Measure, Analyze, Control
... be smart
USER MANUAL8
WIRELESS CONNECTION
For normal operation of the device,
it is necessary, at the place of its
installation, to ensure the presence of
a signal from your wireless network.
When you first start up or after
restoring the factory settings, the
device enters the wireless access point
mode.
To connect to your wireless
network, follow these steps:
1. On your computer or phone, go to
the list of wireless networks and
select “smart-MAC” + network
connection (your device number).
If the “smart-MAC” + network (your
device number) is missing, click the
Reset button on your device. The
default password for connection is
missing.
2. After successful connection, enter
http://192.168.4.1 in the address
bar of the browser and go to the
device’s built-in WEB site. The
default password is 0000
3. In the «WiFi and Network» section,
select the name (SSID) of your
network from the list of wireless
networks, click the «Connect»
button and enter the password for
your network. If the name (SSID)
of your network is not in the list of
wireless networks, refresh the list
by clicking the Refresh button.
4. Update the connection status or
reload the page and make sure that
the connection is successful and
that the status bar contains the
internal IP address of the device. In
case of a connection error, repeat
step 3.
5. Go to the device’s built-in WEB
site using the IP address received
when connecting and continue the
settings.
SETTINGS
To complete the installation and
connection of the device, configure the
settings by performing the following
steps:
1. In the «Configuration» section,
select the language of the WEB
interface that is convenient for you.
2. Change the password to enter the
device’s WEB interface.
The default password of 0000 will
not allow you to connect devices to
your account on the «cloud server».
The password must consist of
numbers and have a length of no
more than 10. Your new password
will allow you to access data from
your device stored on a «cloud
server».
3. In the «Data» section, you can set
the initial values of accumulative
counters.
