NB40PP
REV 01 – September 2019 - ENGLISH
SIREN PAIRING
Perform this operation when both NUBI 4.0 and the siren
are fixed in the final position. Press and hold the pairing
button for 3 seconds, until the blue LED flashes and a
beep is emitted. NUBI 4.0 is now in pairing state.
Battery test: As soon as ou enter pairing state, the green
LED will light up for 5 seconds if the batter is charged, or
the red LED if it is exhausted.
Walk test: When NUBI 4.0 is in pairing state, it will beep
ever time the integrated infrared sensor detects
movement, allowing the detector's range to be tested. The
test ends as soon as the siren sound recording starts or
exited prematurel from the pairing state.
Exit pairing state: You can cancel the pairing state
before start recording the sound with a short press of the
pairing button. In this case, an previousl stored siren
pairing will not be erased from the memor .
Pairing the siren: NUBI 4.0 is read to digitize the sound
of the siren and will start recording as soon as it receives a
sound level higher than 90Db. If ou have chosen
operating mode 1 it is sufficient to pla the siren for at least
10 seconds, if instead ou have chosen mode 2, ou will
make it sound for the desired time, in an case greater
than 10 seconds.
Av id l ud n ises: To avoid the risk of false recordings,
avoid producing loud noises (> 90Db) during this
procedure.
Pairing results: After the siren stops sounding, check the
status of the LEDs. The flashing green LED shows that the
operation was successful, the flashing red LED shows an
error, slow flashing means that the sound level is too low,
fast flashing indicates that the sound level is too high. In
case of error, tr to repeat the pairing operation, if this
persists, take the corresponding countermeasures. The
LEDs sta ON for 1 minute, to switch them off prematurel ,
just short press the pairing button.
Operating test: You can test NUBI 4.0 without delivering
the smoke within 20 minutes of pairing. The test is
identical, regardless of the operating mode 1 or 2 selected.
If ou make the siren sound less than the recorded time,
when the siren sound ends ou will hear a series of beeps
for 8 seconds. If the siren sounds longer, when the siren
sound ends ou will hear a beep ever 8 seconds for 5
minutes. If within these 5 minutes the infrared sensor
detects movement, ou will hear a series of beeps for 8
seconds and the test ends. After performing a test, ou still
have 20 minutes to perform another one without activating
smoke. NUBI 4.0 will enter standard operating mode 20
minutes after pairing or after the last test.
OPERATING MODE
NUBI 4.0 is normall inactive in "sleep mode". When it
receives a sound level greater than 90dB that matches to
the paired siren, it switches to the "active state", so an
movement detected b the built-in PIR will activate the
smoke output.
NUBI 4.0 remains in the "active state" when the the siren
sounds and returns to "sleep mode" according to the
selected mode 1 or 2. In mode 1 (Jumper open) NUBI 4.0
back to "sleep mode" 3 seconds after the end of the siren
sound, regardless of its duration. In mode 2 (Jumper
closed) NUBI 4.0 behaves as in mode 1 onl if the duration
of the siren sound has not exceeded that recorded during
the pairing. If the siren sounds longer, it will return to
"sleep mode" 5 minutes after the end of the sound.
This allows to discriminate two situations: an alarm
occurred b user error, which then disarms it within a
reasonable time, or a true alarm that will last longer. During
the 5 minutes after the sound ends, NUBI 4.0 will emit a
short beep ever 10 seconds to indicate this condition,
useful especiall to the owner of the s stem.
When NUBI 4.0 back to "sleep mode" it emits a series of
beeps for 8 seconds.
SMOKE CANISTER REPLACEMENT
The empt smoke canister must be replaced onl with the
original spare part. The smoke canister is supplied with the
activation card connected to the ends of the wires. This
card has a connector to be plugged to the appropriate one
placed on the motherboard.
Rem ve the NUBI 4.0 battery and wait at least 10
sec nds bef re replacing the sm ke cartridge.
MAINTENANCE
Replace the smoke canister ever 4 ears using onl the
original spare part.
WARRANTY
SMARTEK s.r.l. It guarantees its products against all
manufacturing defects for a period of 30 months from the
production date shown on the label.
RECOMMENDATIONS
Before leaving, ventilate the rooms thoroughl after the
smoke has been delivered.
TECHNICAL SPECIFICATIONS
Power suppl 3,6V lithium batter AA
Autonom About 10 ears
Size 12cm x 17cm x 14cm
Saturable volume 100m3
Weight 760g
Smoke average deliver time 25sec
Operating temperature From -20°C to +70°C
Maximum relative humidit 70%
