SmartPro Optimum-1 Manuel utilisateur

1.INTRODUCTION

CONTENTS

05-06

07-15

16-18

20-22

22-24

25-27

28-35

36-38

39-43

44-45

3.QUICK START GUIDE

4.FEATURES AND ADVANTAGES

2.DISCLAMERS, EXCLUSIONS AND LIMITATIONS OF LIABILITY

5.PRODUCT SPECIFICATIONS

6.DEVICE ACCESSORIES AND OVERVIEW

7.POWERING THE DEVICE

8.CALIBRATION

9.TESTING PROCEDURES

10.TEST RESULTS

11.OTHER FEATURES

12.SAFETY INFORMATION

13.SAFE HANDLING / MAINTENANCE

14.TROUBLESHOOTING

1.INTRODUCTION

Congratulations for having our SmartPro Optimum-I (SPO-I).

The very first and unique handheld diamond multi-tester using a special UV LEDs with fiber optic

technology that designed for identifying between Natural Diamond, CVD/HPHT, all types of

Moissanite, various shapes and carat weight from 0.015 carat to 10 carat for polished diamonds

Colorless to Faint (D-M) Loose diamonds or Jewelry (with or without under hole)

2.DISCLAMERS, EXCLUSIONS AND LIMITATIONS OF LIABILITY

Please read and note SMARTPRO WARRANTY TERMS AND CONDITIONS as stated in the warranty

card. SmartPro warranty for its subject to proper use by its user in accordance with all the terms and

conditions as stated in the relevant user manual and shall cover only manufacturing defects.

Due to continued product improvement, SmartPro reserves the right to revise all documents

including the right to make changes to the user manual without notice and without obligation to

notify any person of such revisions or changes. Users are advised to check SmartPro’s website

http://www.smartproinstrument.com

2.DISCLAMERS, EXCLUSIONS AND LIMITATIONS OF LIABILITY

SmartPro shall not be responsible for any damage or loss resulting from the use of the product or user

manual, and under no circumstances shall SmartPro, its manufacturer or any of its subsidiaries,licensors,

distributors, resellers, servants and/or agents be liable for any direct or indirect damages resulting from

the use of this product.

To maximum extent permitted by applicable law, under no circumstances shall SmartPro, its manufacturer

or any of its subsidiaries, licensors, distributors, resellers, servants and/or agents be liable for any

special, incidental, consequential or indirect damages howsoever caused.

Smartpro Optimum I referred to in this user manual is provided and/or sold on “as is” basis. Except as

required by applicable law, no warranties of any kind, expressed or implied, including, but not limited to,

the implied warranties of merchantability and fitness for a particular purpose.

3. QUICK START GUIDE

3.1) Turn ON/Turn OFF

1. Plug the USB cable from to Output port of Power bank /Adaptor to an Input port of SPO-I

2. Press and hold the Switch for 3 seconds to turn ON/OFF

3. QUICK START GUIDE

Bluetooth UV Torch

Press Start!

1. Cover the Probe tip

2. Click at “START” to begin the calibration

CLOSE the tester's PROBE

with its PROTECTOR

the press START for calibration

3.2) Calibration

3. QUICK START GUIDE

Press Start!

3.3) Functions

3. QUICK START GUIDE

Bluetooth UV Torch

No.

Item display Meaning

Testing START/ STOP

UV Torch ON / OFF

Information&Test results

Press Start!

Ready!

Rotate Display

Bluetooth ON/OFF

DIAMOND MOISSANITE

CVD/HPHT

3. QUICK START GUIDE

3.4) Test Setup

Ready!

NOTE: Don’t move probe away from Gem.

Bluetooth UV Torch

3. QUICK START GUIDE
