SmartVent Synergy2 SYN190E2 Manuel utilisateur
Your guide to a healthier home
HOME VENTILATION SYSTEMS
SYN190E2
User Manual
Warning
- This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
- Children should be supervised to ensure that they do not play with the appliance.
- Isolate the mains supply before attempting to replace the system’s air filter.
3
SMARTVENT SYNERGY2 SYSTEM
Contents
How the System Works ........................................................................... 4
Quick Setup Guide .................................................................................. 5
Screens and Navigation ........................................................................... 8
Standby Screen ................................................................................ 10
Home Screen ................................................................................... 10
Home Screen Icons .......................................................................... 11
Settings ............................................................................................ 13
Date/Time ......................................................................................... 14
Filter .................................................................................................. 15
General Settings................................................................................ 16
Settings Interface............................................................................... 17
Ventilation.......................................................................................... 18
Heat Transfer..................................................................................... 21
Tempering Heater .............................................................................. 24
Core Bypass...................................................................................... 27
Recycle ............................................................................................. 28
Maintenance........................................................................................... 29
Filters ................................................................................................ 29
Recovery Core................................................................................... 31
Troubleshooting...................................................................................... 32
Error Codes............................................................................................ 34
Glossary ................................................................................................. 35
Technical Specfications .......................................................................... 36
4
How the System Works
Some features covered in this instruction manual are only available when
installed and activated. Consult your installer for more information if you are
interested in adding additional features to your system.
The SmartVent Synergy2 System
SmartVent Synergy2 is a heat/energy recovery ventilation
system which uses air taken from the outside to ventilate your
home.
System Enhancements1)
Second Air Source
Adds air from the roof cavity as a second air source option so
that your system can provide continued quality ventilation
when the outside air is too cold or humid.
Heat Transfer
Used to transfer any excess heat from your lounge to your
bedrooms.
Tempering Heaters
Designed for situations where supply air temperatures are too
cool.
Core Bypass
Adds the ability for the system to bypass the recovery core and
take advantage of the fresh air temperature.
When system enhancements are added, your system can offer greater options
in how it operates.
The options can override or influence one another as in the following examples.
Example: When the environment in your home meets your chosen heat transfer
condition the ventilation and tempering heater functions deactivate.
Example: When the system is ventilating and conditions are met for the heater
to turn on, the speed of the fan will be influenced by the heater function.
1) For more information about SmartVent system enhancements, contact 0800 140 150 or email enquir[email protected]
5
Quick Setup Guide
1 - Switch On
- Power on the system with the power button .
2 - Unlock the Touchscreen
- Press and hold the lock icon for 5 seconds in the bottom left corner of
the screen to unlock .
6
DATE/TIME SETTINGS
TIME DATE
08 39 APR 201724
09 40 MAY 201825
10 41 JUN 201926
Quick Setup Guide (cont’d)
3 - Set the Clock
- Press the settings icon on the home screen.
- Select the DATE/TIME icon .
- Scroll and select the current date and time.
- Press the save icon to save your changes.
- Press the home icon to return to the home screen.
7
Your standard SmartVent Synergy2 ventilation system is now set up and ready to
operate.
For further instruction on how to set up Heat Transfer, go to page 18, or for
Tempering Heater set up, go to page 21.
If your system has a Summer Feature installed your SmartVent Synergy2
controller will automatically select the best quality air from either the roof cavity,
or the outside.
Quick Setup Guide (cont’d)
4 - Set Ventilation Mode and Temperature
- From the home screen press the settings icon .
- Select the the VENTILATION icon .
- Select AUTO ventilation mode.
- Press and scroll through the temperature options select your preferred
indoor temperature.
- Press the tick to confirm.
- Press the save icon to save your changes.
- Press the home icon to return to the home screen.
VENTILATION HEAT TRANSFER HEATER
VENTILATION MODE
TEMP
MANTIMERAUTO
22°C 22
23
21
8
Screens and Navigation
STANDBY
SETTINGS
HOME
DATE/TIME FILTER GENERAL
VENTILATION HEAT TRANSFER HEATER
SETTINGS
9
DATE/TIME
VENTILATION
HEATER1)
HEAT TRANSFER1)
GENERAL
FILTER
1) For more information about SmartVent system enhancements, contact 0800 140 150 or email enquir[email protected]
DATE/TIME SETTINGS
TIME DATE
08 39 APR 201724
09 40 MAY 201825
10 41 JUN 201926
GENERAL SETTINGS ADVANCED SETTINGS
CON CT SMARTVENT
NQUI
CONTACT SMARTVENT
0800 140 150
BRIGHTNESS
AUTO LOCK TIME
TSC V0.3.7
CCB HW V0
CCB FW V0.0.0
CCB M V0.0
AUTO SCREEN LOCK
RESET
99%G3 FILTER
USED
FILTER SETTINGS
RESET
55%
F7 FILTER
10
Standby Screen
When your SmartVent Synergy2 controller is first powered on, the standby
screen will be shown. Press the standby icon in the middle of the screen to
turn the system on.
Home Screen
If the screen is locked, press and hold the lock icon for 5 seconds in the
bottom left corner of the screen to unlock.
