Network setting
Sr. No. Network Setting
Parameters Description
1. IP AddressSet IP address to device for TCP/IP communication
2. Subnet Mask As per your network.
3. Gateway As per your network.
4. Local TCP Port For device indentification and communication
5. Local UDP Port For device indentification and communication.
6. Server IP Set Server IP Address, it is used when MAC security
feature is Enable.
7. PUSH Server1 IP Set Server IP Address where we want to push
transaction data using TCP.
8. PUSH Server1 Port Set Server Port Address where we want to push
transactiondata using TCP.
9. PUSH Server2 IP NA
10. PUSH Server2 Port NA
11. UDP PushServer IP Set Server IP Address where we want to push
transaction data using UDP.
12. UDP PushServer Port Set Server Port Address where we want to push
transactiondata using UDP.
13. HB Server IP Set Server IP Address where we want to push Heart
Beat data. Device sendsall important information to
this server.
14. HB Server Port Set Server Port Address where we want to push
Heart Beat data.
15. HB Time Set Heart Beat Time,this is time delay after which
controller send Device Information to HB Server IP.
