filter, and a soft

pod filter. Below each filter you will find the

corresponding symbol.

3.3 How to make espresso

Ground coffee:

1. Place the ground coffee filter basket (1)

in the filter holder (2), choosing the one-

cup or the two-cup basket.

2. Tamp the ground coffee down using the

tamper (3).

Use

ENITEN

3. Wipe off any excess ground coffee

from the edge of the filter holder.

Attach the filter holder by aligning the

handle with and turning it to the

right to the position.

4. Place the cup or cups under the filter

holder spouts and press the coffee

button or .

• For one cup, fill the filter basket

with one level scoop of coffee

(about 1 tablespoon.)

• For two cups, fill the filter basket

with two scoops of coffee.

• For a stronger coffee, tamp the

ground coffee hard with the

tamper.

• For a weaker coffee, use the

tamper to tamp the ground

coffee lightly.

Risk of scalding

• To avoid any splashing, do not detach

the filter holder while coffee is being

dispensed. Wait a few seconds for the

process to finish.

After the machine has not been

used for a while (more than 30

minutes) it is normal for the first

cups of coffee not to be at the right

temperature.

The recommendations for

obtaining a hot coffee immediately

are shown in section “4.5 What to

do if...”

Use

Coffee soft pods:

1. Insert the coffee soft pod filter basket

in the filter holder.

2. Insert the soft pod in the filter holder trying

to center it as much as possible.

3. Proceed in the same way as with ground

coffee.

3.4 How to make cappuccino

1. Make an espresso in a large cup.

2. Press the button: the light will flash.

3. Fill a container with 1/2 cup cold,

partially skimmed milk for each

cappuccino you want to make.

4. When the light stops flashing, place

an empty container under the

cappuccino frother (1) and turn the

steam valve (2) to the position to

drain any water present and then close

the valve.

5. Place the container with the milk under

the cappuccino frother (1), immersing the

cappuccino frother a few millimeters

below the surface. Turn the steam valve (2)

to the position and slowly move the

container up and down to obtain a

creamier foam.

Risk of scalding

• To avoid any splashing, do not detach

the filter holder while coffee is being

dispensed. Wait a few seconds for the

process to finish.

• The process can be interrupted

at any time by pressing the coffee

button.

• To increase the amount of coffee

in the cup, hold down the coffee

button.

Use

ENITEN

6. Once the volume of the milk has

doubled, dip the cappuccino frother

deep into the milk and heat to 140°F

(60°C). Stop the frothing process by

turning the steam valve clockwise.

7. Pour the milk into the cups with the

espresso.

3.5 How to heat water

1. Turn the machine on using the ON/OFF

switch.

2. Place a container under the cappuccino

frother.

3. Turn the steam valve to the position

to let the hot water out.

3.6 Accessing the programming

menus and changing the settings

1. Make sure that the machine is ready to

use and hold the button for 10

seconds until the three buttons start

flashing: the machine will enter

programming mode.

2. Program the machine settings to your

own needs.

3. To exit the menu, simply do not press any

button for 15 seconds.

• To make more than one

cappuccino, first prepare all the

espresso and then froth the milk

for all the cappuccinos.

• For hygiene reasons, it is

recommended to clean the

cappuccino frother after use.

• Clean out the milk residue by

opening the steam valve to let out

the steam.

• Release the steam for only a

maximum of 60 seconds.

• Release the steam for only a

maximum of 60 seconds.

Use

Setting the coffee temperature

1. Access the programming menu.

2. Press the button to select the

temperature of the coffee. The lights of

the current setting will turn on:

3. The lights will start flashing in sequence.

4. Press the button corresponding to the

desired temperature: low ,

medium or high .

5. The button will flash to indicate the

selection has been saved.

Setting the amount of coffee

To change the quantity of coffee dispensed

by the machine:

1. Place one or two cups under the filter

holder spouts.

2. Press the button for one cup or two

cups and hold it down.

3. The machine will start dispensing coffee.

4. Release the button as soon as you reach

the desired amount of coffee.

5. The light will flash to indicate that the

selected quantity has been saved.

Setting the water hardness

1. Access the programming menu.

2. Press the button to select the water

hardness. The lights of the current setting

will turn on:

3. The lights will start flashing in sequence.

4. Press the button corresponding to the

water hardness:

5. The button will flash to indicate the

selection has been saved.

Lights Temperature setting

Low

Medium

High

Lights Water setting

Soft

Medium

Hard

soft medium hard

<10°dH 10°dH - 20°dH > 20°dH

<18°fH 18°fH - 36°fH > 36°fH

< 180 mg/l

CaCo3

180-300 mg/l

CaCo3

360 mg/l

CaCo3

Use

ENITEN

Setting the auto shut-off time

For energy saving reasons, the espresso

machine is equipped with an auto shut-off

feature that activates when the machine has

been left on for a long time.

To set the auto shut-off time:

1. Access the programming menu.

2. Press the button to select the auto

shut-off time. The lights of the current

setting will turn on:

3. The lights will start flashing in sequence.

4. Press the button corresponding to the

time you want to set, choosing from 9

minutes , 30 minutes or 3

hours .

5. The button will flash to indicate the

selection has been saved.

Restoring the factory settings

To restore factory settings:

1. Access the programming menu.

2. Turn the steam valve to the position.

3. Press the button: the three lights will

blink to indicate that the original settings

have been restored.

4. Turn the steam valve back to the

position.

Lights Time setting

9 minutes

30 minutes

3 hours

Use

3.7 How to cool down the boiler

The boiler must be cooled down if you want

to make coffee immediately after frothing

milk for cappuccino.

If the boiler is not cooled down, the coffee

will be burned.

1. Place a container under the cappuccino

frother and open the steam valve to

dispense hot water.

2. The hot water will stop coming out as

soon as the machine has cooled down.

3. Close the steam valve and proceed with

making the coffee.

Autres manuels pour ECF01

Table des matières

Autres manuels Smeg Cafetière

Smeg

Smeg DCF01 Manuel utilisateur

Smeg

Smeg BCC11WHMEU Manuel utilisateur

Smeg

Smeg DCF02DGUS Manuel utilisateur

Smeg

Smeg BCC02 Manuel utilisateur

Smeg

Smeg CMSU6451X Manuel utilisateur

Smeg

Smeg BCC12BLMEU Manuel utilisateur

Smeg

Smeg CMSC45B Manuel utilisateur

Smeg

Smeg BCC01 Manuel utilisateur

Smeg

Smeg DCF02 Manuel utilisateur

Smeg

Smeg DCF02BLUS Manuel utilisateur

Smeg

Smeg 50's Style Series Manuel utilisateur

Smeg

Smeg DCF02 Manuel utilisateur

Smeg

Smeg DCF02RDEU Manuel utilisateur

Smeg

Smeg BCC01WHMUS Manuel utilisateur

Smeg

Smeg EGF03 Manuel utilisateur

Smeg

Smeg DOLCE& GABANNA CGF01DGBEU Manuel utilisateur

Smeg

Smeg ECF02 Manuel utilisateur

Smeg

Smeg CMS4604NX Manuel utilisateur

Smeg

Smeg CMS6451X Manuel utilisateur

Smeg

Smeg ECF02WHEU Manuel utilisateur

Smeg

Smeg BCC02 Manuel utilisateur

Smeg

Smeg CM845A-9 Manuel utilisateur

Smeg

Smeg Dolce Stil Novo CMS4101S Manuel utilisateur

Smeg

Smeg ECF01 Manuel utilisateur

Manuels Cafetière populaires d'autres marques

Taurus

Taurus Livorno 6 Manuel utilisateur

Delta-q

Delta-q QUICK Manuel utilisateur

Bunn

Bunn LCA-1 Guide de dépannage

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instructions d'installation

Saeco

Saeco Vienna Plus Sup 018M Manuel utilisateur

DeLonghi

DeLonghi DC300 Manuel utilisateur

INCAPTO

INCAPTO BXCO1470E Manuel utilisateur

Bosch

Bosch TASSIMO finesse TAS16B Series Manuel utilisateur

Exido

Exido 245-072 Manuel utilisateur

Animo

Animo OptiVend Choco Manuel utilisateur

Siemens

Siemens TQ505DF Series Manuel utilisateur

DeLonghi

DeLonghi ECI341 Manuel utilisateur

Krups

Krups KT406511 Manuel utilisateur

Cimbali

Cimbali M32 Classic Manuel utilisateur

Philips

Philips HL3844N Manuel utilisateur

Bosch

Bosch TES 515 SERIES Manuel utilisateur

Tekmatix

Tekmatix TMFM - 65 Manuel utilisateur

Scarlett

Scarlett SC-CM33005 Manuel utilisateur
