SMART Slate WS200 Manuel utilisateur

SMART Slate WS200

User’s Guide

Product Registration

If you register your SMART product, we’ll notify you of new features and software

upgrades.

Keep the following information available in case you need to contact SMART

Technical Support.

Serial Number: ________________________________________________

Date of Purchase: ________________________________________________

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause

harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause

harmful interference in which case the user will be required to correct the interference at his own expense.

Trademark Notice

The SMART logo and smarttech are trademarks or registered trademarks of SMART Technologies ULC in the U.S.

and/or other countries. All other third-party product and company names may be trademarks of their respective

owners.

transcribed, stored in a retrieval system or translated into any language in any form by any means without the prior

written consent of SMART Technologies ULC. Information in this manual is subject to change without notice and does

not represent a commitment on the part of SMART.

Patent No. US5448263; US6141000; US6320597; US6326954; US6337681; US6741267; US6747636; US7151533;

CA2058219; CA2252302. Other patents pending.

06/2009

Part No.

1| –

1About Your SMART Slate WS200......................................................1

Tethered Pen .....................................................................................2

USB Charging Cable..........................................................................2

SMART Notebook Software...............................................................2

Bluetooth® USB Wireless Adapter

(Not Included).....................................................................................3

2Attaching the Pen Tether ...................................................................5

Charging your Slate ...........................................................................6

Installing SMART Notebook software and SMART Board Drivers.....6

Establishing a Wireless Connection to Your Computer .....................7

Installing your Bluetooth USB Wireless Adapter (Not Included) ........8

3Using the Pen.....................................................................................9

Connecting Multiple Slates.................................................................9

Storing the Pen ..................................................................................9

Using the slate buttons.......................................................................9

Using the pen buttons......................................................................10

Storing the USB adapter..................................................................10

4Paper Underlays ..............................................................................11

Waste Electrical and Electronic Equipment Regulations (WEEE Directive)13

Restriction of Certain Hazardous Substances (RoHS Directive)............13

Batteries .................................................................................................13

Packaging...............................................................................................14

Covered Electronics Devices..................................................................14

China’s Electronic Information Products Regulations.............................14

U.S. Consumer Product Safety Improvement Act ..................................14

Online Information and Support..............................................................15

Training...................................................................................................15

Technical Support...................................................................................15

Shipping and Repair Status....................................................................15

General Inquiries....................................................................................16

Warranty.................................................................................................16

Registration ............................................................................................16

2| –

Part No.

Chapter 1

Overview

About Your SMART Slate WS200

The SMART Slate works with your computer and a SMART Board™ interactive

whiteboard and allows you to write notes, use applications and perform normal

computer operations. The slate connects wirelessly to your computer and has a

rage of 33" (10 m), allowing teachers to write notes and use applications from a

distance. You can use up to seven slates at the same time allowing multiple

teachers and students to write on the slate and have their notes appear on the

interactive whiteboard.

Customizable Buttons Power Switch

Power LED

Wireless Connection LED

Underlay Cover

Workspace

2 | CHAPTER 1 – OVERVIEW

Part No.

Tethered Pen

The pen controls the pointer on your display.

Move the pen above the surface of the slate to

move the pointer. When you touch the pen to

the slate your computer registers the point of

contact as a left mouse click. Touch the pen to

the slate to write notes and use computer

applications. The pen has a side switch and an

eraser that you can customize. You can attach

the pen tether so that you don’t misplace the

pen.

USB Charging Cable

Your can charge your slate by connecting it to your

computer with the USB charging cable. Your slate

comes with an installed lithium ion battery. It takes XX

to fully charge the battery, which lasts for XX hours.

SMART Notebook Software

Your slate comes with a SMART Notebook software CD

pack. The first CD contains SMART Notebook software

and the second CD contains the drivers you need to

connect your SMART Slate to your computer.

Pen Tether Slot

Pen Storage Compartment

Battery

Compartment

USB Wireless Adapter

Storage Compartment

Connect Button

Charging USB Cable Receptacle

Side Switch

Eraser

Tether

Part No.

Bluetooth® USB Wireless Adapter

(Not Included)

If your computer doesn’t have built-in Bluetooth

wireless capability, you must purchase the

Bluetooth USB wireless adapter (part # WS200-

BT) from you local SMART Reseller. The

Bluetooth USB wireless adapter enables you to

connect your slate to your computer.

Installation

USB Wireless

Adapter

WS200-BT

4 | CHAPTER 1 – OVERVIEW

Part No.

Chapter 2

Setting Up Your

SMART Slate

Before you can use your slate, you must do the following:

• Attach the pen tether (page 5).

• Install the battery (?) (page 6).

• Charge the slate (page 6).

• Install SMART Notebook software and SMART Board drivers on your

computer (page 6).

• Install a paper underlay (page 7).

• Establish a Bluetooth wireless connection (page 7).

• If your computer doesn’t have built-in Bluetooth wireless capability, install the

Bluetooth USB wireless adapter (page 8).

Attaching the Pen Tether

The tether connects the pen to the slate so you don’t misplace the pen.

To attach the tether to

the pen 1. Thread one tether loop through the hole at the end of the pen.

2. Feed the other tether loop through the first loop as shown in the diagram

below, and then pull the tether so the first loop is snug.

6 | CHAPTER 2 – SETTING UP YOUR SMART SLATE

Part No.

To attach the tether to

the slate 1. Place the tether loop that is free through the tether slot in the slate.

2. Feed the pen, with the tether attached, through the loop as shown in the

diagram below, and then pull the tether so the loop is snug.

Installing the Battery (?)

Charging your Slate

Your slate comes with an installed lithium ion battery that powers the slate so your

movement isn’t restricted by a power cable. You can charge the slate by

connecting it to your computer with the included USB charging cable. It takes XX

hours to charge the slate, and a fully charged slate lasts for XX hours of use.

If the power LED glows green, the slate is fully charged. If the power LED glows

red, the slate needs to be charged.

To charge your slate 1. Turn on your computer.

2. Connect the USB A connector of the charging cable to your computer.

3. Connect the USB B connector of the charging cable to your slate.

The slate starts to charge and the power LED glows green.

Installing SMART Notebook software and SMART Board

Drivers

Your SMART Slate WS200 comes with a SMART Notebook software and SMART

Board drivers CD pack. SMART Notebook is presentation and collaboration

software that is designed to work with your slate. The SMART Board drivers

enables your computer to connect to the slate.
