SmarTrike 650 Manuel utilisateur
USA: 1-855-SMTRKUS
(1-855-768-7587)
UK: 0845 5046410
9:30am – 5:00pm Monday to Friday
Not Bank Holidays or weekends.
for assistance and advice.
Thank you for buying smarTrike,
If you have any assembly issues or are missing
a part, please call us for assistance. Our
smarTrike® assembly experts will assist you.
DO NOT RETURN TO THE STORE
If you are experiencing problems with this
product, please call our HELP LINE.
650
LOOK US UP ON YOUTUBE:
www.youtube.com/user/SmartTrikeOcial
www.smarTrike.com
-1-
20010008620
A B
20010004620
C
20010006680
D
20010001680(X2)
20010002680(X3)
B1
B2 B3
1
2
2001000163020010015680(X2)
ON P
20010016680
Q
20010011640
20010014680 20010007620
KL
200100113620
M
2001001068020010009680
E
20010012620
20010005620
J
20010014620
20010011620
G H IF
I1
BAO
1a
1b
1c
2
1
-2-
Step 1 Parts needed to complete this section
Place the washer (O)
on the axle (as shown)
Connect each back
wheel (B) to back axle.
X2
B1 B2
I1
Pull out plastic tabs from
each rear wheel (B2) until
the wheel cover(B1) opens.
Take out white plugs+
screws (B3).
P
B
B3
B1
X2 X2
CLICK!
CLICK!
CLICK!
2a
2b
2c
-3-
Step 2 Parts needed to complete this section
By using the Phillips
screwdriver (P),
screw part A3 into
part B. Firmly
tighten clockwise.
Firmly insert white
plug (B3) into axle
opening, as shown.
Align spring lock
with dropout hole in
axle and push
firmly into position,
until piece "clicks"
into place.
Re-attach wheel
cover by aligning
small cover
protrusions with
small wheel rim
holes, "click" into
place all 3
positions until the
hub is firmly
secure.
-4-
the hole (as shown)
-
b
3b
3a
Step 3 Parts needed to complete this section
Insert part E into part A all
the way through the hole
(as shown)
Insert part D into part
C all the way through
the hole (as shown)
EC D
-5-
Push the apple rmly down to
insert, slightly turn until you
-
a
4a
CLICK!
ly down to
insert, slightl you
" k r
-
b
4b
Step 4 Parts needed to complete this section
Push the apple firmly down to insert,
slightly turn until you hear a "click".
Make sure white connector is not visible.
Insert the wheel all the way
through the body of the trike until
the bolt meets the retaining head.
CLICK!
Step 5 Parts needed to complete this section
P
5a 5b
I1G
Take the seat (G), push the screw through the
seat hole & the seat belt (I1).
Screw into the most rear facing hole and
firmly tighten with Allen key (P).
By using the "Allen" key (P), remove
screw by turning counter clockwise.
-6-
-7-
Step 6 Parts needed to complete this section
6a
6b
CLICK!
With little force, push safety bar
(H) into the apple's holes until you
hear a "click".
CLICK!
1
2
Place safety bar (H) holes into
protrusions located at the back of
the seat.
Align part (F) into the designated
holes in the center of the handlebar
and push down firmly until it "clicks".
CLICK!
H
F
-8-
Step 7 Parts needed to complete this section
I
7a 7b
7c
Connect headrest (I) into
designated slots on safety bar (as
shown), until you hear a "click".
Hook cords, located on both sides
of the seat cover, onto back seat
protrusions.
WARNING: It may be dangerous to leave your child
unattended. Use a safety belt as soon as your child can sit
unaided. This seat is not suitable for children under 10 months.
Any load attached to the handle aects the stability of the
product. This product is not suitable for running or skating.
Make sure safety belt (I1) is placed
correctly on top and seat cover is
assembled properly, as shown.
CLICK!
Ensure headrest
attached correctly.
Step 8 Parts needed to complete this section
J
8a
8a
Canopy's (J) narrow arch needs to
face towards the rear of the trike.
8b
8c
CLICK!
Attach both sides of the canopy (J)
into designated slots on head rest
(I), until you hear a "click".
-9-
P
K
CLICK!
CLICK!
9c
9b
-10-
Step 9 Parts needed to complete this section
Attach basket firmly to vertical
frame (as shown), use removed
screw and turn clockwise until
secured.
Push basket (K) firmly onto
rear axle until it "clicks" into
position (see 1 & 2).
2
1
9a
By using the Phillips screwdriver
(P), remove screw by turning
counter clockwise.
