EZ Connect g

802.11g Wireless PCI Adapter

SMCWPCI-G2

20 Mason

Irvine, CA 92618

Phone: (949) 679-8000

EZ Connect™ g 802.11g

Wireless PCI Adapter

User Guide

The easy way to make all your network connections

February 2008

Pub No: R01

Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable.

However, no responsibility is assumed by SMC for its use, nor for any infringements of patents

or other rights of third parties which may result from its use. No license is granted by

implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to

change specifications at any time without notice.

SMC Networks, Inc.

20 Mason

Irvine, CA 92618

Trademarks:

SMC is a registered trademark; and EZ Connect is a trademark of SMC Networks, Inc. Other

product and company names are trademarks or registered trademarks of their respective

holders.

Compliances

Federal Communication Commission Interference

Statement

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate this

equipment.

IMPORTANT NOTE

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance of 20 cm between the radiator and your body.

This transmitter must not be co-located or operating in conjunction with any other

antenna or transmitter.

2.4GHz operation of this product in the U.S.A. is firmware-limited to channels 1

through 11.

Compliances

IC (Industry Canada) Statement

This device complies with RSS-210 of the Industry Canada Rules.

Operation is subject to the following two conditions:

1) this device may not cause interference and

2) this device must accept any interference, including interference that may cause

undesired operation of the device

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numerique de la class B est conforme a la norme NMB-003 du

Canada.

This device has been designed to operate with an antenna having a maximum

gain of 2 dBi. Antenna having a higher gain is strictly prohibited per regulations of

Industry Canada. The required antenna impedance is 50 ohms

To reduce potential radio interference to other users, the antenna type and its gain

should be so chosen that the EIRP is not more than required for successful

communication.

IMPORTANT NOTE:

IC Radiation Exposure Statement:

This equipment complies with Canada radiation exposure limits set forth for

uncontrolled environments. This equipment should be installed and operated with

minimum distance of 20 cm between the radiator and your body.

This transmitter must not be co-located or operating in conjunction with any other

antenna or transmitter.

2.4GHz operation of this product in Canada is firmware-limited to

channels 1 through 11.

Compliances

iii

EC Conformance Declaration

SMC contact for these products in Europe is:

SMC Networks Europe,

Edificio Conata II,

Calle Fructuos Gelabert 6-8, 2, 4a,

08970 - Sant Joan Despi,

Barcelona, Spain

Marking by the above symbol indicates compliance with the Essential

Requirements of the R&TTE Directive of the European Union (1999/5/EC). This

equipment meets the following conformance standards:

EN 300 328

EN 301 489-1

EN 301 489-17

EN 60950

NCC (Taiwan)

注意 !

依據低功率電波輻射性電機管理辦法

第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均

不得擅自變更頻率、加大功率或變更原設計之特性及功能。

第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干

擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通

信，指依電信規定作業之無線電信。低功率射頻電機須忍受合法通信或

工業、科學及醫療用電波輻射性電機設備之干擾。

ABLE

ONTENTS

EZ Connect™g 802.11g Wireless PCI Adapter . . 1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Package Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Hardware Description . . . . . . . . . . . . . . . . . . . . . . . 5

LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . 6

Driver and Utility Installation . . . . . . . . . . . . . . . . . 8

Using the Installation Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Utility Configuration . . . . . . . . . . . . . . . . . . . . . . . 11

Using the SMCWPCI-G2 Utility Program . . . . . . . . . . . . . . . . . 11

Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Link Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

IP Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Site Survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Version Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Network Configuration and Planning . . . . . . . . . 25

Network Topologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Ad Hoc Wireless LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Infrastructure Wireless LAN . . . . . . . . . . . . . . . . . . . . . . 26

Setting the Communication Domain . . . . . . . . . . . . . . . . . . . . . 27

Stationary Wireless PCs . . . . . . . . . . . . . . . . . . . . . . . . . 27

Roaming Wireless PCs . . . . . . . . . . . . . . . . . . . . . . . . . . 27

ABLE

ONTENTS

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .29

Adapter Installation Problems . . . . . . . . . . . . . . . . . . . . . . . . . 29

Network Connection Problems . . . . . . . . . . . . . . . . . . . . . . . . 30

SMCWPCI-G2 Maximum Distance Table . . . . . . . . . . . 31

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

EZ CONNECT™G802.11G

WIRELESS PCI ADAPTER

SMC’s EZ Connect™g 802.11g Wireless PCI Adapter

(SMCWPCI-G2) is a 54 Mbps wireless network adapter for

desktop PCs that seamlessly integrates with existing Ethernet

networks. This solution offers a high data rate and reliable

wireless connectivity with considerable cost savings over wired

LANs (which include long-term maintenance overhead for

cabling). Just install enough wireless access points to cover your

network area, plug wireless cards into your desktop computers,

and start networking.

Using this card in conjunction with SMC wireless access points,

you can create an instant network that integrates seamlessly with

10/100 Mbps Ethernet LANs. Moving or expanding your network

is as easy as moving or installing additional access points – no

wires!

Features

•Up to 54 Mbps data rate

•Wireless connection without the hassles and cost of cabling

•Greater flexibility to locate or move networked computers

•Integrates with or replaces wired LANs at dramatically lower

cost than wired alternatives

•Seamless connectivity to wired Ethernet LANs augments

existing networks quickly and easily

APPLICATIONS

•Easy installation

•Working range up to 60 m (197 ft) at 54 Mbps, or up to 350 m

(1,155 ft) at 1 Mbps for indoor communications

•Direct Sequence Spread-Spectrum (DSSS) technology

provides robust, interference-resistant and secure wireless

connection

•Supports a wide range of systems

(Windows 2000/XP/Vista)

•Provides a user-friendly interface for configuration

•Enhances your network security with WEP and WPA/WPA2

data encryption

•Removable antenna

Applications

EZ ConnectTM g wireless products offer fast and reliable network

access for wireless clients in applications such as:

• Remote access to corporate network information

Email, file transfer, and terminal emulation

• Difficult-to-wire environments

Historic or old buildings, asbestos installations, and open

areas where wiring is difficult to employ

• Frequently changing environments

Retailers, manufacturers, and banks who frequently

rearrange the workplace and change location
