Smart Keeper PC Lock Manuel utilisateur
Comxi World, LLC
Glen Allen, Virginia USA Phone. 1 (804) 299-5234
ONE YEAR LIMITED WARRANTY
Product should only be used as directed. Warranty provided for
1 year after purchase. This limited warranty does not cover and
Comxi World is not responsible for: Damages caused by misuse,
abuse, accidents, fire, theft, disappearance, misplacement,
uctuations and reckless, willful, or intentional conduct. Damages
caused by usage that is not in accordance with product instructions
or user manuals, failure to follow the product instructions or user
manuals
www.comxiworld.com
PC LOCK
(COMBINATION VERSION)
USER GUIDE
PC Lock parts and Notice
1
①Please read user guide carefully before use
②We are not responsible for lost combination
PC Lock Parts
Notice
Check for compatibility
(Record your combination in a safe place)
PC Lock Body Security cable Bracket
Space between screw
and edge of the desktop
panel must be less than
0.63 inches (16mm) to
be PC lock compatible
③ For PC relocation or theft prevention, Put security cable in the shackle.
Setting your own combination
2
①Initial default combination is 0-0-0-0
② Turn the shackle 180 degrees according to the diagram, then press the
shackle in direction of arrow
③ Set your new combination with shackle pressed in
* When changing combination, for easy
setup, place the shackle upward (see left)
* Not possible to reset lost combination
PC Lock installation and removal
3
Install bracket
Assign a screw on PC panel to attach PC Lock, remove the screw
(see diagram)
①Place the
bracket by
the hole
②Reinsert the
screw
③ Bracket attached
Attaching PC Lock into the bracket
Insert PC Lock body into the bracket according to the diagram (see below)
Locking PC Lock
PC Lock removal
Insert Direction
Turn the shackle into the PC Lock body and press the shackle in according
to the diagram (see below)
To remove PC Lock reverse the installation steps
① ②
③ ④
