Prism Solar Motion Light
Smart Solar is a Smart Living Home & Garden brand. © 2021 V0 #SmartLivingHG
Press the button under the sensor to turn the unit on. It blinks once to let you know it is in mode 1. Press
the button a 2nd time and it blinks twice to let you know it is in mode 2. Press the button a 3rd time and
light blinks 3 times to let you know it is in mode 3. Press the button a 4th time to turn it off. In all 3 modes
the unit uses a light sensor in the solar panel to stay off during the day and work automatically at night
when dark enough.
As rechargeable batteries get older and go through more charge/discharge cycles they become less
efficient and the capacity reduces. If you find that the performance of the battery seems to be reduced
try boost charging the battery by turning it off to charge for 2-3 sunny days. If that does not improve the
performance you can replace the battery with one of the same specs.
Rechargeable Li-Ion (Lithium-Ion) battery size 18650, 3.7v, 1500mAh.
To replace the battery remove the screws
on the back of the unit . The battery
compartment is wired to the back cover.
Carefully pry the unit open so you do not
detach any wires. Remove the battery and
install a new one of the same specs. Then
screw the unit back together.
We recommend leaving it switched off for 2 sunny days to ensure the
battery is fully charged before first use. Once charged press the on button
to select the desired mode and your light with work automatically at night
using a built in light sensor.
Mode 1: light off, when motion is detected it illuminates on high brightness for 60 seconds
Mode 2: light stays on low, when motion is detected it illuminates on high for 60 seconds then returns to low
Mode 3: light stays on medium brightness all night, motion detector not active
Operation:
Battery:
Change Battery:
First Use:
<50%
48h
100%
1. Make sure the unit receives direct sun on the panel during the day. Move to a different location if needed.
2. Ensure you don’t have any lights shining on it at night that will interfere with the light sensor.
3. Press the on button and count the flashes to check which mode you selected.
4. Clean the solar panel and motion sensor with soft cloth and glass cleaner.
5. Replace the battery if needed.
6. If you replace the battery make sure to use the proper type and install correctly.
7. Check to see if any water has gotten into the light.
Troubleshooting
Back (Outside)
Back
(Inside)
Battery
Front
(Inside)
